IEC 61009-1:2024

Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs) - Part 1: General rules

IEC 61009-1:2024 gives general requirements and tests for residual current operated circuit‑breakers with integral overcurrent protection for household and similar uses (hereafter referred to as RCBOs), for rated operational voltages not exceeding 440 V AC, with rated frequencies of 50 Hz, 60 Hz or 50/60 Hz and rated currents not exceeding 125 A and rated short‑circuit capacities not exceeding 25 000 A.
This fourth edition cancels and replaces the third edition published in 2010, Amendment 1:2012 and Amendment 2:2013. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) harmonization of all clauses between the IEC 61008, IEC 61009 and IEC 60755 series using blocks and modules approach;
b) harmonization of all tables and figures between the IEC 61008, IEC 61009 and IEC 60755 series;
c) terms and definitions are now referred to IEC 62873-2;
d) modification of Subclause 4.1 for classification according to supply conditions;
e) new Subclauses 8.17 and 9.24 for requirements and tests for the resistance to temporary overvoltages (TOV);
f) improvement of Subclause 9.7 for test of dielectric properties;
g) tests for screwless, flat-quick terminals and aluminium conductors are now referred to in the IEC 62873-3 series.

Interrupteurs automatiques à courant différentiel résiduel avec dispositif de protection contre les surintensités incorporé pour usages domestiques et analogues (DD) – Partie 1: Règles générales

L'IEC 61009-1:2024 spécifie les exigences générales et les essais relatifs aux interrupteurs automatiques à courant différentiel résiduel avec dispositif de protection contre les surintensités incorporé pour usages domestiques et analogues (ci-après appelés DD), de tension d'emploi assignée inférieure ou égale à 440 V en courant alternatif avec une fréquence assignée de 50 Hz, 60 Hz ou 50/60 Hz, un courant assigné inférieur ou égal à 125 A et des pouvoirs de coupure et de fermeture en court‑circuit assignés inférieurs ou égaux à 25 000 A.
Cette quatrième édition annule et remplace la troisième édition parue en 2010, son Amendement 1:2012 et son Amendement 2:2013. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) harmonisation de tous les articles entre les séries IEC 61008, IEC 61009 et IEC 60755 par une approche fondée sur les blocs et les modules;
b) harmonisation de tous les tableaux et de toutes les figures entre les séries IEC 61008, IEC 61009 et IEC 60755;
c) les termes et définitions renvoient désormais à l'IEC 62873-2;
d) modification du 4.1 relatif à la classification selon les conditions d'alimentation;
e) de nouveaux paragraphes 8.17 et 9.24 ont été ajoutés pour les exigences et les essais de résistance aux surtensions temporaires (TOV);
f) amélioration du 9.7 relatif à l'essai des propriétés diélectriques;
g) les essais des bornes sans vis, des bornes plates à connexion rapide et des conducteurs en aluminium renvoient désormais à la série IEC 62873-3.
La présente version bilingue (2025-11) correspond à la version anglaise monolingue publiée en 2024-11.
La version française de cette norme n'a pas été soumise au vote.

General Information

• Status: Published
• Publication Date: 20-Nov-2024
• ICS: 29.120.50 - Fuses and other overcurrent protection devices
• Technical Committee: SC 23E - Circuit-breakers and similar equipment for household use
• Drafting Committee: WG 2 - TC 23/SC 23E/WG 2
• Current Stage: PPUB - Publication issued
• Start Date: 21-Nov-2024
• Completion Date: 06-Dec-2024

Relations

• Revises: IEC 61009-1:2010 - Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs) - Part 1: General rules
• Effective Date: 05-Sep-2023
• Revises: IEC 61009-1:2010/AMD2:2013 - Amendment 2 - Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs) - Part 1: General rules
• Effective Date: 05-Sep-2023
• Revises: IEC 61009-1:2010/AMD1:2012 - Amendment 1 - Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs) - Part 1: General rules
• Effective Date: 05-Sep-2023
• Revises: IEC 61009-1:2010/AMD2:2013/COR1:2014 - Corrigendum 1 - Amendment 2 - Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs) - Part 1: General rules
• Effective Date: 05-Sep-2023

Overview

IEC 61009-1:2024 - Residual current operated circuit‑breakers with integral overcurrent protection (RCBOs) - Part 1: General rules, is the 4th edition international standard that defines general requirements and mandatory tests for RCBOs for household and similar uses. It applies to devices with rated operational voltages up to 440 V AC, rated frequencies 50 Hz, 60 Hz or 50/60 Hz, rated currents up to 125 A, and rated short‑circuit capacities up to 25 000 A. This edition supersedes the 2010 edition and its amendments and constitutes a technical revision with harmonization and new test requirements.

Key Topics and Requirements

The standard establishes construction, performance and testing rules for RCBOs, covering:

• Classification and rated values
  • Classification according to supply conditions, number of poles/current paths and adjustable residual operating current.
  • Rated voltages, rated currents (In ≤ 125 A), rated frequency and rated short‑circuit capacity (Icn ≤ 25 000 A).
• Construction and safety
  • Mechanical design, terminals (including screwless and flat‑quick), clearances and creepage, and protection against electric shock.
• Electrical performance
  • Operating characteristics for residual currents, overcurrent response, temperature‑rise limits and mechanical/electrical endurance.
• Dielectric and transient requirements
  • Improved dielectric property tests (Subclause 9.7) and resistance to temporary overvoltages (TOV) (new Subclauses 8.17 and 9.24).
• Short‑circuit and making/breaking capability
  • Tests for short‑circuit behaviour, verification of I²t and peak current, and rated residual making and breaking capacity (IΔm).
• Reliability and environmental robustness
  • Resistance to mechanical shock/impact, heat, fire behaviour, EMC and marking/installation conditions.
• Harmonization and references
  • Harmonized clause structure, tables and figures with IEC 61008 and IEC 60755 using a blocks/modules approach; terms and definitions now referenced to IEC 62873-2; terminal and conductor tests referenced to IEC 62873-3.

Applications and Who Uses This Standard

IEC 61009-1:2024 is essential for:

• RCBO manufacturers designing products for household and similar applications.
• Test laboratories and certification bodies performing compliance testing and type approval.
• Electrical safety engineers and product designers specifying protective devices in distribution boards.
• Specifiers, utilities and regulators referencing internationally harmonized safety and performance criteria.
• Installers and OEMs selecting compliant RCBOs for residential and light commercial applications.

Related Standards

• IEC 61008 (residual current circuit-breakers without integral overcurrent protection)
• IEC 60755 (series related requirements)
• IEC 62873-2 (terms and definitions)
• IEC 62873-3 (terminal and conductor tests)

Keywords: IEC 61009-1:2024, RCBOs, residual current operated circuit-breaker, overcurrent protection, TOV, dielectric tests, rated short‑circuit capacity, household electrical safety.
