IEC 60512-28-100:2019

Connectors for electrical and electronic equipment - Tests and measurements - Part 28-100: Signal integrity tests up to 2 000 MHz - Tests 28a to 28g

IEC 60512-28-100:2019 specifies the test methods for signal integrity and transmission performance for connectors specified in respective parts of IEC 60603-7, IEC 61076-1, IEC 61076-2, and IEC 61076-3 standards for connecting hardware applications up to 2 000 MHz. It is also suitable for testing lower frequency connectors, however, the test methodology specified in the detail specification for any given connector remains the reference conformance test for that connector. The above list of connector series of standards does not preclude referencing this document in other connector manufacturer’s specifications or published standards. Test procedures provided herein are:
- insertion loss, test 28a;
- return loss, test 28b;
- near-end crosstalk (NEXT) test 28c;
- far-end crosstalk (FEXT), test 28d;
- transverse conversion loss (TCL), test 28f;
- transverse conversion transfer loss (TCTL), test 28g.
Other test procedures referenced herein are:
- transfer impedance (ZT), see IEC 60512-26-100, test 26e.
- for coupling attenuation (aC), see IEC 62153 4 12.
This second edition cancels and replaces the first edition, issued in 2013, and constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- The title is revised from 1 000 MHz to 2 000 MHz to reflect the range of frequencies which may be tested.
- All tables and requirements have been revised up to 2 000 MHz.
Key words: Connectors, Signal Integrity Tests

Connecteurs pour équipements électriques et électroniques - Essais et mesures - Partie 28-100: Essais d’intégrité des signaux jusqu’à 2 000 MHz - Essais 28a à 28g

L'IEC 60512-28-100:2019 spécifie les méthodes d’essai d’intégrité des signaux et de qualité de transmission pour des connecteurs spécifiés dans les parties respectives des normes IEC 60603-7, IEC 61076-1, IEC 61076-2 et IEC 61076-3 pour des applications de matériel de connexion jusqu’à 2 000 MHz. Elle s’applique également aux essais de connecteurs de fréquences inférieures, mais la méthodologie d’essai stipulée dans la spécification particulière pour tout connecteur donné reste l’essai de conformité de référence pour le connecteur en question. La liste ci-dessus de séries de normes concernant les connecteurs n’exclut pas le fait de faire référence au présent document dans d’autres normes publiées ou spécifications des fabricants de connecteurs. Les procédures spécifiées ici sont:
- perte d’insertion, essai 28a;
- affaiblissement de réflexion, essai 28b;
- paradiaphonie (NEXT), essai 28c;
- télédiaphonie (FEXT), essai 28d;
- perte de conversion transverse (TCL), essai 28f;
- perte de transfert de conversion transverse (TCTL), essai 28g.
Les autres procédures citées ici en référence sont:
- impédance de transfert (ZT), voir l’IEC 60512-26-100, essai 26e;
- pour l’affaiblissement de couplage (aC), voir l’IEC 62153 4 12.
Cette deuxième édition annule et remplace la première édition parue en 2013 et constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l’édition précédente:
- Le titre a été modifié, 1 000 MHz a été remplacé par 2 000 MHz afin de refléter la plage des fréquences qui peuvent être soumises à des essais.
- Tous les tableaux et toutes les exigences ont été révisés jusqu’à 2 000 MHz.
Mots-clés: connecteurs, essai d’intégrité des signaux

General Information

• Status: Published
• Publication Date: 14-Nov-2019
• ICS: 31.220.10 - Plug-and-socket devices. Connectors
• Technical Committee: SC 48B - Electrical connectors
• Current Stage: DELPUB - Deleted Publication
• Start Date: 02-Aug-2024
• Completion Date: 18-Nov-2021

Relations

• Revises: IEC 60512-28-100:2013 - Connectors for electronic equipment - Tests and measurements - Part 28-100: Signal integrity tests up to 1 000 MHz on IEC 60603-7 and IEC 61076-3 series connectors - Tests 28a to 28g
• Effective Date: 05-Sep-2023
• Revised: IEC 60512-28-100:2024 - Connectors for electrical and electronic equipment - Tests and measurements - Part 28-100: Signal integrity tests up to 2 000 MHz - Tests 28a to 28g
• Effective Date: 05-Sep-2023

Overview

IEC 60512-28-100:2019 defines standardized signal integrity tests for connectors used in electrical and electronic equipment, extending the test frequency range up to 2 000 MHz. It specifies test methods and measurement arrangements to evaluate transmission performance of connector series referenced in IEC 60603-7 and IEC 61076-1/2/3 and can be applied to lower-frequency connector types (while the connector’s own detail specification remains the primary conformance reference).

This second edition updates the previous 1 000 MHz scope to 2 000 MHz and revises tables and requirements throughout.

Key topics and technical requirements

• Signal integrity measurements (Tests 28a–28g):
  • Test 28a - Insertion loss
  • Test 28b - Return loss
  • Test 28c - Near-end crosstalk (NEXT)
  • Test 28d - Far-end crosstalk (FEXT)
  • Test 28f - Transverse conversion loss (TCL)
  • Test 28g - Transverse conversion transfer loss (TCTL)
• Referenced procedures
  • Shield transfer impedance (ZT) - see IEC 60512-26-100 (test 26e)
  • Coupling attenuation (aC) - see IEC 62153‑4‑12
• Measurement infrastructure and best practice
  • Use of vector network analysers (VNA), RF switching units, controlled coaxial interconnects and calibrated reference loads
  • Mixed-mode S‑parameter nomenclature and modal decomposition techniques for balanced pair measurements
  • Detailed requirements for test fixtures (indirect-reference, direct-probe, specialized) and termination loads
  • Calibration at the defined reference plane and verification of termination symmetry and impedance matching
• Test reporting and accuracy guidance for each measurement type

Practical applications

• Qualification and performance verification of high-speed connectors used in:
  • Data communications (Ethernet, datacenter interconnects)
  • Telecommunications and networking equipment
  • Industrial and electronic assemblies requiring controlled transmission up to 2 GHz
• Use cases include connector design validation, production test, compliance verification, and supplier qualification.
• Test labs, OEMs, connector manufacturers and compliance engineers use this standard to ensure consistent, repeatable signal integrity results across suppliers and test facilities.

Who should use this standard

• Connector manufacturers and R&D teams validating mating hardware
• Independent test and certification laboratories
• System integrators and OEMs specifying connector performance for high-speed links
• Quality and compliance engineers establishing test programs for interconnects

Related standards

• IEC 60603-7, IEC 61076-1/2/3 (connector family specifications)
• IEC 60512-26-100 (transfer impedance test 26e)
• IEC 62153-4-12 (coupling attenuation)

Keywords: IEC 60512-28-100:2019, Connectors, Signal Integrity Tests, insertion loss, return loss, NEXT, FEXT, TCL, TCTL, transfer impedance, mixed‑mode S‑parameters.
