EN ISO 15984:2002

Open end blind rivets with break pull mandrel and countersunk head - A2/A2 (ISO 15984:2002)

ISO 15984 specifies dimensional and mechanical characteristics and application data for open end blind rivets with break pull mandrel and countersunk head, with an austenitic stainless steel body (A2) and an austenitic stainless steel mandrel (A2) and with nominal diameters from 3 mm up to and including 5 mm.

Offene Blindniete mit Sollbruchdorn und Senkkopf - A2/A2 (ISO 15984:2002)

Diese Internationale Norm legt Maße und mechanische Eigenschaften sowie Anwendungsdaten für offene Blindniete mit Sollbruchdorn und Senkkopf, mit einer Niethülse aus nichtrostendem austenitischem Stahl (A2) und einem Nietdorn aus nichtrostendem austenitischen Stahl (A2) und mit Nenndurchmessern, d, von 3 mm bis 5 mm fest.

Rivets aveugles à Rivets aveugles à rupture de tige à corps ouvert, à tête fraisée - A2/A2 (ISO 15984:2002)rupture de tige à corps ouvert, à tête fraisée - A2/A2 (ISO 15984:2002)

L'ISO 15984:2002 spécifie les caractéristiques dimensionnelles et mécaniques ainsi que les données d'application pour les rivets aveugles à rupture de tige à corps ouvert, à tête fraisée, avec un corps en acier inoxydable austénitique (A2) et une tige en acier inoxydable austénitique (A2), de diamètre nominal compris entre 3 mm et 5 mm inclus.

Slepe votle kovice z zarezanim zakovnim trnom in ugrezno glavo - A2/A2 (ISO 15984:2002)

General Information

• Status: Published
• Publication Date: 31-Oct-2002
• ICS: 21.060.40 - Rivets
• Technical Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Drafting Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 04-Feb-2008
• Completion Date: 04-Feb-2008
• Ref Project: SIST EN ISO 15984:2003 - Open end blind rivets with break pull mandrel and countersunk head - A2/A2 (ISO 15984:2002)

Overview

EN ISO 15984:2002 (ISO 15984:2002) specifies dimensional, mechanical and application data for open end blind rivets with break pull mandrel and countersunk head, manufactured from austenitic stainless steel A2/A2. The standard covers nominal diameters from 3 mm to 5 mm and defines geometry, material, mechanical properties and acceptance/testing references for these blind fasteners.

Key topics and requirements

• Scope and materials
  • Rivet body and mandrel both A2 (austenitic stainless steel) in accordance with ISO 3506‑1.
  • Plain (natural) finish required.
• Dimensions and tolerances
  • Nominal diameters: 3; 3.2; 4; 4.8; 5 mm.
  • Detailed head, shank and length dimensions plus recommended grip ranges are provided (see Table 1 and Figure 1 in the standard).
  • Clearance hole diameters (h1) are specified to avoid assembly problems and strength reductions.
• Mechanical performance
  • Minimum shear and tensile loads and maximum mandrel break loads are specified and tested per ISO 14589. Examples:
    • 3 mm: shear ≥ 1 800 N, tensile ≥ 2 200 N, mandrel break ≤ 4 100 N
    • 4 mm: shear ≥ 2 700 N, tensile ≥ 3 500 N, mandrel break ≤ 6 500 N
    • 5 mm: shear ≥ 4 700 N, tensile ≥ 5 800 N, mandrel break ≤ 9 000 N
  • Mandrel push‑out resistance must exceed 10 N.
  • Mandrel head retention test loads are specified (e.g., 35 N for 3/3.2 mm, 40 N for 4 mm, 45 N for 4.8/5 mm).
• Quality and acceptance
  • Workmanship rules: burr‑free, well‑formed heads/shanks, no cracking after setting (5× magnification).
  • Acceptance inspection defaults to ISO 3269 unless otherwise agreed.
• Designation
  • Example: Blind rivet ISO 15984 - 4 ×××× 12 - A2/A2

Applications and who uses it

• Typical use: blind fastening where only one side of an assembly is accessible (sheet metal assemblies, enclosures, HVAC, building façade panels, general manufacturing).
• Benefits of the A2/A2 combination: corrosion resistance and compatibility where stainless fasteners are needed and a countersunk head for flush finish is required.
• Primary users:
  • Fastener manufacturers and product designers specifying rivet geometry and performance
  • Mechanical and structural engineers specifying blind fasteners for assemblies
  • Quality inspectors and test laboratories performing acceptance testing
  • Procurement teams ensuring conformity to EN ISO 15984 for stainless steel countersunk blind rivets

Related standards

• ISO 14588 - Blind rivets: terminology and definitions
• ISO 14589 - Blind rivets: mechanical testing
• ISO 3506‑1 - Mechanical properties of corrosion‑resistant stainless‑steel fasteners
• ISO 3269 - Fasteners: acceptance inspection

Keywords: EN ISO 15984, ISO 15984:2002, open end blind rivets, A2/A2, countersunk head, break pull mandrel, stainless steel rivets, blind fastening, mechanical properties, clearance hole.

Standards Content (Sample)

SLOVENSKI STANDARD
01-julij-2003
Slepe votle kovice z zarezanim zakovnim trnom in ugrezno glavo - A2/A2 (ISO
15984:2002)
Open end blind rivets with break pull mandrel and countersunk head - A2/A2 (ISO
15984:2002)
Offene Blindniete mit Sollbruchdorn und Senkkopf - A2/A2 (ISO 15984:2002)
Rivets aveugles a Rivets aveugles a rupture de tige a corps ouvert, a tete fraisée - A2/A2
(ISO 15984:2002)rupture de tige a corps ouvert, a tete fraisée - A2/A2 (ISO 15984:2002)
Ta slovenski standard je istoveten z: EN ISO 15984:2002
ICS:
21.060.40 Kovice Rivets
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL ISO
STANDARD 15984
First edition
2002-11-01
Open end blind rivets with break pull
mandrel and countersunk head — A2/A2
Rivets aveugles à rupture de tige à corps ouvert, à tête fraisée — A2/A2

Reference number
ISO 15984:2002(E)
©
ISO 2002
ISO 15984:2002(E)
PDF disclaimer
This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not
be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this
file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this
area.
Adobe is a trademark of Adobe Systems Incorporated.
Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters
were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event
that a problem relating to it is found, please inform the Central Secretariat at the address given below.

©  ISO 2002
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic
or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body
in the country of the requester.
ISO copyright office
Case postale 56 • CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 749 09 47
E-mail [e-mail]
Web www.iso.ch
Printed in Switzerland
ii © ISO 2002 – All rights reserved

ISO 15984:2002(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies (ISO
member bodies). The work of preparing International Standards is normally carried out through ISO technical
committees. Each member body interested in a subject for which a technical committee has been established has
the right to be represented on that committee. International organizations, governmental and non-governmental, in
liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical
Commission (IEC) on all matters of electrotechnical standardization.
International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 3.
The main task of technical committees is to prepare International Standards. Draft International Standards adopted
by the technical committees are circulated to the member bodies for voting. Publication as an International
Standard requires approval by at least 75 % of the member bodies casting a vote.
Attention is drawn to the possibility that some of the elements of this International Standard may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights.
ISO 15984 was prepared by Technical Committee ISO/TC 2, Fasteners.
Annex A of this International Standard is for information only.
INTERNATIONAL STANDARD ISO 15984:2002(E)

Open end blind rivets with break pull mandrel and countersunk
head — A2/A2
1 Scope
This International Standard specifies dimensional and mechanical characteristics and application data for open end
blind rivets with break pull mandrel and countersunk head, with an austenitic stainless steel body (A2) and an
austenitic stainless steel mandrel (A2) and with nominal diameters, d, from 3 mm up to and including 5 mm.
2 Normative references
The following normative documents contain provisions which, through reference in this text, constitute provisions of
this International Standard. For dated references, subsequent amendments to, or revisions of, any of these
publications do not apply. However, parties to agreements based on this International Standard are encouraged to
investigate the possibility of applying the most recent editions of the normative documents indicated below. For
undated references, the latest edition of the normative document referred to applies. Members of ISO and IEC
maintain registers of currently valid International Standards.
ISO 3269:2000, Fasteners — Acceptance inspection
ISO 3506-1:1997, Mechanical properties of corrosion-resista
...
