EN 2699:2019

Aerospace series - Aluminium alloy (5086) - Annealed and straightened (H111) - Drawn bar - 6 mm ≤ D ≤ 50 mm

This document specifies the requirements relating to:
Aluminium alloy (5086)
Annealed and straightened (H111)
Drawn bar
6 mm ≤ D ≤ 50 mm
for aerospace applications.

Luft- und Raumfahrt - Aluminiumlegierung (5086) - Geglüht und gerichtet (H111) - Stangen, gezogen - 6 mm ≤ D ≤ 50 mm

Série aérospatiale - Alliage d'aluminium (5086) - Recuit et dressé (H111) - Barres étirées - 6 mm ≤ D ≤ 50 mm

Aeronavtika - Aluminijeva zlitina (5086) - Žarjena in poravnana (H111) - Vlečene palice - 6 mm ≤ D ≤ 50 mm

Ta dokument določa zahteve, ki se nanašajo na:
aluminijevo zlitino (5086),
žarjeno in poravnano (H111),
vlečene palice,
6 mm ≤ D ≤ 50 mm,
za uporabo v aeronavtiki.

General Information

• Status: Published
• Publication Date: 26-Mar-2019
• Withdrawal Date: 29-Sep-2019
• ICS: 49.025.20 - Aluminium
• Technical Committee: ASD-STAN - Aerospace
• Drafting Committee: ASD-STAN/D 4 - Metallic
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 27-Mar-2019
• Completion Date: 27-Mar-2019
• Ref Project: SIST EN 2699:2019 - Aerospace series - Aluminium alloy (5086) - Annealed and straightened (H111) - Drawn bar - 6 mm ≤ D ≤ 50 mm

Overview

EN 2699:2019 (CEN) is a European aerospace material standard that specifies requirements for aluminium alloy 5086 in the H111 (annealed and straightened) condition, supplied as drawn bars with diameters 6 mm ≤ D ≤ 50 mm. It is part of the Aerospace series of metallic material standards and is intended to ensure consistent chemistry, form, delivery condition and testing for aerospace applications.

Key Topics

• Material and form
  • Aluminium alloy 5086, produced as drawn bars (bar form) in the diameter range 6–50 mm.
  • Delivery condition H111 (annealed and straightened); delivery condition code U.
• Chemical composition
  • Limits are specified for major elements (e.g., Si, Fe, Cu, Mn, Mg, Cr, Ti, Zr and others). Notably, Mg is specified in the ~3.5–4.5% range and maximum limits are given for elements such as Si, Fe and Cu.
• Mechanical and test requirements
  • Mechanical properties referenced include proof stress (Rp0.2), tensile strength (Rm) and elongation (A%); test direction is longitudinal (L) and tests are normally at ambient temperature.
  • Hardness is listed (informative) and some inspection and dimensional checks are required.
• Production and dimensional control
  • Bars are produced by drawing; dimensional tolerances and shape classes are linked to EN 2044 / EN 2045 / EN 2046 depending on round, square or hexagonal sections.
• Qualification and inspection
  • Product qualification programs and inspection criteria (marking, dimensional inspection) are to be agreed between manufacturer and purchaser where applicable.

Applications

EN 2699:2019 is used wherever consistent, aerospace-grade aluminium 5086 drawn bars are required. Typical practical uses:

• Structural components and fittings in aircraft where corrosion resistance and good mechanical stability are needed
• Shafts, pins and machined components manufactured from drawn bar stock
• Procurement and specification for suppliers and buyers of aerospace aluminium bar
• Quality assurance, incoming inspection and material certification processes

Users of this standard include materials engineers, procurement specialists, aerospace manufacturers, suppliers of aluminium bar, and certification/quality teams.

Related Standards

• EN 2044 / EN 2045 / EN 2046 - dimensional and tolerance standards for round, square and hexagonal aluminium bars
• EN 4400-3 - aerospace technical specification for aluminium bar and section
• EN 4258 - organization of aerospace metallic material standards
• EN 4500-002 - drafting rules for aluminium material standards

Keywords: EN 2699:2019, aluminium alloy 5086, H111, drawn bar, aerospace standard, CEN, 6–50 mm, chemical composition, mechanical properties, EN 2044.
