ETSI TS 102 257 V1.1.1 (2003-08)
Technical Specification
Private Integrated Services Network (PISN);
Inter-exchange Signalling Protocol;
Make Call Request supplementary service
---------------------- Page: 3 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
2 ETSI TS 102 257 V1.1.1 (2003-08)
Reference
DTS/ECMA-00232
Keywords
PISN, QSIG, stage 3, supplementary service
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, send your comment to:
editor@etsi.org
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2003.
All rights reserved.
TM TM TM
DECT , PLUGTESTS and UMTS are Trade Marks of ETSI registered for the benefit of its Members.
TM
TIPHON and the TIPHON logo are Trade Marks currently being registered by ETSI for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
---------------------- Page: 4 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
3 ETSI TS 102 257 V1.1.1 (2003-08)
Contents
Intellectual Property Rights.6
Foreword.6
Brief History.6
1 Scope.7
2 Conformance.7
3 References (normative).7
4 Definitions.8
4.1 External definitions.8
4.2 Other definitions.8
4.2.1 Co-operating PINX.8
4.2.2 Co-operating User.8
4.2.3 Destination PINX.8
4.2.4 Destination User.9
4.2.5 Make Call Request.9
4.2.6 Original Call.9
4.2.7 Requested Call.9
4.2.8 Requesting PINX.9
4.2.9 Requesting User.9
5 List of acronyms.9
6 Signalling Protocol for the support of SS-MCR.10
6.1 SS-MCR description.10
6.2 SS-MCR operational requirements.10
6.2.1 Requirements on a Requesting PINX .10
6.2.2 Requirements on a Co-operating PINX .10
6.2.3 Requirements on a Destination PINX.11
6.2.4 Requirements on a Transit PINX.11
6.3 SS-MCR coding requirements.12
6.3.1 Operations.12
6.3.2 Information elements.15
6.3.2.1 Facility information element.15
6.3.2.2 Other information elements.15
6.3.3 Messages.15
6.4 SS-MCR state definitions.15
6.4.1 States at the Requesting PINX.15
6.4.1.1 State MCR-Idle.15
6.4.1.2 State MCR-Active.15
6.4.2 States at the Co-operating PINX.15
6.4.2.1 State MCR-Idle.15
6.4.2.2 State MCR-Active.15
6.4.3 States at the Destination PINX .16
6.5 SS-MCR signalling procedures .16
6.5.1 Actions at the Requesting PINX.16
6.5.1.1 Normal procedures.16
6.5.1.1.1 Activation/deactivation/interrogation.16
6.5.1.1.2 Invocation and operation .16
6.5.1.2 Exceptional procedures.16
6.5.1.2.1 Activation/deactivation/interrogation.16
6.5.1.2.2 Invocation and operation .16
6.5.2 Actions at the Co-operating PINX.16
6.5.2.1 Normal procedures.17
6.5.2.1.1 Activation / deactivation / interrogation.17
6.5.2.1.2 Invocation and operation .17
ETSI
---------------------- Page: 5 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
4 ETSI TS 102 257 V1.1.1 (2003-08)
6.5.2.2 Exceptional procedures.17
6.5.2.2.1 Activation/deactivation/interrogation.17
6.5.2.2.2 Invocation and operation .17
6.5.3 Actions at the Destination PINX.18
6.5.3.1 Normal procedures.18
6.5.3.1.1 Activation / deactivation / interrogation.18
6.5.3.1.2 Invocation and operation .18
6.5.3.2 Exceptional procedures.18
6.5.3.2.1 Activation / deactivation / interrogation.18
6.5.3.2.2 Invocation and operation .18
6.5.4 Actions at a Transit PINX.18
6.6 SS-MCR impact of interworking with public ISDNs.18
6.7 SS-MCR impact of interworking with non-ISDNs .18
6.8 Protocol interactions between SS-MCR and other supplementary services and ANFs.18
6.8.1 Calling Line Identification Presentation (SS-CLIP) .19
6.8.2 Connected Line Identification Presentation (SS-COLP) .19
6.8.3 Calling/Connected Line Identification Restriction (SS-CLIR).19
6.8.4 Calling Name Identification Presentation (SS-CNIP).19
6.8.5 Calling Name Identification Presentation (SS-CNIR) .19
6.8.6 Connected Name Identification Presentation (SS-CONP).19
6.8.7 Completion of Call to Busy Subscriber (SS-CCBS).19
6.8.8 Completion of Call on No Reply (SS-CCNR) .19
6.8.9 Call Transfer (SS-CT).19
6.8.10 Call Forwarding Unconditional (SS-CFU) .19
6.8.11 Call Forwarding Busy (SS-CFB).19
6.8.12 Call Forwarding No Reply (SS-CFNR).20
6.8.13 Call Deflection (SS-CD).20
6.8.14 Path Replacement (ANF-PR).20
6.8.15 Call Offer (SS-CO) .20
6.8.16 Call Intrusion (SS-CI).20
6.8.17 Do not Disturb (SS-DND) .20
6.8.18 Do not Disturb Override (SS-DNDO) .20
6.8.19 Advice of Charge (SS-AOC) .20
6.8.20 Recall (SS-RE).20
6.8.21 Call Interception (ANF-CINT) .20
6.8.22 Transit Counter (ANF-TC) .21
6.8.23 Route Restriction Class (ANF-RRC).21
6.8.24 Message Waiting Indication (SS-MWI) .21
6.8.25 Wireless Terminal Location Registration (SS-WTLR).21
6.8.26 Wireless Terminal Incoming Call (ANF-WTMI).21
6.8.27 Wireless Terminal Outgoing Call (ANF-WTMO).21
6.8.28 Wireless Terminal Authentication of a WTM User (SS-WTAT) .21
6.8.29 Wireless Terminal Authentication of the PISN (SS-WTAN) .21
6.8.30 Private User Mobility Incoming Call (ANF-PUMI).21
6.8.31 Private User Mobility Outgoing Call (ANF-PUMO).21
6.8.32 Private User Mobility Registration (SS-PUMR).21
6.8.33 Common Information (ANF-CMN) .21
6.8.34 Call Priority Interruption (Protection) (SS-CPI(P)) .21
6.8.35 Single Step Call Transfer (SS-SSCT) .21
6.3.36 Simple Dialog (SS-SD).22
6.8.37 Global Call Identification and Call Linkage (ANF-CIDL).22
6.8.38 Short Message Service (SS-SMS) .22
6.8.39 Message Centre Monitoring (SS-MCM).22
6.8.40 Mailbox Identification (SS-MID) .22
6.9 SS-MCR parameter values (Timers) .22
6.9.1 Timer T1.22
Annex A (normative): Protocol Implementation Conformance Statement (PICS) Proforma .23
A.1 Introduction.23
A.2 Instructions for completing the PICS proforma .23
A.2.1 General structure of the PICS proforma .23
ETSI
---------------------- Page: 6 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
5 ETSI TS 102 257 V1.1.1 (2003-08)
A.2.2 Additional information.24
A.2.3 Exception information.24
A.3 PICS proforma for ECMA-344 .24
A.3.1 Implementation identification.24
A.3.2 Protocol summary.25
A.3.3 General.25
A.3.4 Procedures.25
A.3.5 Coding.26
A.3.6 Timers.26
Annex B (informative): Examples of Message Sequences.27
B.1 Example message sequences for invocation and operation of SS-MCR.28
B.1.1 Example message sequences without prior existing connection .28
B.1.2 Example message sequences of a successful communication with a message centre .31
Annex C (informative): Specification and Description Language (SDL) Representation of
Procedures.32
C.1 SDL representation of SS-MCR at the Requesting PINX.33
C.2 SDL representation of SS-MCR at the Co-operating PINX.34
C.3 SDL representation of SS-MCR at the Destination PINX .35
History .36
ETSI
---------------------- Page: 7 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
6 ETSI TS 102 257 V1.1.1 (2003-08)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Technical Specification (TS) has been produced by ECMA on behalf of its members and those of the European
Telecommunications Standards Institute (ETSI).
Brief History
The present document is one of a series of ECMA Standards defining services and signalling protocols applicable to
Private Integrated Services Networks (PISNs). The series uses ISDN concepts as developed by ITU-T and conforms to
the framework of International Standards for Open Systems Interconnection as defined by ISO/IEC. It has been
produced under ETSI work item DTS/ECMA-00232.
The present document specifies the signalling protocol for use at the Q reference point in support of the Make Call
Request supplementary service. The protocol defined in the present document forms part of the PSS1 protocol
(informally known as QSIG).
The present document is based upon the practical experience of ECMA member companies and the results of their
active and continuous participation in the work of ISO/IEC JTC1, ITU-T, ETSI and other international and national
standardization bodies. It represents a pragmatic and widely based consensus.
ETSI
---------------------- Page: 8 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
7 ETSI TS 102 257 V1.1.1 (2003-08)
1 Scope
The present document specifies the signalling protocol for the support of the Supplementary Service Make Call Request
(SS-MCR) at the Q reference point between Private Integrated services Network eXchanges (PINXs) connected
together within a Private Integrated Services Network (PISN).
Supplementary service MCR enables a Requesting User to request a Co-operating User to establish a new Requested
Call to a Destination User. This new Requested Call between the Co-operating and Destination User can be either a
Basic call or a Call Independent Signalling Connection.
The Q reference point is defined in ECMA-133 [1].
Service specifications are produced in three stages and according to the method specified in ETS 300 387 [6]. The
present document contains the stage 3 specification for the Q reference point and satisfies the requirements identified by
the stage 1 and stage 2 specifications in ECMA-343 [4].
The signalling protocol for SS-MCR operates on top of the signalling protocol for basic circuit switched call control, as
specified in ECMA-143 [2], and uses certain aspects of the generic procedures for the control of supplementary services
specified in ECMA-165 [3].
The present document also specifies additional signalling protocol requirements for the support of interactions at the
Q reference point between SS-MCR and other supplementary services and ANFs.
The present document is applicable to PINXs, which can interconnect to form a PISN.
2 Conformance
In order to conform to the present document, a PINX shall satisfy the requirements identified in the Protocol
Implementation Conformance Statement (PICS) proforma in annex A.
Conformance to the present document includes conforming to those clauses that specify protocol interactions between
SS-MCR and other supplementary services and ANFs for which signalling protocols at the Q reference point are
supported in accordance with the stage 3 standards concerned.
3 References (normative)
The following standards contain provisions, which, through reference in this text, constitute provisions of the present
document. All standards are subject to revision, and parties to agreements based on the present document are
encouraged to investigate the possibility of applying the most recent editions of the standards indicated below.
In the case of references to ECMA Standards that are aligned with ISO/IEC International Standards, the number of the
appropriate ISO/IEC International Standard is given in brackets after the ECMA reference.
[1] ECMA-133: "Private Integrated Services Network (PISN) - Reference Configuration for PISN
Exchanges (PINX)", (International Standard ISO/IEC 11579-1).
[2] ECMA-143: "Private Integrated Services Network (PISN) - Circuit Mode Bearer Services - Inter-
Exchange Signalling Procedures and Protocol (QSIG-BC)", (International Standard
ISO/IEC 11572).
[3] ECMA-165: "Private Integrated Services Network (PISN) - Generic Functional Protocol for the
Support of Supplementary Services - Inter-Exchange Signalling Procedures and Protocol
(QSIG-GF)", (International Standard ISO/IEC 11582).
[4] ECMA-343: "Private Integrated Services Network (PISN) - Specification, Functional Model and
Information Flows - Make Call Request Supplementary Service (MCRSD)".
[5] ECMA-345: "Private Integrated Services Network (PISN) - Use of QSIG for Message Centre
Access (MCA) Profile Standard".
ETSI
---------------------- Page: 9 ----------------------
SIST-TS ETSI/TS 102 257 V1.1.1:2005
8 ETSI TS 102 257 V1.1.1 (2003-08)
[6] ETSI ETS 300 387: "Private Telecommunication Network (PTN); Method for the specification of
basic and supplementary services".
[7] ITU-T Recommendation I.112: "Vocabulary of terms for ISDNs".
[8] ITU-T Recommendation I.210: "Principles of telecommunication services supported by an ISDN
and the means to describe them".
[9] ITU-T Recommendation Q.950: "Digital Subscriber Signalling System No. 1 (DSS1) -
Supplementary services protocols, structure and general principles".
[10] ITU-T Recommendation Z.100: "Specification and Description Language (SDL)".
4 Definitions
For the purposes of the present document, the following terms and definitions apply.
4.1 External definitions
The present document uses the following terms and definitions given in other documents apply:
Application Protocol Data Unit (APDU): See ECMA-165 [3].
call, basic call: See ECMA-165 [3].
Call Independent Signalling Connection (CISC): See ECMA-165 [3].
call-independent: See ECMA-165 [3].
gateway PINX: See ECMA-165 [3].
originating PINX: See ECMA-165 [3].
Priv
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
