Ta dokument opredeljuje prizemni snopovni radijski sistem (TETRA), ki podpira govor in podatke (V+D). Določa radijski vmesnik, medsebojno delovanje med prizemnimi snopovnimi radijskimi sistemi in drugimi sistemi prek prehodov, vmesnik terminalske opreme na mobilni postaji, povezavo linijskih postaj z infrastrukturo, varnostne vidike prizemnih snopovnih radijskih omrežij, upravljavne storitve, ki jih ima na voljo operater, cilje učinkovitosti in dopolnilne storitve,
ki so na voljo poleg osnovnih in telekomunikacijskih storitev. Ta del opisuje varnostne sestavine govora in podatkov prizemnega snopovnega radia. Zagotavlja mehanizme za zaupnost krmilne signalizacije ter govora in podatkov uporabnika na radijskem vmesniku, mehanizme za preverjanje pristnosti in ključne mehanizme za upravljanje
radijskega vmesnika in medsistemskega vmesnika (ISI). Točka 4 opisuje mehanizme za preverjanje pristnosti in ključne mehanizme za upravljanje za radijski vmesnik prizemnega snopovnega radia. Naslednji storitvi preverjanja pristnosti za radijski vmesnik sta na podlagi analize groženj določeni v standardu ETR 086-3 [i.3]:
preverjanje pristnosti mobilne postaje (MS) z infrastrukturo prizemnega snopovnega radia;
preverjanje pristnosti infrastrukture prizemnega snopovnega radia z mobilno postajo.
Točka 5 opisuje mehanizme in protokole za omogočanje in onemogočanje opreme mobilnih postaj in naročnine uporabnika. Prizemni snopovni radio lahko omogoča možnost šifriranja radijskega vmesnika. Točka 6, kadar se uporablja, opisuje mehanizme zaupnosti s šifriranjem radijskega vmesnika, govor v vodovnem načinu, podatke v vodovnem načinu, paketne podatke in informacije o krmiljenju. Točka 6 opisuje mehanizme šifriranja in postopke mobilnosti. Vključuje tudi podroben opis protokola za nadzor šifriranja na radijskem vmesniku. Ta dokument ne obravnava podrobne obravnave napak protokola ali mehanizmov protokola, kadar prizemni snopovni radio deluje v degradiranem načinu. Ta vprašanja so specifična za posamezno izvedbo in zato ne spadajo na področje prizadevanj za standardizacijo prizemnega snopovnega radia. Podroben opis centra za preverjanje pristnosti ne spada v področje uporabe tega dokumenta.
