Environmental Engineering (EE) - Monitoring and control interface for infrastructure equipment (power, cooling and building environment systems used in telecommunication networks) - Part 12: ICT equipment power, energy and environmental parameters monitoring information model

The present document defines measurement and monitoring of power, energy and environmental parameters for ICT equipment in telecommunications or datacenter or customer premises.
It defines the power, energy and environmental parameters monitoring interface of ICT equipment based on generic ETSI ES 202 336-1 [1] interface so that correlations can be made with ICT equipment parameters (traffic, flowrate, number of connected lines, radio setting, QoS KPI, etc.) in the network management system.
Correlations of monitored data (power, energy consumption and environmental values) with the ICT equipment parameters and settings are not in the scope of the present document.
The monitoring interface covers:
• Internal power consumption measurement on the ICT equipment powered in DC and AC.
• Power consumption measurement external to the ICT equipment (if not implemented internally, e.g. legacy equipment).
• Energy metering based on power consumption measurement.
• Environmental parameters of the ICT equipment (e.g. temperature at air inlet of equipment). The present document defines:
• The minimum set of exchanged information required at the interface, including parameters such as measurement type (e.g. RMS), accuracy, range, etc. and settings such as data acquisition and transmission period, etc. This includes the data preparation, recording and transmission functions.
• The testing method of some parameters and functions.
• Text tables in annexes A and B with data exchange described in "natural language".
• The XML files with tags and variables corresponding to the data in the tables of annexes A and B in complement to general rules defined in ETSI ES 202 336-1 [1] and ETSI ES 202 336-2 [3].

Okoljski inženiring (EE) - Nadzorovalni in krmilni vmesnik za infrastrukturno opremo (elektroenergetski, hladilni in stavbni okoljski sistemi v telekomunikacijskih omrežjih) - 12. del: Oprema za napajanje IKT, energija in okoljski parametri za nadzorovanje informacijskega modela

Ta dokument določa meritev in nadzor napajanja, energije in okoljskih parametrov za opremo IKT v telekomunikacijskih ali podatkovnih središčih oz. prostorih strank.
Opredeljuje nadzorovalni vmesnik za napajanje, energijo in okoljske parametre opreme IKT na podlagi splošnega vmesnika ETSI ES 202 336-1 [1], da je mogoče vzpostaviti korelacije s parametri opreme IKT (promet, pretok, število povezanih linij, radijska nastavitev, kakovost storitve, ključni indikator zmogljivosti (KPI) itd.) v sistemu za upravljanje omrežja.
Korelacije nadzorovanih podatkov (napajanje, poraba energije in okoljske vrednosti) s parametri in nastavitvami opreme IKT niso zajete v področje uporabe tega dokumenta.
Nadzorovalni vmesnik zajema:
• meritev porabe notranje energije v opremi IKT z enosmernim in izmeničnim napajanjem;
• meritev porabe zunanje energije opreme IKT (če ni na voljo notranje napajanje, npr. pri starejši opremi);
• merjenje energije na podlagi izmerjene porabe energije;
• okoljske parametre opreme IKT (npr. temperatura pri vstopni odprtini za zrak na opremi). Ta dokument določa:
• najmanjši nabor izmenjanih informacij, ki se zahtevajo na vmesniku, vključno s parametri, kot so vrsta meritve (npr. RMS), točnost, doseg itd., ter nastavitvami, kot sta obdobji zajemanja in prenosa podatkov itd. To vključuje funkcije za pripravo, zapisovanje in prenos podatkov;
• metodo preskušanja nekaterih parametrov in funkcij;
• besedilne preglednice v dodatkih A in B z izmenjavo podatkov, opisano v »naravnem jeziku«;
• datoteke XML z oznakami in spremenljivkami, ki ustrezajo podatkom v preglednicah dodatkov A in B ter dopolnjujejo splošna pravila, opredeljena v dokumentih ETSI ES 202 336-1 [1] in ETSI ES 202 336-2 [3].
