EN ISO 2338:1997

Parallel pins, of unhardened steel and austenitic stainless steel (ISO 2338:1997)

Zylinderstifte aus ungehärtetem Stahl und austenitischem nichtrostendem Stahl (ISO 2338:1997)

Diese Internationale Norm beschreibt die Eigenschaften von Zylinderstiften aus ungehärtetem Stahl und austenitischem nichtrostendem Stahl mit metrischen Abmessungen und Nenndurchmessern d von 0,6 bis einschließlich 50 mm.

Goupilles cylindriques en acier non trempé et en acier inoxydable austénitique (ISO 2338:1997)

La présente Norme internationale prescrit les caractéristiques des goupilles cylindriques en acier non trempé et en acier inoxydable austénitique de diamètre nominal, d, de 0,6 mm à 50 mm inclus.

Valjasti zatiči iz nekaljenega ali avstenitnega nerjavnega jekla (ISO 2338:1997)

General Information

• Status: Published
• Publication Date: 31-Oct-1997
• ICS: 21.060.50 - Pins, nails
• Technical Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Drafting Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 04-Feb-2008
• Completion Date: 04-Feb-2008
• Ref Project: SIST EN ISO 2338:2001 - Parallel pins, of unhardened steel and austenitic stainless steel (ISO 2338:1997)

Relations

• Replaces: EN 22338:1992 - Parallel pins, unhardened (ISO 2338:1986)
• Effective Date: 22-Dec-2008

Overview

EN ISO 2338:1997 (ISO 2338:1997) specifies the characteristics, dimensions and basic requirements for parallel pins (cylindrical pins) made of unhardened steel and austenitic stainless steel. The standard covers nominal diameters from 0.6 mm to 50 mm and a commercially used series of nominal lengths. It is a product standard widely used by designers, manufacturers and purchasers of fasteners and locating elements.

Key topics and technical requirements

• Scope and sizes
  • Nominal diameters d = 0.6 mm to 50 mm inclusive.
  • Nominal lengths provided in a standard series (table of lengths up to and beyond 200 mm; above 200 mm lengths in 20 mm steps).
• Tolerances and fit
  • Typical tolerance classes referenced: m6 and h8. Dimensional tolerances are specified in the standard’s tables.
  • All dimensional tolerances apply prior to plating or coating.
• Material and hardness
  • Unhardened steel (St): hardness range 125 HV30 to 245 HV30.
  • Austenitic stainless steel (grade A1): hardness range 210 HV30 to 280 HV30, with mechanical properties referenced to ISO 3506-1.
• Surface finish and coatings
  • Pins are normally supplied plain (natural finish) or, by agreement, with coatings.
  • Preferred coatings for steel pins: black oxide, phosphate, or zinc plating with chromate conversion (see ISO 9717 and ISO 4042).
  • Surface roughness targets: for m6 R < 0.8 µm, for h8 R < 1.6 µm.
• Workmanship and acceptance
  • Pins must be free of irregularities and burrs.
  • Acceptance inspection procedures follow ISO 3269.

Applications and users

• Practical uses:
  • Locating, aligning and securing machine components, jigs and fixtures.
  • Assembly and repair work where precision dowel or locating pins are required.
• Primary users:
  • Mechanical designers and engineers specifying fasteners and locating elements.
  • Fastener manufacturers, quality inspectors and purchasing/procurement teams.
  • Maintenance and assembly technicians in industries such as general machinery, tooling, automotive and other manufacturing sectors.

Related standards

• ISO 3269 - Fasteners: Acceptance inspection
• ISO 3506-1 - Mechanical properties of corrosion-resistant stainless steel fasteners
• ISO 4042 - Fasteners: Electroplated coatings (revision referenced)
• ISO 9717 - Phosphate conversion coatings for metals

Example designation formats in the standard:

• Parallel pin ISO 2338 – 6 m6 × 30 – St (unhardened steel)
• Parallel pin ISO 2338 – 6 m6 × 30 – A1 (austenitic stainless steel)

Keywords: EN ISO 2338, ISO 2338:1997, parallel pins, unhardened steel, austenitic stainless steel, fasteners standard, pin dimensions, tolerance m6 h8, surface finish, mechanical design.

Standards Content (Sample)

SLOVENSKI STANDARD
01-julij-2001
1DGRPHãþD
SIST EN 22338:1996
9DOMDVWL]DWLþLL]QHNDOMHQHJDDOLDYVWHQLWQHJDQHUMDYQHJDMHNOD,62
Parallel pins, of unhardened steel and austenitic stainless steel (ISO 2338:1997)
Zylinderstifte aus ungehärtetem Stahl und austenitischem nichtrostendem Stahl (ISO
2338:1997)
Goupilles cylindriques en acier non trempé et en acier inoxydable austénitique (ISO
2338:1997)
Ta slovenski standard je istoveten z: EN ISO 2338:1997
ICS:
21.060.50 =DWLþLåHEOML Pins, nails
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL ISO
STANDARD 2338
Second edition
1997-11-01
Parallel pins, of unhardened steel and
austenitic stainless steel
Goupilles cylindriques en acier non trempé et en acier inoxydable
austénitique
A
Reference number
ISO 2338:1997(E)
ISO 2338:1997(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide
federation of national standards bodies (ISO member bodies). The work of
preparing International Standards is normally carried out through ISO
technical committees. Each member body interested in a subject for which
a technical committee has been established has the right to be represented
on that committee. International organizations, governmental and non-
governmental, in liaison with ISO, also take part in the work. ISO
collaborates closely with the International Electrotechnical Commission
(IEC) on all matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are
circulated to the member bodies for voting. Publication as an International
Standard requires approval by at least 75 % of the member bodies casting
a vote.
International Standard ISO 2338 was prepared by Technical Committee
ISO/TC 2, Fasteners.
This second edition cancels and replaces the first edition (ISO 2338:1986),
which has been technically revised.
©  ISO 1997
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced
or utilized in any form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from the publisher.
International Organization for Standardization
Case postale 56 • CH-1211 Genève 20 • Switzerland
Internet [e-mail]
X.400 c=ch; a=400net; p=iso; o=isocs; s=central
Printed in Switzerland
ii
©
INTERNATIONAL STANDARD  ISO ISO 2338:1997(E)
Parallel pins, of unhardened steel and austenitic
stainless steel
1 Scope
This International Standard specifies the characteristics of parallel pins of unhardened steel and austenitic
stainless steel, with nominal diameters d from 0,6 mm to 50 mm inclusive.
2 Normative references
The following standards contain provisions which, through reference in this text, constitute provisions of this
International Standard. At the time of publication, the editions indicated were valid. All standards are subject
to
...
