ASTM B640-12a(2021)

Standard Specification for Welded Copper Tube for Air Conditioning and Refrigeration Service

ABSTRACT
This specification establishes the requirements for welded copper for air conditioning and refrigeration service for use in connections, repairs, and alterations. The material of manufacture shall be sheet or strip of Copper Alloy UNS No. C10100, or C10200, or C12000, or C12200 of such purity and soundness as to be suitable for processing into welded tube to meet the properties prescribed. The product shall be manufactured by forming the material into a tubular shape on a suitable forming mill and welded using an automatic process. The product shall be cold worked to the finished size and wall thickness and subsequently annealed to meet the temper properties specified. The material shall conform to the chemical compositional requirements for the Copper UNS No. designation specified. Tensile strength test, expansion test, microscopical examination, hydrogen embrittlement susceptibility, flattening test, reverse bend test, electromagnetic test, and cleanness test shall be made to conform to specified requirements.
SCOPE
1.1 This specification establishes the requirements for welded copper tube for air conditioning and refrigeration service for use in connections, repairs, and alterations. The tube shall be made from one of the following coppers:
Copper UNS No.
Previously Used Designation
Type of Copper
C10100
OFE
Oxygen-free electronic
C10200
OF
Oxygen-free without-residual oxidants
C12000
DLP
Phosphorus-deoxidized, low-residual phosphorus
C12200
DHP
Phosphorus-deoxidized, high-residual phosphorus
Note 1: Fittings used for soldered or brazed connections in air conditioning and refrigeration systems are described in ASME Standard B 16.22.
Note 2: The assembly of copper tubular systems by soldering is described in Practice B828.
Note 3: Solders for joining copper tubular systems by described in Specification B32. The requirements for acceptable fluxes for these systems are described in Specification B813.
1.2 Copper UNS No. C12200 shall be furnished, unless otherwise specified. The copper tube shall be supplied in annealed coils or drawn temper straight lengths.
1.3 Units—The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-Dec-2020
• ICS: 77.150.30 - Copper products
• Technical Committee: B05 - Copper and Copper Alloys
• Drafting Committee: B05.04 - Pipe and Tube

Relations

• Refers: ASTM E8/E8M-24 - Standard Test Methods for Tension Testing of Metallic Materials
• Effective Date: 01-Jan-2024
• Refers: ASTM B828-23 - Standard Practice for Making Capillary Joints by Soldering of Copper and Copper Alloy Tube and Fittings
• Effective Date: 01-Dec-2023
• Refers: ASTM B846-19a - Standard Terminology for Copper and Copper Alloys
• Effective Date: 01-Aug-2019
• Refers: ASTM B577-19 - Standard Test Methods for Detection of Cuprous Oxide (Hydrogen Embrittlement Susceptibility) in Copper
• Effective Date: 01-Apr-2019
• Refers: ASTM B846-19 - Standard Terminology for Copper and Copper Alloys
• Effective Date: 01-Jan-2019
• Refers: ASTM B601-18a - Standard Classification for Temper Designations for Copper and Copper Alloys—Wrought and Cast
• Effective Date: 01-Oct-2018
• Refers: ASTM E243-18 - Standard Practice for Electromagnetic (Eddy Current) Examination of Copper and Copper-Alloy Tubes
• Effective Date: 01-Jun-2018
• Refers: ASTM B601-18 - Standard Classification for Temper Designations for Copper and Copper Alloys—Wrought and Cast
• Effective Date: 01-Mar-2018
• Refers: ASTM B601-16 - Standard Classification for Temper Designations for Copper and Copper Alloys—Wrought and Cast
• Effective Date: 01-Oct-2016
• Refers: ASTM E8/E8M-16 - Standard Test Methods for Tension Testing of Metallic Materials
• Effective Date: 15-Jul-2016
• Refers: ASTM B828-16 - Standard Practice for Making Capillary Joints by Soldering of Copper and Copper Alloy Tube and Fittings
• Effective Date: 01-Jun-2016
• Refers: ASTM B813-16 - Standard Specification for Liquid and Paste Fluxes for Soldering of Copper and Copper Alloy Tube
• Effective Date: 01-May-2016
• Refers: ASTM B577-16 - Standard Test Methods for Detection of Cuprous Oxide (Hydrogen Embrittlement Susceptibility) in Copper
• Effective Date: 01-Apr-2016
• Refers: ASTM B170-99(2015) - Standard Specification for Oxygen-Free Electrolytic Copper—Refinery Shapes
• Effective Date: 15-Oct-2015
• Refers: ASTM E8/E8M-15 - Standard Test Methods for Tension Testing of Metallic Materials
• Effective Date: 01-Feb-2015

Overview

ASTM B640-12a(2021) is the internationally recognized standard specification for welded copper tube used in air conditioning and refrigeration service. Developed by ASTM, this standard defines material, manufacturing, and performance requirements for copper tube products designed for use in system connections, repairs, and alterations within air conditioning and refrigeration systems. The specification ensures welded copper tubes meet high standards in terms of purity, strength, cleanliness, and reliability, making them suitable for demanding HVACR (Heating, Ventilation, Air Conditioning, and Refrigeration) applications.

Key Topics

• Material Requirements:
  The standard establishes that welded copper tubes should be manufactured from sheet or strip of specific copper alloys, including UNS C10100 (Oxygen-Free Electronic), C10200 (Oxygen-Free), C12000 (Phosphorus-Deoxidized, Low Phosphorus), or C12200 (Phosphorus-Deoxidized, High Phosphorus).

• Manufacturing Process:

  • Copper is formed into tube shape and welded automatically.
  • Tubes are cold worked to final dimensions and annealed as needed to achieve specified temper properties.
  • Products may be delivered in annealed coils or drawn temper straight lengths.

• Performance and Testing:
  To ensure the integrity and suitability of copper tubes, the specification requires:

  • Tensile strength tests for mechanical properties
  • Expansion and flattening tests
  • Microscopical examination (for certain alloys)
  • Hydrogen embrittlement testing
  • Reverse bend tests
  • Electromagnetic (eddy current) testing
  • Cleanliness testing to verify internal residue levels

• Dimensional Control:
  Standards for diameter, wall thickness, roundness, and cut squareness are included to ensure product consistency.

• Identification and Marking:
  All copper tubes must be marked with manufacturer details and relevant specifications for traceability.

Applications

The scope of ASTM B640 applies to welded copper tube in HVACR systems, notably for:

• System Connections:
  Used to route refrigerant or air in split-system, packaged, and ductless air conditioners, heat pumps, and refrigeration units.

• System Repairs and Alterations:
  Ideal for maintenance and retrofit work where reliable copper tube connections are required.

• OEM Equipment:
  Frequently used by equipment manufacturers to ensure compliance with international HVACR material quality standards.

• Construction and Manufacturing:
  Employed by contractors and engineers seeking guaranteed performance for new building installations and system upgrades.

Utilizing copper tube certified to ASTM B640 guarantees high performance, corrosion resistance, and compatibility with industry-recognized methods for joining, cleaning, and testing.

Related Standards

ASTM B640 references and aligns with several important related standards to ensure full-system compatibility:

• ASME B16.22:
  Wrought copper and copper alloy solder joint pressure fittings for HVACR systems.

• ASTM B32:
  Specification for solder metal used in joining copper tubes.

• ASTM B813:
  Specification for acceptable fluxes in soldering processes.

• ASTM B828:
  Practice for making capillary joints by soldering copper tubes and fittings.

• ASTM E8/E8M:
  Test methods for tensile testing of metals.

• ASTM E243:
  Practice for electromagnetic examination of copper tubes.

By adhering to these standards, HVACR professionals and manufacturers ensure safe, efficient, and reliable system performance for both residential and commercial systems.

---

Keywords: welded copper tube, air conditioning, refrigeration, ASTM B640, copper tubing, HVACR, copper alloy C12200, copper tube testing, refrigeration system repairs, copper tube specification
