EN 4708-101:2017

Aerospace series - Sleeving, heat-shrinkable, for binding, insulation and identification - Part 101: Polyolefin sleeving - Operating temperatures -55 °C to 135 °C - Product standard

This European Standard specifies the required characteristics for four types of heat-shrinkable polyolefin sleevings for use in aircraft electrical systems at operating temperatures between − 55 °C and 135 °C.
Type A:   Very flexible, flame retarded, shrink ratio 2:1
This sleeving has very good flexibility, is flame retarded and will shrink at low temperatures. It is suitable where sensitive components and delicate wiring need protection from excessive heat during shrinking.
Type B:   Flexible, flame retarded, shrink ratio 2:1, 3:1 and 4:1
This sleeving is flexible and flame retarded. It is suitable for general purposes and is available with high shrink ratios.
Type C:   Flexible, not flame retarded, shrink ratio 2:1 and 3:1
This sleeving is flexible and not flame retarded and is available in two shrink ratios.
Type D:   Semi-rigid, flame retarded, shrink ratio 2:1
This sleeving is semi-rigid and flame retarded. It is suitable where strain relief and mechanical support are required

Luft- und Raumfahrt - Wärmeschrumpfender Schlauch zur Befestigung, Isolierung und Identifizierung - Teil 101: Polyolefin Schlauch - Temperaturbereich -55 °C bis 135 °C - Produktnorm

Série aérospatiale - Manchons thermorétractables, de jonction, isolement et identification - Partie 101: Gaine polyoléfine - Températures d'utilisation -55 °C à 135 °C - Norme de produit

Aeronavtika - Toplotno skrčljiva cev za utrjevanje, izolacijo in identifikacijo - 101. del: Poliolefinske cevi - Delovne temperature od –55 °C do 135 °C - Standard za proizvod

Ta evropski standard določa zahtevane značilnosti za štiri vrste toplotno skrčljivih poliolefinskih cevi za uporabo v letalih električnih sistemih pri delovni temperaturi med −55 °C in 135 °C.
Vrsta A: Zelo prožna, ognjeodporna, razmerje krčenja 2:1
Ta cev je zelo prožna, ognjeodporna in se krči pri nizkih temperaturah. Primerna je za zaščito občutljivih komponent in napeljave pred prekomerno toploto med krčenjem.
Vrsta B: Prožna, ognjeodporna, razmerje krčenja 2:1, 3:1 in 4:1
Ta cev je prožna in ognjeodporna. Primerna je za splošno uporabo in je na voljo z visokimi razmerji krčenja.
Vrsta C: Prožna, ni ognjeodporna, razmerje krčenja 2:1 in 3:1
Ta cev je prožna in ni ognjeodporna ter je na voljo v dveh razmerjih krčenja.
Vrsta D: Poltoga, ognjeodporna, razmerje krčenja 2:1
Ta cev je poltoga in ognjeodporna. Primerna je, kjer sta potrebni razbremenitev in mehanska podpora. Te cevi so običajno dobavljive z notranjimi premeri do 102 mm za razmerji krčenja 2:1 in 4:1 ter do 39 mm za razmerje krčenja 3:1 in v naslednjih barvah za vrsto B: črna, rjava, rdeča, rumena, zelena, modra, oranžna, vijolična, siva, bela in zelena/rumena. Vrsti A in D sta samo črne barve.
Vrsta C je prosojna, ni ognjeodporna in ne izpolnjuje zahtev glede vnetljivosti iz standarda EN 4708-001.
Na voljo so lahko tudi druge velikosti in barve, ki niso posebej navedene v tem standardu. Upoštevati je treba, da se te postavke skladajo s tem standardom, če so skladne z zahtevami za lastnosti, navedenimi v preglednicah 5, 6 in 7, razen z zahtevami za mere in težo.

General Information

• Status: Published
• Publication Date: 07-Mar-2017
• Withdrawal Date: 29-Sep-2017
• ICS: 49.060 - Aerospace electric equipment and systems
• Technical Committee: ASD-STAN - Aerospace
• Drafting Committee: ASD-STAN/D 2 - Electrical
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 08-Mar-2017
• Completion Date: 08-Mar-2017
• Ref Project: SIST EN 4708-101:2017 - Aerospace series - Sleeving, heat-shrinkable, for binding, insulation and identification - Part 101: Polyolefin sleeving - Operating temperatures -55 °C to 135 °C - Product standard

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.SURL]YRGLuft- und Raumfahrt - Wärmeschrumpfender Schlauch zur Befestigung, Isolierung und Identifizierung - Teil 101: Polyolefin Schlauch - Temperaturbereich -55 °C bis 135 °C - ProduktnormSérie aérospatiale - Manchons thermorétractables, de jonction, isolement et identification - Partie 101: Gaine polyoléfine - Températures d'utilisation -55 °C à 135 °C - Norme de produitAerospace series - Sleeving, heat-shrinkable, for binding, insulation and identification - Part 101: Polyolefin sleeving - Operating temperatures -55 °C to 135 °C - Product standard49.060Aerospace electric equipment and systemsICS:Ta slovenski standard je istoveten z:EN 4708-101:2017SIST EN 4708-101:2017en,fr,de01-maj-2017SIST EN 4708-101:2017SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 4708-101
March
t r s y ICS
v {ä r x r English Version
Aerospace series æ Sleevingá heatæshrinkableá for bindingá insulation and identification æ Part
s r sã Polyolefin sleeving æ Operating temperatures æ w w
¹C to
s u w
¹C æ Product standard Série aérospatiale æ Manchons thermorétractablesá de jonctioná isolement et identification æ Partie
s r sã Gaine polyoléfine æ Températures d 5utilisation æ w w
¹C à
s u w
¹C æ Norme de produit
Luftæ und Raumfahrt æ Wärmeschrumpfender Schlauch zur Befestigungá Isolierung und Identifizierung æ Teil
s r sã Polyolefin Schlauch æ Temperaturbereich æ w w
¹C bis
s u w
¹C æ Produktnorm This European Standard was approved by CEN on
{ January
t r s yä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s y CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
v y r zæ s r sã t r s y ESIST EN 4708-101:2017

«
w w
¹C and
s u w
¹Cä Type A: Very flexible, flame retarded, shrink ratio 2:1 This sleeving has very good flexibility, is flame retarded and will shrink at low temperatures. It is suitable where sensitive components and delicate wiring need protection from excessive heat during shrinking.
Type B: Flexible, flame retarded, shrink ratio 2:1, 3:1 and 4:1 This sleeving is flexible and flame retarded. It is suitable for general purposes and is available with high shrink ratios.
Type C: Flexible, not flame retarded, shrink ratio 2:1 and 3:1 This sleeving is flexible and not flame retarded and is available in two shrink ratios. Type D: Semi-rigid, flame retarded, shrink ratio 2:1 This sleeving is semi-rigid and flame retarded. It is suitable where strain relief and mechanical support are required These sleevings are normally supplied with internal diameters up to 102 mm for shrink ratios of 2:1 and 4:1 and up to 39 mm for shrink ratios of 3:1 and in the following colours for type B, black, brown, red, yellow, green, blue, orange, violet, grey, white and green/yellow. Types A and D are black only. Type C is transparent, is not flame retarded and does not meet the flammability requirements of EN 4708-001. Sizes or colours other than those specifically listed in this standard may be available. These items shall be considered to comply with this standard if they comply with the property requirements listed in Tables 5, 6 and 7 except for dimensions and mass. 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies.
EN 3909, Aerospace series — Test fluids and test methods for electrical and optical components and sub-assemblies EN 4708-001, Aerospace series — Sleeving, heat-shrinkable, for binding, insulation and identification — Part 001: Technical specification IEC 60684-1:2011, Specification for flexible insulating sleeving — Part 1: Definitions and general requirements 1)
1) Published by: IEC International Electrotechnical Commission. http://www.iec.ch/ SIST EN 4708-101:2017

2) Published by: Department of Defense (DoD). http://www.defenselink.mil/ 3) Published by: SAE National (US) Society of Automotive Engineers. http://www.sae.org/ 4) Published by: ASTM National (US) American Society for Testing and Materials. http://www.astm.org/ SIST EN 4708-101:2017
...
