ETSI EN 302 998-2 V1.1.1 (2010-07) - Electromagnetic compatibility and Radio spectrum Matters (ERM); Transmitting equipment for terrestrial mobile TV to provide multimedia multicast service; Part 2: Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive, Test Arrangements for transmitters utilizing OFDM technology
English language
15 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.YQRVWQHJDElectromagnetic compatibility and Radio spectrum Matters (ERM) - Transmitting equipment for terrestrial mobile TV to provide multimedia multicast service - Part 2: Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive, Test Arrangements for transmitters utilizing OFDM technology33.100.01Elektromagnetna združljivost na splošnoElectromagnetic compatibility in general33.060.20Sprejemna in oddajna opremaReceiving and transmitting equipmentICS:Ta slovenski standard je istoveten z:EN 302 998-2 Version 1.1.1SIST EN 302 998-2 V1.1.1:2011en01-julij-2011SIST EN 302 998-2 V1.1.1:2011SLOVENSKI
STANDARD



SIST EN 302 998-2 V1.1.1:2011



ETSI EN 302 998-2 V1.1.1 (2011-05)Harmonized European Standard Electromagnetic compatibilityand Radio spectrum Matters (ERM);Transmitting equipment for terrestrial mobile TVto provide multimedia multicast service;Part 2: Harmonized EN covering the essential requirementsof article 3.2 of the R&TTE Directive,Test Arrangements for transmitters utilizing OFDM technology SIST EN 302 998-2 V1.1.1:2011



ETSI ETSI EN 302 998-2 V1.1.1 (2011-05) 2
Reference DEN/ERM-TG17WG1-004-2 Keywords mobile, multimedia, TV ETSI 650 Route des Lucioles F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00
Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C Association à but non lucratif enregistrée à la Sous-Préfecture de Grasse (06) N° 7803/88
Important notice Individual copies of the present document can be downloaded from: http://www.etsi.org The present document may be made available in more than one electronic version or in print. In any case of existing or perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF). In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive within ETSI Secretariat. Users of the present document should be aware that the document may be subject to revision or change of status. Information on the current status of this and other ETSI documents is available at http://portal.etsi.org/tb/status/status.asp If you find errors in the present document, please send your comment to one of the following services: http://portal.etsi.org/chaircor/ETSI_support.asp Copyright Notification No part may be reproduced except as authorized by written permission. The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011. All rights reserved.
DECTTM, PLUGTESTSTM, UMTSTM, TIPHONTM, the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members. 3GPPTM is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners. LTE™ is a Trade Mark of ETSI currently being registered for the benefit of its Members and of the 3GPP Organizational Partners. GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association. SIST EN 302 998-2 V1.1.1:2011



ETSI ETSI EN 302 998-2 V1.1.1 (2011-05) 3 Contents Intellectual Property Rights . 4 Foreword . 4 Introduction . 4 1 Scope . 5 2 References . 5 2.1 Normative references . 5 2.2 Informative references . 5 3 Definitions, symbols and abbreviations . 6 3.1 Definitions . 6 3.2 Symbols . 7 3.3 Abbreviations . 7 4 General measuring arrangements . 7 4.1 Test conditions . 7 4.1.1 Test frequency range . 7 4.1.2 Test modulating signal . 8 4.2 Test arrangement for measurement of spurious emissions . 8 4.3 Test arrangement for measurement of out-of-band emissions . 9 4.4 Test arrangement for measurement of cabinet radiation . 9 Annex A (normative): HS Requirements and conformance Test specifications Table (HS-RTT) . 11 Annex B (informative): The EN title in the official languages . 13 Annex C (informative): Bibliography . 14 History . 15
SIST EN 302 998-2 V1.1.1:2011



ETSI ETSI EN 302 998-2 V1.1.1 (2011-05) 4 Intellectual Property Rights IPRs essential or potentially essential to the present document may have been declared to ETSI. The information pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web server (http://webapp.etsi.org/IPR/home.asp). Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web server) which are, or may be, or may become, essential to the present document. Foreword This Harmonized European Standard (EN) has been produced by ETSI Technical Committee Electromagnetic compatibility and Radio spectrum Matters (ERM). The present document has been produced by ETSI in response to a mandate from the European Commission issued under Council Directive 98/34/EC [i.1] (as amended) laying down a procedure for the provision of information in the field of technical standards and regulations. The title and reference to the present document are intended to included in the publication in the Official Journal of the European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [1]. See article 5.1 of Directive 1999/5/EC [1] for information on presumption of conformity and Harmonised Standards or parts thereof the references of which have been published in the Official Journal of the European Union. The requirements relevant to Directive 1999/5/EC [1] are summarised in annex A. The present document is part 2 of a multi-part deliverable. Full details of the entire series can be found in part 1 [2].
National transposition dates Date of adoption of this EN: 20 May 2011 Date of latest announcement of this EN (doa): 31 August 2011 Date of latest publication of new National Standard or endorsement of this EN (dop/e):
29 February 2012 Date of withdrawal of any conflicting National Standard (dow): 28 February 2013
Introduction The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [1]. The modular structure is shown in EG 201 399 [i.2]. SIST EN 302 998-2 V1.1.1:2011



ETSI ETSI EN 302 998-2 V1.1.1 (2011-05) 5 1 Scope The present document applies to the following radio equipment types: 1) Transmitting equipment for terrestrial mobile TV to provide multimedia multicast service, with 7 MHz and 8 MHz RF channel bandwidths, operating in the CEPT or national frequency bands appropriate for this service. The present document is intended to cover the provisions of Directive 1999/5/EC [1] (R&TTE Directive), Article 3.2, which states that "…. radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference". In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive [1] may apply to equipment within the scope of the present document. NOTE: A list of such ENs is included on the web site http://www.newapproach.org. 2 References References are either specific (identified by date of publication and/or edition number or version number) or non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the reference document (including any amendments) applies. Referenced documents which are not found to be publicly available in the expected location might be found at http://docbox.etsi.org/Reference. NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee their long term validity. 2.1 Normative references The following referenced documents are necessary for the application of the present document. [1] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity (R&TTE Directive). [2] ETSI EN 302 998-1 (V1.1.1) "Electromagnetic compatibility and Radio spectrum Matters (ERM); Transmitting equipment for terrestrial mobile TV to provide multimedia multicast service; Part 1: Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive, Common Requirements". [3] CENELEC EN 55016-1-1 (2007 + A1:2007 + A2:2008): "Specification for radio disturbance and immunity measuring apparatus and methods - Part 1-1: Radio disturbance and immunity measuring apparatus - Measuring apparatus". [4] CISPR 16-2-3 Ed. 2.0 b:2006: "Specification for radio disturbance and immunity measuring apparatus and methods - Part 2-3: Methods of measurement of disturbances and immunity - Radiated disturbance measurements". 2.2 Informative references The following referenced documents are not necessary for the application of the present document but they assist the user with regard to a particular subject area. [i.1] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a procedure for the provision of information in the field of technical standards and regulations. SIST EN 302 998-2 V1.1.1:2011



ETSI ETSI EN 302 998-2 V1.1.1 (2011-05) 6 [i.2] ETSI EG 201 399 (V2.1.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM); A guide to the production of candidate Harmonized Standards for application under the R&TTE Directive".
3 Definitions, symbols and abbreviations 3.1 Definitions For the purposes of the present document, the following terms and definitions apply: antenna port: port of an apparatus which is designed, in normal operation, to be connected to an antenna using coaxial cable cabinet radiation: emissions from the equipment, radiated from the enclosure port, other than those present at the antenna port carrier power: average power supplied to the antenna port by a transmitter during one radio frequency cycle taken under the condition of no modulation class of emission: set of characteristics of an emission, designated by standard symbols, e.g. type of modulation of the main carrier, modulating signal, type of information to be transmitted, and also, if appropriate, any additional signal characteristics dBc: decibels relative to the unmodulated carrier power of the emission NOTE: In the cases which do not have a carrier,
...

Draft ETSI EN 302 998-2 V1.1.1 (2010-07)
Harmonized European Standard (Telecommunications series)

Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Transmitting equipment for terrestrial mobile TV
to provide multimedia multicast service;
Part 2: Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive,
Test Arrangements for transmitters utilizing OFDM technology

---------------------- Page: 1 ----------------------
2 Draft ETSI EN 302 998-2 V1.1.1 (2010-07)



Reference
DEN/ERM-TG17WG1-004-2
Keywords
mobile, multimedia, TV
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: +33 4 92 94 42 00  Fax: +33 4 93 65 47 16

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2010.
All rights reserved.

TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI

---------------------- Page: 2 ----------------------
3 Draft ETSI EN 302 998-2 V1.1.1 (2010-07)

Contents
Intellectual Property Rights . 4
Foreword . 4
Introduction . 4
1 Scope . 5
2 References . 5
2.1 Normative references . 5
2.2 Informative references . 5
3 Definitions, symbols and abbreviations . 6
3.1 Definitions . 6
3.2 Symbols . 7
3.3 Abbreviations . 7
4 General measuring arrangements . 7
4.1 Test conditions . 7
4.1.1 Test frequency range . 7
4.1.2 Test modulating signal . 8
4.2 Test arrangement for measurement of spurious emissions . 8
4.3 Test arrangement for measurement of out-of-band emissions . 9
4.4 Test arrangement for measurement of cabinet radiation . 9
Annex A (normative): HS Requirements and conformance Test specifications Table (HS-
RTT) . 11
Annex B (informative): The EN title in the official languages . 13
Annex C (informative): Bibliography . 14
History . 15

ETSI

---------------------- Page: 3 ----------------------
4 Draft ETSI EN 302 998-2 V1.1.1 (2010-07)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM), and is now submitted for the Public Enquiry phase
of the ETSI standards Two-step Approval Procedure.
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC [i.1] (as amended) laying down a procedure for the provision of information in the
field of technical standards and regulations.
The present document is intended to become a Harmonized Standard, the reference of which will be published in the
Official Journal of the European Communities referencing the Directive 1999/5/EC [1] of the European Parliament and
of the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual
recognition of their conformity ("the R&TTE Directive").
The requirements relevant to Directive 1999/5/EC [1] are summarised in annex A.
The present document is part 2 of a multi-part deliverable. Full details of the entire series can be found in part 1 [2].

Proposed national transposition dates
Date of latest announcement of this EN (doa): 3 months after ETSI publication
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 6 months after doa
Date of withdrawal of any conflicting National Standard (dow): 18 months after doa

Introduction
The present document is part of a multi-part deliverable developed by ETSI and is designed to fit in a modular structure
to cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive. The modular
structure is shown in EG 201 399 [i.2].
ETSI

---------------------- Page: 4 ----------------------
5 Draft ETSI EN 302 998-2 V1.1.1 (2010-07)
1 Scope
The present document applies to the following radio equipment types:
1) Transmitting equipment for terrestrial mobile TV to provide multimedia multicast service, with 7 MHz and
8 MHz RF channel bandwidths, operating in the CEPT or national frequency bands appropriate for this
service.
The present document is intended to cover the provisions of Directive 1999/5/EC [1] (R&TTE Directive), Article 3.2,
which states that "…. radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [1] may apply to equipment within the scope of the present
document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org.
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity (R&TTE Directive).
[2] ETSI EN 302 998-1 (V1.1.1) "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Transmitting equipment for terrestrial mobile TV to provide multimedia multicast service; Part 1:
Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive,
Common Requirements".
[3] CENELEC EN 55016-1-1 (2007 + A1:2007 + A2:2008): "Specification for radio disturbance and
immunity measuring apparatus and methods - Part 1-1: Radio disturbance and immunity
measuring apparatus - Measuring apparatus".
[4] CISPR 16-2-3 Ed. 2.0 b:2006: "Specification for radio disturbance and immunity measuring
apparatus and methods - Part 2-3: Methods of measurement of disturbances and immunity -
Radiated disturbance measurements".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
ETSI

---------------------- Page: 5 ----------------------
6 Draft ETSI EN 302 998-2 V1.1.1 (2010-07)
[i.2] ETSI EG 201 399 (V2.1.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
A guide to the production of candidate Harmonized Standards for application under the R&TTE
Directive".
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
antenna port: port of an apparatus which is designed, in normal operation, to be connected to an antenna using coaxial
cable
cabinet radiation: emissions from the equipment, radiated from the enclosure port, other than those present at the
antenna port
carrier power: average power supplied to the antenna port by a transmitter during one radio frequency cycle taken
under the condition of no modulation
class of emission: set of characteristics of an emission, designated by standard symbols, e.g. type of modulation of the
main carrier, modulating signal, type of information to be transmitted, and also, if appropriate, any additional signal
characteristics
dBc: decibels relative to the unmodulated carrier power of the emission
NOTE: In the cases which do not have a carrier, for example in some digital modulation schemes where the
carrier is not accessible for measurement, the reference level equivalent to dBc is decibels relative to the
mean power P.
enclosure port: physical boundary of the apparatus through which electromagnetic fields may radiate or impinge
NOTE: In the case of integral antenna equipment, this port is inseparable from t
...

Questions, Comments and Discussion
