EN ISO 1234:1997

Split pins (ISO 1234:1997)

Splinte (ISO 1234:1997)

Diese Internationale Norm enthält die Festlegungen über Splinte.

Goupilles fendues (ISO 1234:1997)

La présente Norme internationale prescrit les caractéristiques des goupilles fendues.

Razcepke (ISO 1234:1997)

General Information

• Status: Published
• Publication Date: 31-Oct-1997
• ICS: 21.060.50 - Pins, nails
• Technical Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Drafting Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 04-Feb-2008
• Completion Date: 04-Feb-2008
• Ref Project: SIST EN ISO 1234:2001 - Split pins (ISO 1234:1997)

Overview

EN ISO 1234:1997 / ISO 1234:1997 - Split pins defines the characteristics, dimensions and requirements for split pins (also called cotter pins or goupilles fendues). Prepared by ISO/TC 2 (Fasteners) and published as the second edition in 1997, this standard is the international reference for manufacturing, inspection and designation of split pins and has been adopted as an EN standard in many countries (e.g., SIST EN ISO 1234:2001).

Key Topics

• Scope: Specifies characteristics of split pins including dimensions, materials, workmanship and acceptance criteria.
• Dimensions: Detailed nominal sizes and lengths are given in Table 1 and Table 2 (dimensions in millimetres). Nominal hole sizes cover a range from small (≈0.6 mm) up to larger commercial sizes (up to 20 mm and beyond for commercial lengths).
• Tolerances: Recommended tolerance classes for pin-hole diameters: H13 for nominal size < 1.2 mm and H14 for nominal size > 1.2 mm.
• Materials: Permitted materials include steel (St), copper‑zinc alloy (Cu Zn), copper (Cu), aluminium alloy (Al), austenitic stainless steel (A) and other materials agreed between customer and supplier.
• Mechanical requirement (ductility): Each leg of the split pin shall withstand being bent back upon itself once with no visible fracture at the bend.
• Surface finish & coatings: Parts may be supplied plain, lubricated or with coatings as agreed. For electroplated and phosphate coatings see referenced standards (ISO 4042, ISO 9717).
• Workmanship & acceptability: Pins must be free of burrs and defects; the eye should be as circular as possible and the combined cross‑section of the two legs should be circular. Acceptance inspection follows ISO 3269.
• Designation example: Split pin ISO 1234 – 5 × 50 – St (nominal size 5 mm, length 50 mm, steel).

Applications

• Use in mechanical assemblies to secure clevis pins, bolts and shafts where a simple, removable locking device is required.
• Common across automotive, agricultural machinery, railway, industrial equipment and light engineering.
• Engineers, fastener manufacturers, purchasing/specification teams, quality inspectors and maintenance personnel rely on EN ISO 1234 to ensure interchangeability, safety and correct selection of split pins.

Related Standards

• ISO 3269 - Fasteners: Acceptance inspection
• ISO 4042 - Fasteners: Electroplated coatings
• ISO 9717 - Phosphate conversion coatings for metals

Keywords: EN ISO 1234:1997, ISO 1234:1997, split pins, split pin dimensions, fasteners standard, split pin specifications, split pin materials, split pin tolerances.

Standards Content (Sample)

SLOVENSKI STANDARD
01-julij-2001
1DGRPHãþD
SIST ISO 1234:1995
Razcepke (ISO 1234:1997)
Split pins (ISO 1234:1997)
Splinte (ISO 1234:1997)
Goupilles fendues (ISO 1234:1997)
Ta slovenski standard je istoveten z: EN ISO 1234:1997
ICS:
21.060.50 =DWLþLåHEOML Pins, nails
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL ISO
STANDARD 1234
Second edition
1997-11-01
Split pins
Goupilles fendues
A
Reference number
ISO 1234:1997(E)
ISO 1234:1997(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide
federation of national standards bodies (ISO member bodies). The work of
preparing International Standards is normally carried out through ISO
technical committees. Each member body interested in a subject for which
a technical committee has been established has the right to be represented
on that committee. International organizations, governmental and non-
governmental, in liaison with ISO, also take part in the work. ISO
collaborates closely with the International Electrotechnical Commission
(IEC) on all matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are
circulated to the member bodies for voting. Publication as an International
Standard requires approval by at least 75 % of the member bodies casting
a vote.
International Standard ISO 1234 was prepared by Technical Committee
ISO/TC 2, Fasteners.
This second edition cancels and replaces the first edition (ISO 1234:1976),
which has been technically revised.
©  ISO 1997
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced
or utilized in any form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from the publisher.
International Organization for Standardization
Case postale 56 • CH-1211 Genève 20 • Switzerland
Internet [e-mail]
X.400 c=ch; a=400net; p=iso; o=isocs; s=central
Printed in Switzerland
ii
©
INTERNATIONAL STANDARD  ISO ISO 1234:1997(E)
Split pins
1 Scope
This International Standard specifies the characteristics of split pins.
2 Normative references
The following standards contain provisions which, through reference in this text, constitute provisions of this
International Standard. At the time of publication, the editions indicated were valid. All standards are subject
to revision, and parties to agreements based on this International Standard are encouraged to investigate the
possibility of applying the most recent editions of the standards indicated below. Members of IEC and ISO
maintain registers of currently valid International Standards.
ISO 3269:1988, Fasteners – Acceptance inspection.
1)
ISO 4042:— , Fasteners – Electroplated coatings.
ISO 9717:1990, Phosphate conversion coatings for metals – Method of specifying requirements.
3 Dimensions
See figure 1, table 1 and table 2
Figure 1
1) To be published. (Revision of ISO 4042:1989).
...
