INTERNATIONAL STANDARD ISO 18296:2014(E)
Ships and marine technology — Ship-shifting winches
1 Scope

This International Standard specifies requirements for the design, operation, safety, performance, and

inspection rules of ship-shifting winches, with electric or hydraulic drive.

Such winches are applicable to longitudinal and transverse movements or positioning of engineering

vessels for offshore operation. It can be used as a reference for inland operation.

2 Normative references

The following documents, in whole or in part, are normatively referenced in this document and are

indispensable for its application. For dated references, only the edition cited applies. For undated

references, the latest edition of the referenced document (including any amendments) applies.

ISO 2408, Steel wire ropes for general purposes — Minimum requirements

ISO 3828, Shipbuilding and marine structures — Deck machinery — Vocabulary and symbols

ISO 4413, Hydraulic fluid power — General rules and safety requirements for systems and their components

ISO 6482, Shipbuilding — Deck machinery — Warping end profiles
ISO 7825, Shipbuilding — Deck machinery — General requirements

IEC 60092 (all parts), Electrical installations in ships — Special features — High Voltage Shore Connection

Systems (HVSC-Systems)
IEC 60529, Degrees of protection provided by enclosures (IP Code)
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1 Technical terms
3.1.1
light load pull

pull of steel wire ropes not less than 25 % that of the drum load with a rope wound on the drum in a

single layer
3.1.2
light line speed

minimum hauling speed measured when the ship-shifting winch is under the light load pull with a rope

wound on the drum in a single layer
3.1.3
normally closed brake

brake that is always in the braking condition except for the operation conditions of hoisting and

rendering a rope
© ISO 2014 – All rights reserved 1
---------------------- Page: 5 ----------------------
ISO 18296:2014(E)
3.2 Types of ship-shifting winches
3.2.1
left-hand ship-shifting winch

winch where the reduction gear or the drive of the drum is on the left-hand side of the drum, in relation

to an observer situated on the side of the motor, power supply, or controller
Note 1 to entry: See Figure 1.
3.2.2
right-hand ship-shifting winch

winch where the reduction gear or the drive of the drum is on the right-hand side of the drum, in relation

to an observer situated on the side of the motor, power supply, or controller
Note 1 to entry: See Figure 2.
Figure 1 — Left-hand ship-shifting winch
Figure 2 — Right-hand ship-shifting winch
4 Design and operation
4.1 General requirements

Ship-shifting winches shall meet the general requirements for deck equipment in ISO 7825.

NOTE Attention is drawn to the existence of safety regulations in certain countries and organizations

affecting ship-shifting winch controls.
4.2 Strength requirements

4.2.1 The allowable calculated stresses of any drive part under the drum load, based on simple elastic

theory, shall not be greater than 0,4 times the upper yield strength ( R )
...
