SIST EN ISO 14587:2012

Hexalobular socket raised countersunk (oval) head tapping screws (ISO 14587:2011)

ISO 14587:2011 specifies the characteristics of hexalobular socket raised countersunk (oval) head tapping screws with thread sizes from ST2,9 to ST6,3 inclusive.
If, in special cases, specifications other than those listed in ISO 14587:2011 are required, they can be selected from existing International Standards, for example ISO 1478, ISO 2702, ISO 4759-1.

Linsensenk-Blechschrauben mit Innensechsrund (ISO 14587:2011)

Diese Internationale Norm legt die Eigenschaften von Linsensenk-Blechschrauben mit Innensechsrund, mit Gewinde von ST2,9 bis ST6,3 fest.
Werden in besonderen Fällen andere als in dieser Internationalen Norm aufgeführten Festlegungen benötigt, können diese aus bestehenden Internationalen Normen wie zum Beispiel ISO 1478, ISO 2702 und ISO 4759 1 ausgewählt werden.

Vis à tôle à tête fraisée bombée à six lobes internes (ISO 14587:2011)

L'ISO 14587:2011 spécifie les caractéristiques des vis à tôle à tête fraisée bombée à six lobes internes, de filetage de diamètre ST2,9 à ST6,3 inclus.
Si, dans des cas particuliers, des spécifications autres que celles figurant dans l'ISO 14587:2011 sont requises, elles peuvent être choisies dans les Normes internationales existantes, par exemple l'ISO 1478, l'ISO 2702 et l'ISO 4759‑1.

Notranji šestrogeljnik v lečasti ugrezni glavi pločevinskega vijaka (ISO 14587:2011)

Ta mednarodni standard določa značilnosti vijakov z notranjim šestrogeljnikom v lečasti ugrezni glavi pločevinskega vijaka z velikostmi navojev od ST2,9 do vključno ST6,3. Če se v posebnih primerih zahtevajo specifikacije, ki so drugačne od navedenih v tem mednarodnem standardu, se lahko izberejo med obstoječimi mednarodnimi standardi, na primer ISO 1478, ISO 2702, ISO 4759-1.

General Information

• Status: Published
• Publication Date: 28-Nov-2011
• ICS: 21.060.10 - Bolts, screws, studs
• Technical Committee: ISEL - Mechanical elements
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 23-Nov-2011
• Due Date: 28-Jan-2012
• Completion Date: 29-Nov-2011
• Ref Project: EN ISO 14587:2011 - Hexalobular socket raised countersunk (oval) head tapping screws (ISO 14587:2011)

Relations

• Replaces: SIST EN ISO 14587:2002 - Hexalobular socket raised countersunk (oval) head tapping screws (ISO 14587:2001)
• Effective Date: 01-Jan-2012

Overview

SIST EN ISO 14587:2012 is an international standard specifying the characteristics of hexalobular socket raised countersunk (oval) head tapping screws, covering thread sizes from ST2.9 to ST6.3 inclusive. This standard, developed by ISO/TC 2 "Fasteners" in collaboration with CEN/TC 185 “Fasteners”, provides detailed specifications to ensure consistency, quality, and interchangeability of these specialized tapping screws in industrial applications. It supersedes the earlier edition EN ISO 14587:2001 and became effective as a European Standard in February 2011.

These tapping screws are characterized by their raised countersunk oval heads combined with a hexalobular (six-lobed) internal socket design, which enhances torque transfer and reduces cam-out during installation. The document offers comprehensive details on dimensions, material properties, mechanical requirements, and finishing methods.

Key Topics

• Scope and Application
  Defines thread sizes from ST2.9 up to ST6.3 and details screw types including edge treatments and head shapes tailored for specific engineering needs.

• Dimensions and Tolerances
  Precise measurements for various components of the screw such as pitch, head diameter, socket size, thread length, and pitch diameter are standardized following ISO 225 and ISO 7721. Dimensional accuracy ensures compatibility with mating parts and tools.

• Material and Mechanical Properties
  The screws are typically made from heat-treated steel conforming to ISO 2702 requirements, providing strength and durability. Mechanical properties ensure reliability in fastening applications, including resistance to shear and tensile stresses.

• Drive Feature
  The hexalobular internal driving feature specified by ISO 10664 is designed to optimize engagement with drivers, improving torque transmission while minimizing damage to screw heads.

• Finish and Coating
  Surface treatments include electroplated coatings per ISO 4042 and non-electrolytically applied zinc flake coatings according to ISO 10683, offering corrosion resistance and enhanced durability depending on environmental conditions.

• Acceptance and Quality Control
  Inspection procedures for quality assurance follow ISO 3269 to guarantee conformity with accepted product grades and dimensional tolerances as per ISO 4759-1.

• Designation System
  Provides a standardized method for naming tapping screws for clear identification, e.g., "Tapping screw ISO 14587 - ST3,5 × 16 - R" where R indicates a round end type.

Applications

Hexalobular socket raised countersunk (oval) head tapping screws standardized under SIST EN ISO 14587:2012 are widely used in industries requiring reliable and secure fastening solutions, including:

• Automotive manufacturing – Engine assembly, interior fittings, and body components.
• Electronics and electrical equipment – Securing housings and components while allowing controlled torque installation.
• Machinery and equipment – Durable fastening for mechanical parts exposed to vibration and movement.
• Construction and metal fabrication – Assembly of sheet metals and structural panels.
• Precision engineering – Applications demanding high repeatability and minimal damage to fasteners during installation/removal.

This standard supports manufacturers, suppliers, and end-users by providing consistent requirements that facilitate interchangeability and ensure performance in demanding operational environments.

Related Standards

• ISO 1478 – Tapping screw thread profiles.
• ISO 2702 – Heat-treated steel tapping screws and mechanical properties.
• ISO 4759-1 – Tolerances for fasteners, covering bolts, screws, and studs.
• ISO 225 – Symbols and dimension descriptions for fasteners.
• ISO 7721 – Countersunk head screws-head configuration and gauging.
• ISO 10664 – Hexalobular internal driving feature specifications.
• ISO 4042 – Requirements for electroplated coatings on fasteners.
• ISO 10683 – Non-electrolytically applied zinc flake coatings for fasteners.
• ISO 3269 – Acceptance inspection for fasteners.

Summary

SIST EN ISO 14587:2012 delivers a detailed framework for the manufacture, testing, and application of hexalobular socket raised countersunk (oval) head tapping screws. By adhering to this standard, stakeholders ensure product quality, interchangeability, accurate fitment, and long-lasting performance in various industrial fastening applications. The integration with complementary ISO standards further enhances its practical value and global acceptance.

Keywords: hexalobular socket screws, raised countersunk head screws, tapping screws standard, ISO 14587, fastener specifications, thread size ST2.9 to ST6.3, tapping screw dimensions, mechanical properties, corrosion-resistant coatings, fastener quality control, engineering fasteners.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Linsensenk-Blechschrauben mit Innensechsrund
(ISO 14587:2011)Vis à tôle à tête fraisée bombée à six lobes internes
(ISO 14587:2011)Hexalobular socket raised countersunk (oval) head tapping screws (ISO 14587:2011)21.060.10Sorniki, vijaki, stebelni vijakiBolts, screws, studsICS:Ta slovenski standard je istoveten z:EN ISO 14587:2011SIST EN ISO 14587:2012en,fr,de01-januar-2012SIST EN ISO 14587:2012SLOVENSKI
STANDARDSIST EN ISO 14587:20021DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN ISO 14587
February 2011 ICS 21.060.10 Supersedes EN ISO 14587:2001English Version
Hexalobular socket raised countersunk (oval) head tapping screws (ISO 14587:2011)
Vis à tôle à tête fraisée bombée à six lobes internes (ISO 14587:2011)
Linsensenk-Blechschrauben mit Innensechsrund (ISO 14587:2011) This European Standard was approved by CEN on 17 January 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN ISO 14587:2011: ESIST EN ISO 14587:2012

Reference numberISO 14587:2011(E)© ISO 2011
INTERNATIONAL STANDARD ISO14587Second edition2011-02-15Hexalobular socket raised countersunk (oval) head tapping screws Vis à tôle à tête fraisée bombée à six lobes internes
ISO 14587:2011(E) PDF disclaimer This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this area. Adobe is a trademark of Adobe Systems Incorporated. Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.
©
ISO 2011 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body in the country of the requester. ISO copyright office Case postale 56 • CH-1211 Geneva 20 Tel.
+ 41 22 749 01 11 Fax
+ 41 22 749 09 47 E-mail
[e-mail] Web
www.iso.org Published in Switzerlan
...
