ASTM D8501-23a
(Specification)Standard Classification System for and Basis for Specification for Unfilled Poly(Ether Ketone Ketone) (PEKK) Materials for Molding, Extrusion, Composites, Powder Coating and Additive Manufacturing
Standard Classification System for and Basis for Specification for Unfilled Poly(Ether Ketone Ketone) (PEKK) Materials for Molding, Extrusion, Composites, Powder Coating and Additive Manufacturing
SCOPE
1.1 This specification covers poly(ether ketone ketone) materials, commonly referred to as PEKK, which are suitable for molding, extrusion, composites, powder coating and additive manufacturing. Only materials in this Class 6-8 are covered by this specification. This classification system provides requirements for the use of regrind or reprocessed materials.
1.2 This specification covers thermoplastic resin materials supplied in pellet as well as powder form.
1.3 This specification applies only to PEKK copolymers, without any additional fillers or inorganic additives, alloys, or treatments for modification of attributes.
1.4 This classification system and subsequent line callout (specification) are intended to provide means of calling out poly(ether ketone ketone) materials used in the fabrication of end items or parts.
1.5 Poly(ether ketone ketone) (PEKK) is a member of the poly (aryl ether ketone) or PAEK polymer family. PEKK has a broad range of repeat unit combinations of Isophthaloyl and Terephthaloyl repeat units. This standard classifies the polymer options.
1.6 The values stated in SI units, as detailed in IEEE/ASTM S-10, are to be regarded as the standard. The values given in parentheses are for information only.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
Note 1: There is no known ISO equivalent to this standard.
Note 2: PEKK is a thermoplastic polymer. Testing conditions can affect the technical results. Specimens prepared by techniques different than prescribed in this specification can have properties that vary from the values specified.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
General Information
Relations
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: D8501 − 23a
Standard Classification System for and Basis for Specification
for
Unfilled Poly(Ether Ketone Ketone) (PEKK) Materials for
Molding, Extrusion, Composites, Powder Coating and
1
Additive Manufacturing
This standard is issued under the fixed designation D8501; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
NOTE 2—PEKK is a thermoplastic polymer. Testing conditions can
1. Scope*
affect the technical results. Specimens prepared by techniques different
1.1 This specification covers poly(ether ketone ketone)
than prescribed in this specification can have properties that vary from the
materials, commonly referred to as PEKK, which are suitable values specified.
for molding, extrusion, composites, powder coating and addi-
1.8 This international standard was developed in accor-
tive manufacturing. Only materials in this Class 6-8 are
dance with internationally recognized principles on standard-
covered by this specification. This classification system pro-
ization established in the Decision on Principles for the
vides requirements for the use of regrind or reprocessed
Development of International Standards, Guides and Recom-
materials.
mendations issued by the World Trade Organization Technical
Barriers to Trade (TBT) Committee.
1.2 This specification covers thermoplastic resin materials
supplied in pellet as well as powder form.
2. Referenced Documents
1.3 This specification applies only to PEKK copolymers,
2
2.1 ASTM Standards:
without any additional fillers or inorganic additives, alloys, or
D150 Test Methods for AC Loss Characteristics and Permit-
treatments for modification of attributes.
tivity (Dielectric Constant) of Solid Electrical Insulation
1.4 This classification system and subsequent line callout
D257 Test Methods for DC Resistance or Conductance of
(specification) are intended to provide means of calling out
Insulating Materials
poly(ether ketone ketone) materials used in the fabrication of
D618 Practice for Conditioning Plastics for Testing
end items or parts.
D638 Test Method for Tensile Properties of Plastics
1.5 Poly(ether ketone ketone) (PEKK) is a member of the
D792 Test Methods for Density and Specific Gravity (Rela-
poly (aryl ether ketone) or PAEK polymer family. PEKK has a
tive Density) of Plastics by Displacement
broad range of repeat unit combinations of Isophthaloyl and
D883 Terminology Relating to Plastics
Terephthaloyl repeat units. This standard classifies the polymer
D1238 Test Method for Melt Flow Rates of Thermoplastics
options.
by Extrusion Plastometer
D1600 Terminology for Abbreviated Terms Relating to Plas-
1.6 The values stated in SI units, as detailed in IEEE/ASTM
tics
S-10, are to be regarded as the standard. The values given in
D2863 Test Method for Measuring the Minimum Oxygen
parentheses are for information only.
Concentration to Support Candle-Like Combustion of
1.7 This standard does not purport to address all of the
Plastics (Oxygen Index)
safety concerns, if any, associated with its use. It is the
D3418 Test Method for Transition Temperatures and Enthal-
responsibility of the user of this standard to establish appro-
pies of Fusion and Crystallization of Polymers by Differ-
priate safety, health, and environmental practices and deter-
ential Scanning Calorimetry
mine the applicability of regulatory limitations prior to use.
D3892 Practice for Packaging/Packing of Plastics
NOTE 1—There is no known ISO equivalent to this standard.
D4000 Classification System for Specifying Plastic Materi-
als
1
This test method is under the jurisdiction of ASTM Committee D20 on Plastics
and is the direct responsibility of Subcommittee D20.15 on Thermoplastic Materi-
2
als. For referenced ASTM standards, visit the ASTM website, www.astm.org, or
Current edition approved Nov. 1, 2023. Published November 2023. Originally contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM
approved in 2015. Last previous edition approved in 2023 as D8501 – 23. DOI: Standards volume information, refer to the standard’s Document Summary page on
10.1520/D8501-23A. the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
D8501 − 23a
D6247 Test Method for Determination of Elemental Content 3.2.4 regrind (plastic), n—a pro
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D8501 − 23 D8501 − 23a
Standard Classification System for and Basis for Specification
for
Unfilled Poly(Ether Ketone Ketone) (PEKK) Materials for
Molding, Extrusion, Composites, Powder Coating and
1
Additive Manufacturing
This standard is issued under the fixed designation D8501; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope Scope*
1.1 This specification covers poly(ether ketone ketone) materials, commonly referred to as PEKK, which are suitable for molding,
extrusion, composites, powder coating and additive manufacturing. Only materials in this Class 6-8 are covered by this
specification. This classification system provides requirements for the use of regrind or reprocessed materials.
1.2 This specification covers thermoplastic resin materials supplied in pellet as well as powder form.
1.3 This specification applies only to PEKK copolymers, without any additional fillers or inorganic additives, alloys, or treatments
for modification of attributes.
1.4 This classification system and subsequent line callout (specification) are intended to provide means of calling out poly(ether
ketone ketone) materials used in the fabrication of end items or parts.
1.5 Poly(ether ketone ketone) (PEKK) is a member of the poly (aryl ether ketone) or PAEK polymer family. PEKK has a broad
range of repeat unit combinations of Isophthaloyl and Terephthaloyl repeat units. This standard classifies the polymer options.
1.6 The values stated in SI units, as detailed in IEEE/ASTM S-10, are to be regarded as the standard. The values given in
parentheses are for information only.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
NOTE 1—There is no known ISO equivalent to this standard.
NOTE 2—PEKK is a thermoplastic polymer. Testing conditions can affect the technical results. Specimens prepared by techniques different than prescribed
in this specification can have properties that vary from the values specified.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
1
This test method is under the jurisdiction of ASTM Committee D20 on Plastics and is the direct responsibility of Subcommittee D20.15 on Thermoplastic Materials.
Current edition approved Aug. 1, 2023Nov. 1, 2023. Published August 2023November 2023. Originally approved in 2015. Last previous edition approved in 2023 as
D8501 – 23. DOI: 10.1520/D8501-23.10.1520/D8501-23A.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
D8501 − 23a
2. Referenced Documents
2
2.1 ASTM Standards:
D150 Test Methods for AC Loss Characteristics and Permittivity (Dielectric Constant) of Solid Electrical Insulation
D257 Test Methods for DC Resistance or Conductance of Insulating Materials
D618 Practice for Conditioning Plastics for Testing
D638 Test Method for Tensile Properties of Plastics
D792 Test Methods for Density and Specific Gravity (Relative Density) of Plastics by Displacement
D883 Terminology Relating to Plastics
D1238 Test Method for Melt Flow Rates of Thermoplastics by Extrusion Plastometer
D1600 Terminology for Abbreviated Terms Relating to Plastics
D2863 Test Method for Measuring the Minimum Oxygen Concentration to Support Candle-Like Combustion of Plastics
(Oxygen Index)
D3418 Test Method for Transition Temperatures and Enthalpies of Fusion and Crystallization of Polymers by Differential
Scanning Calorimetry
D3892 Practice for Packaging/Packing of Plastics
D4000 Classification System for Specifying Plastic Materials
D6247 Test Method for Determination of Elemental Content of Polyolefins by Wavelength Dispersive X-ray Fluorescence
Spectrometry
D8371 Test Method for Trace Metal Content Analysis in Ca
...
