Standards Content (sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Advanced Surface Movement Guidance and Control System (A-SMGCS) - Part 4: Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for a deployed non-cooperative sensor including its interfaces - Sub-part 2: Specific requirements for a deployed Surface Movement Radar sensor49.090On-board equipment and instruments03.220.50Air transportICS:Ta slovenski standard je istoveten z:EN 303 213-4-2 Version 1.1.1SIST EN 303 213-4-2 V1.1.1:2010en01-december-2010SIST EN 303 213-4-2 V1.1.1:2010SLOVENSKI

STANDARD
SIST EN 303 213-4-2 V1.1.1:2010

ETSI EN 303 213-4-2 V1.1.1 (2010-10)European Standard (Telecommunications series) Advanced Surface Movement Guidanceand Control System (A-SMGCS);Part 4: Community Specification for application under theSingle European Sky Interoperability Regulation EC 552/2004for a deployed non-cooperative sensor including its interfaces;Sub-part 2: Specific requirements fora deployed Surface Movement Radar sensor SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)2

Reference DEN/AERO-00001-4-2 Keywords air traffic management, aeronautical, interoperability ETSI 650 Route des Lucioles F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: +33 4 92 94 42 00
Fax: +33 4 93 65 47 16

Siret N° 348 623 562 00017 - NAF 742 C Association à but non lucratif enregistrée à la Sous-Préfecture de Grasse (06) N° 7803/88

Important notice Individual copies of the present document can be downloaded from: http://www.etsi.org The present document may be made available in more than one electronic version or in print. In any case of existing or perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF). In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive within ETSI Secretariat. Users of the present document should be aware that the document may be subject to revision or change of status. Information on the current status of this and other ETSI documents is available at http://portal.etsi.org/tb/status/status.asp If you find errors in the present document, please send your comment to one of the following services: http://portal.etsi.org/chaircor/ETSI_support.asp Copyright Notification No part may be reproduced except as authorized by written permission. The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2010. All rights reserved.

DECTTM, PLUGTESTSTM, UMTSTM, TIPHONTM, the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members. 3GPPTM is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners. LTE™ is a Trade Mark of ETSI currently being registered for the benefit of its Members and of the 3GPP Organizational Partners. GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association. SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)3 Contents Intellectual Property Rights ................................................................................................................................ 4 Foreword ............................................................................................................................................................. 4 Introduction ........................................................................................................................................................ 5 1 Scope ........................................................................................................................................................ 6 2 References ................................................................................................................................................ 6 2.1 Normative references ......................................................................................................................................... 6 2.2 Informative references ........................................................................................................................................ 6 3 Definitions and abbreviations ................................................................................................................... 7 3.1 Definitions .......................................................................................................................................................... 7 3.2 Abbreviations ..................................................................................................................................................... 9 4 Requirements for implementing Surface Movement Radar (SMR) sensor for A-SMGCS Systems ....... 9 4.1 Design Requirements for SMR sensor for A-SMGCS Systems ......................................................................... 9 4.1.1 General Requirements ................................................................................................................................... 9 4.1.2 Coverage ....................................................................................................................................................... 9 4.1.3 Safety interlocks ........................................................................................................................................... 9 4.2 Built requirements for SMR sensors for A-SMGCS Systems ............................................................................ 9 4.2.1 Basic conformity tests ................................................................................................................................... 9 4.2.2 Performance tests ........................................................................................................................................ 10 4.3 Requirements for site testing procedures for SMR sensor for A-SMGCS Systems ......................................... 10 4.3.1 Site testing procedures ................................................................................................................................ 10 4.4 Maintenance Requirements for SMR sensors for A-SMGCS Systems ............................................................ 10 Annex SA (normative): Standards Annex ............................................................................................ 11 SA.1 Correspondence between this European Standard and the Single European Sky Interoperability Regulation for the A-SMGCS non-cooperative sensor constituent ........................................................ 11 Annex A (normative): Checklist ......................................................................................................... 13 A.1 Interoperability Regulation Annex II Essential Requirements; Part A: General requirements .............. 13 A.2 Interoperability Regulation Annex II Essential Requirements; Part B: Specific requirements .............. 16 A.2.1 Systems and procedures for airspace management........................................................................................... 16 A.2.2 Systems and procedures for air traffic flow management ................................................................................ 17 A.2.3 Systems and procedures for air traffic services ................................................................................................ 17 A.2.3.1 Flight data processing systems.................................................................................................................... 17 A.2.3.2 Surveillance data processing systems ......................................................................................................... 18 A.2.3.3 Human-machine interface systems ............................................................................................................. 19 A.2.4 Communications systems and procedures for ground-to-ground, air-to-ground and air-to-air communications ............................................................................................................................................... 20 A.2.5 Navigation systems and procedures ................................................................................................................. 21 A.2.6 Surveillance systems and procedures ............................................................................................................... 21 A.2.7 Systems and procedures for aeronautical information services ........................................................................ 22 A.2.8 Systems and procedures for the use of meteorological information ................................................................. 22 Annex B (informative): The EN title in the official languages ........................................................... 24 Annex C (informative): Bibliography ................................................................................................... 26 History .............................................................................................................................................................. 27

SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)4 Intellectual Property Rights IPRs essential or potentially essential to the present document may have been declared to ETSI. The information pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web server (http://webapp.etsi.org/IPR/home.asp). Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web server) which are, or may be, or may become, essential to the present document. Foreword This European Standard (Telecommunications series) has been produced by ETSI Technical Committee Aeronautics (AERO). The present document has been produced by ETSI in response to European Commission mandate M/390 for the Interoperability of the European Air Traffic Management Network.

The present document has been developed in cooperation with Eurocae for compliance with the Essential Requirements of the Single European Sky Interoperability Regulation 552/2004 [i.1] and/or requirements given in implementing rules for interoperability based on the Single European Sky Interoperability Regulation. The presumption of conformity which is linked to the full application of EN 303 213 (parts 1 to 4) can only be claimed after EN 303 213 (parts 1 to 4) has been listed in the Official Journal of the European Union as Community Specification. General and specific requirements for presumption of conformity to SES Interoperability Regulation 552/2004 as amended by Regulation 1070/2009 are given in the normative annexes of the present document. NOTE: Other requirements and other EU Regulations and/or Directives may be applicable to the product(s) falling within the scope of the present document. If the present document gives no presumption of conformity, the manufacturer has to demonstrate the compliance for those essential requirements listed in the normative annexes of the present document by its own to the relevant supervisory authority. The present document is part 4, sub-part 2 of a multi-part deliverable covering Advanced Surface Movement Guidance and Control System (A-SMGCS), as identified below: Part 1: "Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for A-SMGCS Level 1 including external interfaces"; Part 2: "Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for A-SMGCS Level 2 including external interfaces"; Part 3: "Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for a deployed cooperative sensor including its interfaces"; Part 4: "Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for a deployed non-cooperative sensor including its interfaces ";

Sub-part 1: "Generic requirement for non-cooperative sensor";

Sub-part 2: "Specific requirements for a deployed Surface Movement Radar sensor". Part 5: "Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive for transmitter used in multilateration equipment"; SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)5 Part 6: "Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive for deployed surface movement radar sensors".

National transposition dates Date of adoption of this EN: 15 October 2010 Date of latest announcement of this EN (doa): 31 January 2011 Date of latest publication of new National Standard or endorsement of this EN (dop/e):

31 July 2011 Date of withdrawal of any conflicting National Standard (dow): 31 July 2012

Introduction The European Union launched the Legislation "Single European Sky" (SES) in 2002 which was adopted in 2004 and amended by Regulation (EC) No 1070/2009 [i.5]. The SES legislation is based on a framework of 4 regulations, which includes "the Interoperability Regulation" (EC 552/2004 [i.1]). The objective of the Interoperability Regulation is to ensure interoperability of the European Air Traffic Management Network (EATMN) consistent with air navigation services. Under this regulation, the use of a European Standard referenced in the Official Journal of the European Union as Community Specification (CS) is a means of compliance to the essential requirements of the Regulation and/or the relevant implementing rules for interoperability. The present document takes into account the Council Decision 2009/320/EC endorsing the European Air Traffic Management Master Plan of the Single European Sky ATM Research (SESAR) project [i.3]. SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)6 1 Scope The present document is applicable to deployed Surface Movement Radar sensor as a constituent of an Advanced Surface Movement Guidance and Control System in addition to EN 303 213-4-1 [2]. The present document provides a European Standard for manufacturers of the non-cooperative sensor constituent, who have to demonstrate and declare conformity for their constituent to the IOP Regulation. Any software elements related to the software assurance level of an A-SMGCS are outside of the scope of the present document. As such the essential requirements of the Interoperability Regulation are not considered for software elements within the present document. The present document does not give presumption of conformity related to the environmental constraints, procedure level, effect of harmful interference and civil/military coordination. NOTE 1: For these ERs, please refer to the Air Navigation Service Provider procedures. NOTE 2: For those parts of the essential requirements, where annexes A and SA give no presumption of conformity, please refer to the Air Navigation Service Provider procedures. Requirements in the present document which refer to "should" statements or recommendations in the normatively referenced material (clause 2.1) are to be interpreted as fully normative ("shall") for the purpose of compliance with the present document. 2 References References are either specific (identified by date of publication and/or edition number or version number) or non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the reference document (including any amendments) applies. Referenced documents which are not found to be publicly available in the expected location might be found at http://docbox.etsi.org/Reference. NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee their long term validity. 2.1 Normative references The following referenced documents are necessary for the application of the present document. [1] EUROCAE ED-116 (ED-116 January 2004): "MOPS for Surface Movement Radar Sensor Systems for Use in A-SMGCS". [2] ETSI EN 303 213-4-1: "Advanced Surface Movement Guidance and Control System (A-SMGCS); Part 4: Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for a deployed non-cooperative sensor including its interfaces; Sub-part 1: Generic requirements for non-cooperative sensor". 2.2 Informative references The following referenced documents are not necessary for the application of the present document but they assist the user with regard to a particular subject area. [i.1] Regulation (EC) No 552/2004 of the regulation of the European Parliament and of the Council of 10 March 2004 on the interoperability of the European Air Traffic Management network (interoperability Regulation), OJ L 96, 31.03.2004 as amended by Regulation (EC) No 1070/2009. SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)7 [i.2] Regulation (EC) No 549/2004 of the European Parliament and of the Council of 10 March 2004 laying down the framework for the creation of the single European sky (the framework Regulation), OJ L 96, 31.03.2004 as amended by Regulation (EC) No 1070/2009. [i.3] Council Decision 2009/320/EC endorsing the European Air Traffic Management Master Plan of the Single European Sky ATM Research (SESAR) project, 30.03.2009. [i.4] ICAO Document 9830, AN/452, Advanced Surface Movement Guidance and Control Systems

(A-SMGCS) Manual, First Edition, 2004. [i.5] Regulation (EC) No 1070/2009 of the European Parliament and of the Council of 21 October 2009 amending Regulations (EC) No 549/2004, (EC) No 550/2004, (EC) No 551/2004 and (EC) No 552/2004 in order to improve the performance and sustainability of the European aviation system, OJ L 300, 14.11.2009. [i.6] ETSI EN 303 213-1: "Advanced Surface Movement Guidance and Control System (A-SMGCS); Part 1: Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for A-SMGCS Level 1 including external interfaces". [i.7] ETSI EN 303 213-2: "Advanced Surface Movement Guidance and Control System (A-SMGCS); Part 2: Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for A-SMGCS Level 2 including external interfaces". [i.8] ETSI EN 303 213-3: "Advanced Surface Movement Guidance and Control System (A-SMGCS); Part 3: Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 for a deployed cooperative sensor including its interfaces". 3 Definitions and abbreviations 3.1 Definitions For the purposes of the present document, the following terms and definitions apply: A-SMGCS Level 1: A-SMGCS including a comprehensive Surveillance element capable of the location and classification of all aircraft and vehicles within the area of interest and the identification of cooperative aircraft and vehicles

Figure 1: A-SMGCS Level 1 Functional Configuration SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)8 A-SMGCS Level 2: A-SMGCS including the capabilities of A-SMGCS Level 1 and uses the comprehensive surveillance data available to monitor the situation in the area of interest against a set of rules which will enable the system to alert the user to hazardous situations

Figure 2: A-SMGCS Level 2 Functional Configuration Advanced Surface Movement Guidance and Control Systems: systems providing routing, guidance, surveillance for the control of aircraft and vehicles in order to maintain the declared surface movement rate under all local weather conditions within the aerodrome Visibility Operational Level (AVOL) while maintaining the required level of safety NOTE: This definition is derived from the ICAO Document 9830 [i.4]. aerodrome: defined area on land or water (including any buildings, installations, and equipment) intended to be used either wholly or in part for arrival, departure and surface movement of aircraft NOTE: This definition is derived from the ICAO Document 9830 [i.4]. apron: defined area on a land aerodrome, intended to accommodate aircraft for purposes of loading or unloading passengers, mail or cargo, fuelling, parking or maintenance NOTE: This definition is derived from the ICAO Document 9830 [i.4]. availability: probability that a system or an item is in a functioning state at a given point in time classification: function which groups targets into various types (e.g. large, medium, small) constituents: tangible objects such as hardware and intangible objects such as software upon which the interoperability of the EATMN depends NOTE: This is the legally binding definition in the context of Single European Sky [i.2]. manoeuvring area: part of an aerodrome to be used for take-off, landing and taxiing of aircraft, excluding aprons NOTE: This definition is derived from the ICAO Document 9830 [i.4]. movement area: part of an aerodrome to be used for take-off, landing and taxiing of aircraft, consisting of the manoeuvring area and apron(s) NOTE: This definition is derived from the ICAO Document 9830 [i.4]. procedure: standard method for either the technical or operational use of the system, in the context of agreed and validated concepts of operation requiring uniform implementation throughout the EATMN NOTE: This is the legally binding definition in the context of Single European Sky [i.2]. system: aggregation of airborne and groundbased constituents, as well as space-based equipment, that provides support for air navigation services for all phases of flight NOTE: This is the legally binding definition in the context of Single European Sky [i.2]. SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)9 target: aircraft, vehicle or obstacle that is displayed on a surveillance display NOTE: This definition is derived from the ICAO Document 9830 [i.4]. update: renewal of target reports relating to all targets under surveillance Further legally binding definitions in the context of Single European Sky are given in [i.2]. 3.2 Abbreviations For the purposes of the present document, the following abbreviations apply: A-SMGCS Advanced Surface Movement Guidance and Control Systems ATM Air Traffic Management AVOL Aerodrome Visibility Operational Level CS Community Specification doa date of announcement dow date of withdrawal EATMN European Air Traffic Management Network EC European Communities EN European Norm - (standard) ER Essential Requirement EUROCAE EUROpean organization for Civil Aviation Equipment EUROCONTROL EUROpean organization for the safety of air navigation ICAO International Civil Aviation Organization IOP Regulation InterOPerability Regulation SES Single European Sky SMR Surface Movement Radar 4 Requirements for implementing Surface Movement Radar (SMR) sensor for A-SMGCS Systems This clause defines the minimum requirements for a SMR sensor of A-SMGCS System. 4.1 Design Requirements for SMR sensor for A-SMGCS Systems 4.1.1 General Requirements The SMR sensor shall comply with the requirements as defined in EN 303 213-4-1 [2]. 4.1.2 Coverage The constituent shall have the minimum coverage as defined in ED-116 [1], clause 2.8. 4.1.3 Safety interlocks The constituent shall comply with the requirements as defined in ED-116 [1], clause 2.14. 4.2 Built requirements for SMR sensors for A-SMGCS Systems 4.2.1 Basic conformity tests The basic conformity tests shall comply with the requirements as defined in ED-116 [1], clause 5.3. SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)10 4.2.2 Performance tests The performace tests shall comply with the requirements as defined in ED-116 [1], clause 5.4. 4.3 Requirements for site testing procedures for SMR sensor for A-SMGCS Systems 4.3.1 Site testing procedures The on site testing procedures shall be performed as defined in ED-116 [1], clause 6.4. 4.4 Maintenance Requirements for SMR sensors for A-SMGCS Systems The constituent shall comply with the maintenance requirements as defined in ED-116 [1], clause 2.21. SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)11 Annex SA (normative): Standards Annex This annex provides a relationship between the present document and the Essential Requirements of the Single European Sky Interoperability Regulation. The A-SMGCS SMR constituent shall comply with the Essential Requirements of the Interoperability Regulation as defined and described in the traceability matrixes of this annex (tables SA.1 and SA.2). SA.1 Correspondence between this European Standard and the Single European Sky Interoperability Regulation for the A-SMGCS non-cooperative sensor constituent Table SA.1: Traceability from Interoperability Regulation to clauses of the present document (Essential) Requirements (ERs) of SES Interoperability Regulation, Annex II, Part A Clause(s) of the present document Qualifying remarks/Notes ER 1 Seamless operation 4.1.2 Coverage 4.1.3 Safety interlocks 4.2.1 Basic conformity tests 4.2.2 Performance tests 4.3.1 Site testing procedures 4.4 Maintenance Requirements for SMR sensors for A-SMGCS Systems 4.5.2 Noise and vibration

ER 2 Support for new concepts of operation
Operation is only applicable at the system level ER 3 Safety n/a
ER 4 Civil-military coordination

The present document does not give presumption of conformity ER 5 Environmental constraints The present document does not give presumption of conformity

ER 6 Principles governing the logical architecture of systems n/a
ER 7 Principles governing the construction of systems n/a

(Essential) Requirements (ERs) of SES Interoperability Regulation, Annex II, Part B Clause(s) of the present document Qualifying remarks/Notes ER 1.1 Seamless operation of airspace management

Not covered by EN 303 213 (parts 1 to 4) ER 2.1 Seamless operation of air traffic flow management

Not covered by EN 303 213 (parts 1 to 4) ER 3.1.1 Seamless operation of flight data processing

Not covered by EN 303 213 (parts 1 to 4) ER 3.1.2 Support for new concepts of operation for flight data processing

Not covered by EN 303 213 (parts 1 to 4) ER 3.2.1 Seamless operation surveillance data processing systems n/a

ER 3.2.2 Support for new concepts of operation for surveillance data processing systems n/a

ER 3.3.1 Seamless operation of Human-machine interface systems n/a
SIST EN 303 213-4-2 V1.1.1:2010

ETSI ETSI EN 303 213-4-2 V1.1.1 (2010-10)12 (Essential) Requirements (ERs) of SES Interoperability Regulation, Annex II, Part B Clause(s) of the present document Qualifying remarks/Notes ER 3.3.2 Support for new concepts of operation for Human-machine interface systems n/a

ER 4.1 Seamless operation of Communications systems and procedures for ground-to-ground, air-to-ground and air-to-air communications

Not covered by EN 303 213 (parts 1 to 4) ER 4.2 Support for new concepts of operation for Communications systems and procedures for ground-to-ground, air-to-ground and air-to-air communications

Not covered by EN 303 213 (parts 1 to 4) ER 5.1 Seamless operation of Navigation systems and procedures

Not covered by EN 303 213 (parts 1 to 4) ER 6.1 Seamless operation of Surveillance systems and procedures

Not covered by EN 303 213 (parts 1 to 4) ER 7.1 Seamless operation of Systems and procedures for aeronautical information services

Not covered by EN 303 213 (parts 1 to 4) ER 8.1 Seamless operation of systems and procedures for the use of meteorological information

Not covered by EN 303 213 (parts 1 to 4) ER 8.2 Support for new concepts of operation for systems and procedures for the use of meteorological information

Not covered by EN 303 213 (parts 1 to 4)

Table SA.2: Traceability from clauses of the present document to Interoperability Regulation Clause(s) of the present document (Essential) Requirements (ERs) of SES Interoperability Regulation, Annex II, Parts A and B Qualifying remarks/Notes 4.1.1 General Requirements ER 1 Seamless operation

4.1.2 Coverage ER 1 Seamless operation
4.1.3 Safety interlocks ER 1 Seamless operation
4.2.1 Basic conformity tests ER 1 Seamless operation
4.2.2 Performance tests ER 1 Seamless operation
4.3.1 Site testing procedures ER 1 Seamless operation

4.4 Maintenance Requiremens for SMR sensors for A-SMGCS Systems ER 1 Seamless operation

NOTE: Other requirements and other EU Regulations and/or Directives may be applicable to the product(s) falling within the scope of the present document. SIST EN 303 213-4-2 V1.1.1:2010
