Optical fibre cables - Part 1-401: Generic specification - Basic optical cable test procedures - Electrical test methods - Short-circuit test (for OPGW, OPPC and OPAC), Method H1

IEC 60794-1-401:2021 applies to the short-circuit test intended to assess the performance of an optical ground wire (OPGW) or optical phase conductor (OPPC) under typical short-circuit, or the impact on the performance of optical attached cable (OPAC) under short-circuit current on the messenger wire. This first edition cancels and replaces the first edition of IEC 60794-1-24 published in 2014. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) OPPC is included;
b) the test methods have been updated.

Câbles à fibres optiques - Procédures fondamentales d’essais des câbles optiques - Partie 401: Méthodes d’essais électriques - Essai de court-circuit (pour les OPGW, les OPPC et les OPAC), Méthode H1

IEC 60794-1-401:2021 s’applique à l'essai de court-circuit destiné à évaluer la performance d'un câble de garde à fibres optiques (OPGW) ou d’un conducteur de phase à fibres optiques (OPPC) en cas de court-circuit typique, ou l'impact sur la performance d'un câble optique attaché (OPAC) en cas de courant de court-circuit sur le fil porteur. Cette première édition annule et remplace la première édition de l'IEC 60794-1-24 publiée en 2014. Cette édition constitue une révision technique.Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
L’OPPC est inclus;
les méthodes d'essais ont été mises à jour.
