SIST EN 302 755 V1.4.1:2016

Digital Video Broadcasting (DVB);Frame structure channel coding and modulation for a second generation digital terrestrial television broadcasting system (DVB-T2)

The present document describes a second generation baseline transmission system for digital terrestrial television
broadcasting. It specifies the channel coding/modulation system intended for digital television services and generic data
streams.
The scope is as follows:
• it gives a general description of the Baseline System for digital terrestrial TV;
• it specifies the digitally modulated signal in order to allow compatibility between pieces of equipment
developed by different manufacturers. This is achieved by describing in detail the signal processing at the
modulator side, while the processing at the receiver side is left open to different implementation solutions.
However, it is necessary in this text to refer to certain aspects of reception.
Versions 1.1.1 and 1.2.1 of the present document [i.7] and [i.8] defined a single profile which incorporates time-slicing
but not time-frequency-slicing (TFS). Features which would allow a possible future implementation of TFS (for
receivers with two tuners/front-ends) can be found in annex E. It is not intended that a receiver with a single tuner
should support TFS.
Version 1.3.1 of the present document [i.9] added a T2-Lite profile. This profile is intended to allow simpler receiver
implementations for very low capacity applications such as mobile broadcasting, although it may also be received by
conventional stationary receivers. The details of this T2-Lite profile are described in annex I. Version 1.3.1 of the
present document [i.9] also introduces a name, which is 'T2-base profile', for the previous single profile.
Version 1.4.1 (the present document) made a number of changes, but all of these are clarifications of particular points,
changes in non-normative recommendations, and corrections to the wording; no new technical features have been added
and no changes have been made to existing features.

Digitalna videoradiodifuzija (DVB) - Struktura okvirov, kodiranje kanalov in modulacija za drugo generacijo sistema digitalne prizemne televizijske radiodifuzije (DVB-T2)

Ta dokument opisuje drugo generacijo osnovnega prenosnega sistema za digitalno prizemno televizijsko radiodifuzijo. Določa sistem za kodiranje/modulacijo kanalov, namenjen za storitve digitalne televizije in splošnih podatkovnih tokov.
Obseg je naslednji:
• podaja splošen opis osnovnega sistema za digitalno prizemno televizijo;
• določa digitalno moduliran signal, s čimer omogoči združljivost med deli opreme
različnih proizvajalcev. To se doseže s podrobnim opisom obdelave signala na strani modulatorja, medtem ko je obdelava na strani sprejemnika mogoča z različnimi rešitvami.
Vendar je treba v okviru tega besedila nasloviti tudi določene vidike sprejemanja.
Različici 1.1.1 in 1.2.1 tega dokumenta [i.7] in [i.8] opredeljujeta en sam profil, ki vključuje časovno segmentacijo, ne pa tudi časovno-frekvenčne segmentacije (TFS). Značilnosti, ki bi omogočale morebitno prihodnjo uvedbo časovno-frekvenčne segmentacije (TFS) (za sprejemnike z dvema uglaševalnikoma/demodulatorjema), so navedene v dodatku E. Sprejemnik z enim samim uglaševalnikom naj ne bi bil namenjen podpori časovno-frekvenčne segmentacije (TFS).
Različica 1.3.1 tega dokumenta [i.9] dodatno vključuje profil T2-Lite. Ta profil omogoča preprostejše uvedbe sprejemnika za uporabe z zelo nizkimi zmogljivostmi, kot je mobilna radiodifuzija, čeprav ga lahko sprejemajo tudi običajni stacionarni sprejemniki. Podrobnosti tega profila T2-Lite so opisane v dodatku I. Različica 1.3.1 tega dokumenta [i.9] uvaja tudi naziv, tj. »profil T2-base«, in sicer za prejšnji posamezni profil.
Različica 1.4.1 (ta dokument) je uvedla številne spremembe, vendar so te spremembe le pojasnila določenih točk, spremembe v priporočilih, ki niso normativna, ter popravki besedila; nobene nove tehnične funkcije niso bile dodane in nobene obstoječe funkcije niso bile spremenjene.

General Information

• Status: Published
• Publication Date: 05-Jan-2016
• ICS: 33.170 - Television and radio broadcasting
• Technical Committee: MOC - Mobile Communications
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 04-Nov-2015
• Due Date: 09-Jan-2016
• Completion Date: 06-Jan-2016
• Ref Project: ETSI EN 302 755 V1.4.1 (2015-07) - Digital Video Broadcasting (DVB); Frame structure channel coding and modulation for a second generation digital terrestrial television broadcasting system (DVB-T2)

Overview

SIST EN 302 755 V1.4.1:2016 (equivalent to ETSI EN 302 755 V1.4.1) defines the DVB-T2 baseline transmission system for second‑generation digital terrestrial television. The standard specifies the transmitter‑side signal processing needed to ensure interoperability between equipment from different manufacturers. It covers the frame structure, channel coding and modulation schemes used to deliver digital TV services and generic data streams. Version 1.4.1 clarifies wording and non‑normative guidance only; it introduces no new technical features.

Key topics and technical requirements

The document addresses the full signal creation chain for DVB‑T2, with major technical topics including:

• System architecture and target performance - overview of the DVB‑T2 baseline system and performance objectives.
• Input and stream adaptation - mode adaptation, input formats, synchronization, null‑packet deletion, CRC and baseband header insertion.
• Bit‑interleaved coding and modulation (BICM) - layered coding approach with outer BCH and inner LDPC error correction, bit interleaving and mapping to modulation constellations (including 16‑QAM, 64‑QAM, 256‑QAM).
• Interleaving and time processing - cell interleaver, time interleaver, mapping of interleaving frames to T2‑frames and handling of short/normal FEC frames.
• L1 signalling - generation, coding and modulation of the Layer‑1 signaling (P1, L1‑pre, L1‑post) that informs receivers about frame configuration and PLPs.
• Frame and super‑frame structure - T2‑frame duration, capacity, mapping of PLPs (Physical Layer Pipes) and L1 data into P2 symbols.
• Profiles and compatibility - description of the T2‑base profile and T2‑Lite profile (for simpler, low‑capacity/mobile reception), and optional support for time‑frequency slicing (TFS) for dual‑tuner receivers (annex E).

Practical applications and who uses this standard

SIST EN 302 755 is primarily used by:

• Broadcasters and network operators planning or operating DVB‑T2 terrestrial services (HD/UHD, mobile TV, datacasting).
• Transmitter and modem manufacturers implementing compliant modulators and encoders to ensure cross‑vendor interoperability.
• Receiver and chipset designers who need to support the signalling and PLP structures (note: the standard defines transmitter processing; receiver implementations may vary).
• Test laboratories and certification bodies validating DVB‑T2 equipment conformance.
• Regulators and system planners defining national frequency and service profiles.

Keywords: DVB‑T2, digital terrestrial television, channel coding, modulation, LDPC, BCH, frame structure, PLP, L1 signalling, T2‑Lite.

Related standards

• ETSI EN 302 755 series (earlier revisions referenced in the document)
• Associated DVB system documents and ETSI broadcast standards (for conformance and implementation guidance).

Standards Content (Sample)
