EN 6024:2024

Aerospace series - Screw, 100° countersunk reduced head, offset cruciform recess, close tolerance shank, short thread, in titanium alloy, anodized, MoS2 lubricated - Classification: 1 100 MPa (at ambient temperature)/315 °C - Inch series

This document specifies the characteristics for screws, 100° countersunk reduced head, offset cruciform recess, close tolerance shank, short thread, in titanium alloy, anodized, MoS2 lubricated, classification 1 100 MPa/315 °C, inch series, for aerospace applications.

Luft- und Raumfahrt - 100° Senk-Passschraube mit reduziertem Kopf, Flügelkreuzschlitz, enge Toleranz, kurzes Gewinde, aus Titanlegierung, anodisiert, MoS2-geschmiert - Klasse: 1 100 MPa (bei Raumtemperatur)/315 °C - Zoll-Reihe

Dieses Dokument legt die Eigenschaften für 100°-Senk-Passschrauben mit reduziertem Kopf, Flügelkreuzschlitz, enge Toleranz, kurzes Gewinde, aus Titanlegierung, anodisiert, MoS2 geschmiert, Klasse 1 100 MPa /315 °C , Zoll-Reihe, für Anwendungen in der Luft- und Raumfahrt fest.

Série aérospatiale - Vis à tête fraisée 100° réduite, à empreinte cruciforme déportée, tige à tolérance serrée, filetage court, en alliage de titane, anodisée, lubrifiée au MoS2 - Classification : 1 100 MPa (à température ambiante)/315 °C - Série en inches

Le présent document spécifie les caractéristiques des vis à tête fraisée 100° réduite, à empreinte cruciforme déportée, tige à tolérance serrée, filetage court, en alliage de titane, anodisées, lubrifiées au MoS2, de classification 1 100 MPa/315 °C, série en inches, pour applications aérospatiales.
