INTERNATIONAL STANDARD ISO 21219-18:2019(E)
Intelligent transport systems — Traffic and travel
information (TTI) via transport protocol experts group,
generation 2 (TPEG2) —
Part 18:
Traffic flow and prediction application (TPEG2-TFP)
1 Scope
This document specifies the TPEG application Traffic Flow and Prediction (TFP). It has been specifically
designed to provide information to a variety of receivers using different channels, including in the
first instance digital broadcasting and Internet technologies. Traffic flow and prediction messages are
intended for in-car applications and can also be presented directly to the user by textual, voice and
graphical output devices.
TFP is status oriented, i.e. the transmitted information continuously updates the receiver's knowledge
for a dedicated road network. In particular the traffic states are delivered any time and for all road
sections of the network, even when there are no abnormal traffic situations.
Generally, TFP focuses on the following requirements:
— provides dynamic navigation systems with up-to-date traffic state information;
— ensures travel safety for the driver;
— enables the calculation of alternative routes;
— avoids delays (e.g. traffic jams);
— lowers traffic load on over-saturated parts of the network;
— keeps the driver informed about current and upcoming traffic;
— compact and efficient coding of the traffic information.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1
Message Management Container
concept applied to the grouping of all message elements, including Message Management Information,
of a TPEG-Message together in one place
© ISO 2019 – All rights reserved 1
---------------------- Page: 8 ----------------------
ISO 21219-18:2019(E)
3.2
Location Referencing
means to provide information that allows a system to accurately identify a location
Note 1 to entry: The content of a location reference allows the location to be presented in a graphical or textual
manner to the end-user (e.g. coloured network graphs) as well as to be used for navigational systems purposes.
3.3
Location Referencing Container
concept applied to the grouping of all the Location Referencing elements, of a TPEG-Message, together
in one place
Note 1 to entry: See ISO/TS 21219-7 for full details of the Location Referencing container.
4 Abbreviated terms
ACID Application and Content Identifier
ADC Application Data Container
AID (TPEG) Application IDentification
CEN Comité Européen de Normalisation
EBU European Broadcasting Union
ITS Intelligent Transport Systems
LRC Location Referencing Container
MMC Message Management Container
OSI Open Systems Interconnection
SFW (TPEG) Service Framework
SID Service and Network Information
SNI Service and Network Information
TISA Traveller Information Services Association
TFP Traffic Flow and Prediction
TMC Traffic Message Channel
TPEG Transport Protocol Expert Group
TTI Traffic and Traveller Information
UML Unified Modelling Language
XML Extensible Markup Language
XSD XML Schema Definition
2 © ISO 2019 – All rights reserved
---------------------- Page: 9 ----------------------
ISO 21219-18:2019(E)
5 Application specific constraints
5.1 Application identification
The word 'application' is used in the TPEG specifications to describe specific subsets of the TPEG
structure. An application defines a limited vocabulary for a certain type of message, e.g. parking
information or road traffic information. Each TPEG application is assigned a unique number, called the
Application IDentification (AID). An AID is defined whenever a new application is developed. These are
all listed in ISO/TS 21219-1.
The application identification number is used within the TPEG2-SNI application (ISO/TS 21219-9) to
indicate how to process TPEG content and facilitates the routing of information to the appropriate
application decoder.
5.2 Version number signalling
Version numbering is used to track the separate versions of an application through its development and
deployment. The differences between these versions may have an impact on client devices.
The version numbering principle is defined in ISO/TS 21219-1.
Table 1 shows the current version numbers for signaling TFP within the SNI application.
Table 1 — Current version numbers for signalling of TFP
major version number 1
minor version number 1
5.3 Ordered components
TPEG2-TFP requires a fixed order of TPEG components. The order for the TFP message component is
shown in Figure 1; the first component shall be the Message Management Container. This shall be the only
component if the message is a cancellation message. Otherwise, the MMC component shall be followed
by one or more Application Data Container components, which includes the traffic flow information.
This shall be followed by the Location Referencing Container component, if the LRC is present in this
message (see also 7.1).
Figure 1 — Composition of TPEG messages
5.4 Extendibility
The requirement of a fixed component order does not affect the extension of TFP. Future application
extensions may insert new components or may replace existing components by new ones without
© ISO 2019 – All rights reserved 3
---------------------- Page: 10 ----------------------
ISO 21219-18:2019(E)
losing backward compatibility. This means that a TFP decoder shall be able to detect and skip unknown
components.
5.5 TPEG Service Component Frame
TPEG2 TFP makes use of the “Service Component Frame with dataCRC, groupPriority, and
messageCount” according to ISO 21219-5.
6 TFP structure
Figure 2 — TFP message structure
4 © ISO 2019 – All rights reserved
---------------------- Page: 11 ----------------------
ISO 21219-18:2019(E)
7 TFP Message components
7.1 TFPMessage
A 'TFPMessage' component is the top container of a TFP message. It contains all information about a
particular part of the network, e.g. the traffic state for a road segment.
The traffic flow content of a TFPMessage is typically highly dynamic while the affected road stretch
defined by the Location Referencing Container (LRC) shall remain static during the life cycle of a
message. Thus, partial message management (ISO 21219-6) may be applied to update the traffic flow
states of a message frequently whereas the LRC may be repeated with a longer repetition interval.
Accordingly, a TFP message can include alternatively:
— One MMC only in case of a cancellation message (ISO 21219-6);
— One MMC, one or several ADCs and one LRC in case of monolithic message management
(ISO/TS 21219-6);
— Partial message management (ISO/TS 21219-6):
— One MMC only, including the multipart message directory,
— One MMC and one or several ADCs,
— One MMC and one LRC.
TFP provides three methods for the representation of current and predicted traffic flow states which
may be used alternatively, i.e. just one method shall be applied within one TFP message:
— Flow-Polygon-Method: The traffic flow is modelled by a number of spatial/temporal
'FlowPolygonObjects' (see description of component 'FlowPolygonObject', 7.8).
— FlowStatus-Method: A flow status applied to the overall road stretch defined by the LRC of the
message (see description of component 'FlowStatus', 7.10). A TFP message using this method and
which is not a cancellation message shall contain exactly one 'FlowStatus' container.
— Flow-Matrix-Method: The road stretch is divided into sections each with a homogenous flow state,
thus building a 'FlowVector'. A 'FlowMatrix' consists of one or several FlowVectors for dedicated
temporal intervals, e.g. with one FlowVector for the current flow status and another one for
prognosis in 15 min (see description of components 'FlowMatrix', 7.11). A TFP message using this
method and which is not a cancellation message shall contain exactly one 'FlowMatrix' container.
To minimize the length of TFP messages the spatial positions of the Flow-Matrix and Flow-Polygon
methods are coded by spatial offsets to the location reference in the LRC. These offsets shall be
calculated in upstream direction to the end of the road stretch as defined by the location reference of
the message (see also 8.3). The location reference in the LRC shall cover the entire road stretch required
for this TFP message. The Flow-Matrix method allows also the usage of relative offsets (see 7.11).
The attributes of the 'TFPMessage' component are listed hereunder:
Table 2 — TFPMessage
Name Type Multiplicity Description
Ordered Components
mmc MessageManagementContainer 1 Message Management Container
(external)
method Component TFPMethod 0.* Traffic flow data
loc LocationReferencingContainer 0.1 Location Referencing Container
(external)
© ISO 2019 – All rights reserved 5
---------------------- Page: 12 ----------------------
ISO 21219-18:2019(E)
7.2 TFPMethod
Traffic conditions are modelled as traffic flow objects. TFP provides three different methods to define
such an object, for details see descriptions of components 'FlowPolygonObject', FlowStatus' and
FlowMatrix'.
The template 'TFPMethod' is the generalization of these three methods.
Name Type Multiplicity Description
startTime DateTime 1 The start of the time period for which the provided content
is valid.
duration IntUnLoMB 0.1 The duration [min] of the time period for which the
provided content is val
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
