IEC 62317-2:2010

Ferrite cores - Dimensions - Part 2: Pot-cores for use in telecommunications, power supply, and filter applications

IEC 62317-2:2010 specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of pot-cores made of ferrite, and the dimensional limits for coil formers to be used with them. The selection of core sizes for this standard is based on the philosophy of including those sizes which are industrial standards, either by inclusion in a national standard, or by broad-based use in industry. See IEC 62317-1 for more detail concerning the philosophy of selecting core sizes to be included. This first edition cancels and replaces the fourth edition of IEC 60133 published in 2000. The main changes with respect to the previous edition of IEC 60133 are listed below:
- changed "e dimension" of P4,6/3,1 in Table 6 from 3,20 Max. to 3,40 Max.;
- removed "derived standards" from Annex B (informative) in the fourth edition of IEC 60133;
- changed the name of core parts in Subclause 3.1.2 from "Grooves" to "Wire-ways" in accordance with IEC 62317-1 Subclause 5.6.

Noyaux ferrites - Dimensions - Partie 2: Circuits magnétiques en pots utilisés dans des applications de télécommunications, d'alimentation électrique et de filtre

La CEI 62317-2:2010 spécifie les dimensions qui présentent une importance pour l'interchangeabilité mécanique d'une gamme préférentielle de circuits magnétiques en pots réalisés en oxydes magnétiques, ainsi que les limites dimensionnelles pour des carcasses à utiliser avec ces pots. Le choix des tailles des noyaux pour la présente norme est fondé sur la philosophie consistant à introduire les tailles qui correspondent à des normes industrielles, soit par une prise en compte dans une norme nationale, soit par le biais d'une utilisation à grande échelle dans l'industrie. Voir la CEI 62317-1 pour plus de détails concernant ce principe de choix des tailles de noyaux à inclure. La présente édition annule et remplace la quatrième édition de la CEI 60133 publiée en 2000. Les principales modifications par rapport à la précédente édition de la CEI 60133 sont énumérées ci-dessous:
- au Tableau 6, changer la dimension "e" du P4,6/3,1 de 3,20 Max. à 3,40 Max.;
- enlever l'Annexe B (informative) "Normes dérivées" dans l'édition quatre de la CEI 60133;
- dans la Paragraphe 3.1.2 du texte anglais, changer "Grooves" en "Wire-ways" conformément à la Paragraphe 5.6 de la CEI 62317-1.
