IEC 62271-101:2021

High-voltage switchgear and controlgear - Part 101: Synthetic testing

IEC 62271-101:2021 mainly applies to AC circuit-breakers within the scope of IEC 62271-100. It provides the general rules for testing AC circuit-breakers, for making and breaking capacities over the range of test duties described in 7.102 to 7.111 of IEC 62271-100:2021, by synthetic methods.
It has been proven that synthetic testing is an economical and technically correct way to test high-voltage AC circuit-breakers according to the requirements of IEC 62271-100 and that it is equivalent to direct testing.
The methods and techniques described are those in general use. The purpose of this document is to establish criteria for synthetic testing and for the proper evaluation of results. Such criteria will establish the validity of the test method without imposing restraints on innovation of test circuitry.
This third edition cancels and replaces the second edition published in 2012 and Amendment 1:2017. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the second edition:
a) alignment with the third edition of IEC 62271-100:2021;
b) update this document with the last methods and techniques used for synthetic tests.
The contents of the corrigendum of October 2021 have been included in this copy.

Appareillage à haute tension - Partie 101: Essais synthétiques

L’IEC 62271-101:2021 s’applique principalement aux disjoncteurs à courant alternatif définis dans le domaine d’application de l’IEC 62271-100. Elle donne les règles générales d’essais de ces disjoncteurs, pour les pouvoirs de fermeture et de coupure dans la plage des séquences d’essais décrites de 7.102 à 7.111 de l’IEC 62271-100:2021, à l'aide de méthodes d'essais synthétiques.
Il a été démontré que l'essai synthétique est un moyen économique et techniquement valable pour soumettre à l’essai les disjoncteurs à courant alternatif à haute tension selon les exigences de l’IEC 62271-100, et qu’il est équivalent à un essai direct.
Les méthodes et techniques décrites sont celles d’usage courant. L’objet du présent document est d'établir des critères pour les essais synthétiques et pour l'évaluation correcte des résultats. Ces critères établissent la validité de la méthode d'essai sans limiter l'invention de nouveaux circuits d'essais.
Cette troisième édition annule et remplace la deuxième édition parue en 2012 et l’Amendement 1:2017. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à la deuxième édition:
a) alignement sur la troisième édition de l’IEC 62271-100:2021;
b) mise à jour du présent document avec les méthodes et techniques récentes utilisées pour les essais synthétiques.
Le contenu du corrigendum d’octobre 2021 a été pris en considération dans cet exemplaire.

General Information

• Status: Published
• Publication Date: 26-Jul-2021
• ICS: 29.130.10 - High voltage switchgear and controlgear
• Technical Committee: SC 17A - Switching devices
• Drafting Committee: MT 28 - TC 17/SC 17A/MT 28
• Current Stage: PPUB - Publication issued
• Start Date: 20-Aug-2021
• Completion Date: 27-Jul-2021

Relations

• Corrected By: IEC 62271-101:2021/COR1:2021 - Corrigendum 1 - High-voltage switchgear and controlgear - Part 101: Synthetic testing
• Effective Date: 05-Sep-2023
• Revises: IEC 62271-101:2012 - High-voltage switchgear and controlgear - Part 101: Synthetic testing
• Effective Date: 05-Sep-2023
• Revises: IEC 62271-101:2012/AMD1:2017/COR1:2018 - Corrigendum 1 - Amendment 1 - High-voltage switchgear and controlgear - Part 101: Synthetic testing
• Effective Date: 05-Sep-2023
• Revises: IEC 62271-101:2012/AMD1:2017 - Amendment 1 - High-voltage switchgear and controlgear - Part 101: Synthetic testing
• Effective Date: 05-Sep-2023

Overview

IEC 62271-101:2021 is an international standard established by the International Electrotechnical Commission (IEC) that defines synthetic testing methods for high-voltage AC circuit-breakers. This standard specifically applies to AC circuit-breakers within the scope of IEC 62271-100 and outlines general rules for assessing making and breaking capacities using synthetic testing techniques. The third edition of this standard, published in 2021, supersedes previous versions and aligns with the latest IEC 62271-100 requirements.

Synthetic testing has become recognized as an economical and technically valid alternative to traditional direct testing, providing equivalent accuracy in evaluating high-voltage circuit-breakers. The standard establishes criteria for performing synthetic tests and proper evaluation of results, facilitating innovation in test circuitry without compromising test integrity.

Key Topics

• Synthetic Testing Principles
  IEC 62271-101 defines fundamental synthetic test methods, including current injection, voltage injection, and the duplicate circuit method. These techniques simulate the electrical conditions during circuit-breaker operation, such as short-circuit making and breaking duties, to verify performance without the need for full direct testing setups.

• Test Intervals and Circuit Components
  The standard breaks down the testing process into critical intervals-high-current, interaction, and high-voltage intervals-each requiring specific conditions to ensure realistic and reliable results.

• Three-Phase Synthetic Testing
  Procedures for three-phase circuit-breakers are detailed, addressing the synchronization and phase relationships necessary during synthetic testing to mimic real-world short-circuit conditions.

• Type Tests and Test Series
  IEC 62271-101 covers requirements for type testing of circuit-breakers including demonstration of arcing times, terminal fault tests, short-line fault tests, out-of-phase making and breaking, and capacitive current tests, all performed using synthetic methods.

• Calculation and Correction Methods
  Annexes provide normative guidance on correcting transient recovery voltages (TRV), di/dt values, and tolerances on test quantities to ensure accurate measurement and valid comparisons with direct testing.

• Advanced Techniques and Circuit Examples
  Informative annexes supply detailed examples, including synthetic test circuits for metal-enclosed and dead tank circuit-breakers, techniques to prolong arcing, and methods specific to circuit-breakers equipped with opening resistors.

Applications

• High-Voltage Circuit-Breaker Testing
  Useful for manufacturers, testing laboratories, and utilities, IEC 62271-101 facilitates economically efficient synthetic tests that validate the making and breaking abilities of AC high-voltage circuit-breakers across prescribed test duties.

• Design Validation and Quality Assurance
  The standard’s defined synthetic test methods support comprehensive type tests critical for design validation, product certification, and ensuring compliance with IEC 62271-100 specifications.

• Innovation in Test Circuitry
  By establishing performance criteria without limiting innovation, the standard encourages development of advanced synthetic test circuits and methodologies to improve testing effectiveness and reduce costs.

• Maintenance and Diagnostics
  Synthetic testing enables periodic assessment and fault analysis of installed circuit-breakers, helping utilities maintain network safety and reliability without the logistics of full-scale direct testing.

Related Standards

• IEC 62271-100
  This is the primary standard covering high-voltage AC circuit-breakers, defining ratings, performance, and test duties. IEC 62271-101 supplements it by specifying synthetic testing methods for fulfilling these test duties.

• IEC 62271 Series
  Other parts of the IEC 62271 series address different aspects of high-voltage switchgear and controlgear, such as insulation requirements, measurement techniques, and product specifications.

• IEC 60947
  Although focused on low-voltage switchgear, IEC 60947 standards provide foundational testing concepts that inform high-voltage equipment testing practices.

• Electropedia and IEC Vocabulary (IEV)
  For terminology and precise definitions related to electrotechnical testing, refer to IEC's Electropedia, which complements IEC 62271-101 by standardizing technical language.

---

Keywords: IEC 62271-101, synthetic testing, high-voltage switchgear, AC circuit-breakers, making capacity tests, breaking capacity tests, transient recovery voltage (TRV), electrical test methods, high-voltage circuit-breaker testing, IEC standards, synthetic test circuits, type testing, electrical equipment safety.
