INTERNATIONAL STANDARD ISO 14621-1:2019(E)
Space systems — Electrical, electronic and
electromechanical (EEE) parts —
Part 1:
Parts management
1 Scope

This document addresses the key elements for an EEE parts management programme for space systems

and is written in general terms as a baseline for developing, implementing, validating, and evaluating a

space parts management programme. The family of EEE parts includes electro-optical parts.

2 Normative references

The following documents are referred to in the text in such a way that some or all of their content

constitutes requirements of this document. For dated references, only the edition cited applies. For

undated references, the latest edition of the referenced document (including any amendments) applies.

ISO 14621-2, Space systems — Electrical, electronic and electromechanical (EEE) parts — Part 2: Control

Programme Requirements
ISO 17666, Space systems — Risk management
3 Terms, definitions, and abbreviated terms
3.1 Terms and definitions
For the purposes of this document, the following terms and definitions apply.

ISO and IEC maintain terminological databases for use in standardization at the following addresses:

— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1.1
best practice

documented process or product developed by the user community, consisting of suppliers and

customers, teaming for the purpose of establishing industry guidelines
3.1.2
electronic, electrical, or electromechanical part
EEE part

device that performs an electronic, electrical, or electromechanical (EEE) function, including electro-

optical devices, and consists of one or more elements so joined together that they cannot normally be

disassembled without destroying the functionality of the device
3.1.3
integrated product team
IPT

integrated product team consisting of members selected from the appropriate disciplines

EXAMPLE Engineering, manufacturing, quality, suppliers or customers, as appropriate.

© ISO 2019 – All rights reserved 1
---------------------- Page: 7 ----------------------
ISO 14621-1:2019(E)
3.1.4
manufacturer
company or organization that transfers raw material into a product
3.1.5
performance specification

document that defines what the customer desires as a product, its operational environments and all

required performance characteristics
3.1.6
product specification

document that defines the end item(s) the supplier intends to provide to satisfy all the performance

specification (3.1.5) requirements
3.1.7
reliability engineering

integral part of the system engineering requirements definition and analysis function

Note 1 to entry: The tasks are to conduct cost/benefit trade-offs and to analyse and determine alternative design

and procurement solutions.
3.1.8
systems engineering

interdisciplinary approach governing the total technical and managerial effort required to transform

a set of stakeholder needs, expectations, and constraints into a solution and to support that solution

throughout its life
[SOURCE: ISO/IEC/IEEE 24748-1:2018, 3.57]
3.1.9
technology insertion strategy

decision making process to assess current and future part availability and trends, which leads to a

decision regarding emerging or new technology insertion

Note 1 to entry: This process is used in the concept development phase, but also impacts the production and field

support phases.
3.1.10
validation

confirmation, through the provision of objective evidence, that the requirements for a specific intended

use or application have been fulfilled

[SOURCE: ISO 9000:2015, 3.8.13, modified — Notes 1, 2, and 3 to entry have been deleted.]

3.1.11
vendor
seller of parts, products, or commodities

Note 1 to entry: This term can be interchangeable with manufacturer (3.1.4), depending on the application

3.1.12
verification

confirmation, through the provision of objective evidence, that specified requirements have been

fulfilled

[SOURCE: ISO 9000:2015, 3.8.12, modified — Notes 1, 2, and 3 to entry have been deleted.]

2 © ISO 2019 – All rights reserved
---------------------- Page: 8 ----------------------
ISO 14621-1:2019(E)
3.2 Abbreviated terms
ARN anticipated reliability number
ASIC application specific integrated circuit
BOM bill of materials
CAM computer-aided manufacturing
Cpk process capability
DEMP discharge electromagnetic pulse
DIC digital integrated circuit
DM design margin
DMSMS diminishing manufacturing sources and material shortages
DoE design of experiments
DPA destructive physical analysis
EEE electronic, electrical and electromechanical
EMC electro-magnetic compatibility
EMP electromagnetic pulse
EPI epitaxial
ESD electrostatic discharge
FMECA failure modes and effects criticality analysis
F I form, fit, function interfaces
FRACAS failure reporting, analysis, and corrective action system
HAST highly accelerated stress test
HEMP high altitude electromagnetic pulse
IPD integrated product design
MPU micro processing unit
NDI non-developmental item
OEM original equipment manufacturer
PEM plastic encapsulated microcircuit
PWB printed wiring board
QML qualified manufacturers list
QPL qualified parts list
RH relative humidity
© ISO 2019 – All rights reserved 3
---------------------- Page: 9 ----------------------
ISO 14621-1:2019(E)
SEB single event burnout
SEE single event effects
SEGR single event gate rupture
SEL single event latchup
SEU single event upset
SGEMP system-generated electromagnetic pulse
SPC statistical process control
4 EEE parts management programme
4.1 EEE parts management process
4.1.1 General

The EEE parts management process defined in this document is designed to assist in dealing

more proactively with critical parts management issues and to provide guidance for developing

comprehensive strategies to manage EEE parts related performance, cost, and schedule risk via an

integrated product team (IPT) process (Figure 1). The main aspects of the EEE parts management

process are design process, supplier management, and shared data. The design process includes,

but is not limited to, design margins, life cycle cost, technology insertion, technical support, system

engineering support, parts selection, obsolescence management and validation/verification. The

emphasis should be on concurrent rather than sequential consideration of these factors in design.

Space systems users shall systematically select and proactively monitor their parts supplier base, while

information collected from the EEE parts manufacturing and supplier communities shall be organized

in a database and shared with IPT members.
Figure 1 — Parts management IPT overview
4.1.2 Design process

The flow diagram (Figure 2) illustrates the interrelationships of the critical key elements that shall be

addressed concurrently by engineering and supplier management (B) (see 4.2), to achieve the “best

4 © ISO 2019 – All rights reserved
---------------------- Page: 10 ----------------------
ISO 14621-1:2019(E)

practice” selection of EEE parts and documentation required for the initial design. The results obtained

from this analysis should be made available as shared data (A) (see 4.3). The following paragraphs

describe the principles embodying the ten key elements. Refer to the Introduction.

4.1.3 Design margin

The objective of developing a design margin is to assist integrated product teams with critical analyses

resulting in a robust design and minimized life cycle cost. The availability of computer-based analysis

and simulation tools presents the opportunity to validate in detail those aspects of design prior to

manufacturing/qualification commitment. Creating a design margin analysis based on actual conditions

will provide a comprehensive description of EEE part characteristics with simulation results, thereby

enhancing system performance. The design margin process (Figure 3) describes a minimum set of

design analyses needed to maximize design robustness and identifies control limits and corrective

action procedures. Metrics to validate the process include, but are not limited to, the following:

a) comparisons of actual design margins to established baselines;
b) quality of engineering design changes;
c) qualification test performance (failures);
d) prediction analysis yield;
e) manufacturing/production yields.
Associated elements are parts selection (4.1.8) and technical support (4.1.6).
© ISO 2019 – All rights reserved 5
---------------------- Page: 11 ----------------------
ISO 14621-1:2019(E)
Key
linked to shared data (see 4.3)
linked to supplier management (see 4.2)
Figure 2 — Systems engineering IPT product
6 © ISO 2019 – All rights reserved
---------------------- Page: 12 ----------------------
ISO 14621-1:2019(E)
Figure 3 — Design margin process
4.1.4 Life cycle cost

In establishing life cycle cost for EEE parts, the following methods should be employed: identify

technology assessment techniques and the mitigation of parts failure risk and utilize procedures

that minimize programme disruptions due to parts obsolescence, unavailability, and other unwanted

conditions. Life cycle cost analysis should include, as well as define, the EEE parts management

programme’s baseline and support a programmatic risk management methodology to control cost as

well as reduce schedule disruptions throughout the life cycle of the programme (Figure 4).

Standardization techniques are becoming increasingly dependent on the available supplier base and

market trends. A new and innovative process being implemented moves away from part number

standardization to commodity/technology/family standardization. This concept should provide a lower

cost/higher benefit approach as the demand for commercial EEE parts increases.

Factors to be considered include technology maturity, market base, material cost, ease of manufacture,

performance management, logistics costs, standardization, and form, fit, function interfaces (F I).

Initial nonrecurring costs should be de-emphasized and rationalized with long-term cost savings to

provide the best value to the customer.

Through the implementation of technology assessments, strategic supplier relationships, technology

leapfrogging, and creative risk mitigation techniques, programme continuity and integrity can be

maintained, and life cycle costs can be minimized.

Validation of the life cycle cost objectives can be accomplished through the use of the following methods:

a) design-to-cost trade studies documenting parts selected during the design phase including all

elements of cost;

b) periodic programme assessment of life cycle ratings, part technology, and part obsolescence;

© ISO 2019 – All rights reserved 7
---------------------- Page: 13 ----------------------
ISO 14621-1:2019(E)

c) periodic price trend analyses for “road map” technologies to validate that costs are declining as the

technologies move from introduction and growth to production maturity in the market;

d) associated elements are:
1) technology insertion strategy (4.1.5),
2) parts selection (4.1.8), and
3) obsolescence management (4.1.9).
4.1.5 Technology insertion strategy

The objective of the technology insertion strategy is to create a technology road map, which minimizes

the risk of obsolescence and develops a strategy for technology insertion during the entire life cycle

(Figure 5). The commercial industry is driving new technology development of EEE parts. The market

dynamics of the industry (availability, functionality, performance, characteristics, and packaging) affect

the way parts are used in the design. Technology road maps subdivide technologies into functions,

which provide the required visibility to resolve future obsolescence and standardization issues. Use of

technology road maps is the key element of the parts selection process. Technology road maps shall be

assessed over the life cycle of the programme to validate their effectiveness.
Associated elements are:
a) design margin (4.1.3),
b) life cycle costs (4.1.4),
c) parts selection (4.1.8), and
d) obsolescence management (4.1.9).
4.1.6 Technical support

Technical support is an all-encompassing activity established to provide a method of obtaining data

to facilitate reliability analysis, monitor applications, identify risk issues, and suggest mitigation

paths associated with the selected parts (Figure 6). Technical support requires a total commitment

by all disciplines and levels of management to ensure success. Specifically, the user shall define

his/her reliability requirements. The responsibility for reliability engineering activities shall be

established early in the programme in order to minimize the cost of unscheduled redesign, rework, or

remanufacture, as well as potential safety problems. Accomplishment of the performance objectives

will be enhanced through the application of user and field reliability information from shared data. The

shared data and supplier management information should be used in support of the IPT for evaluating

sourcing, performance, packaging, and availability. Associated elements of reliability models are

a) design margin (4.1.3),
b) parts selection (4.1.8), and
c) shared data (4.3).
8 © ISO 2019 – All rights reserved
---------------------- Page: 14 ----------------------
ISO 14621-1:2019(E)
Figure 4 — Life cycle cost process
© ISO 2019 – All rights reserved 9
---------------------- Page: 15 ----------------------
ISO 14621-1:2019(E)
Figure 5 — Technology insertion strategy (road map)
4.1.7 System engineering support

The major engineering disciplines involved in evaluating reliability processes are shown in Table 1.

Reliability engineering is just one of the many disciplines required to assess programme development

and implementation. Reliability concepts should be developed early in the programme in order to ensure

adequate verification techniques are defined. Qualification and verification testing are an integral part

of determining system performance characteristics. Failure analysis is a proactive tool for updating

reliability models and ensuring system lifetime performance. Reliability growth and pre-qualification

testing provide opportunities to reveal design and process deficiencies when they are the least costly to

fix or repair or to change the product. Verification testing is equally important in achieving programme

reliability goals as well as production processes. Materials and vendors are constantly changing;

therefore, the understanding of specific failure modes, fault tree analyses and field performance data

should provide a means to identify and correct most reliability problems. During design evaluation,

parts manufacturers should identify the use of simulation data [application specific integrated circuits

(ASIC’s)], interface data, mechanical/thermal robustness, and radiation sen
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
