IEC 61375-2-8:2021

Electronic railway equipment - Train communication network (TCN) - Part 2-8: TCN conformance test

IEC 61375-2-8:2021 applies to all equipment and devices implemented according to IEC 61375-2-3:2015, IEC 61375-2-5:2014 and IEC 61375-3-4:2014, i.e. it covers the procedures to be applied to such equipment and devices when the conformance should be proven. The applicability of this document to a TCN implementation allows for individual conformance checking of the implementation itself, and is a pre-requisite for further interoperability checking between different TCN implementations.

Matériel électronique ferroviaire - Réseau embarqué de train (TCN) - Partie 2-8: Essai de conformité TCN

IEC 61375-2-8:2021 s'applique à l'ensemble des équipements et dispositifs mis en œuvre conformément à l'IEC 61375-2-3:2015, l'IEC 61375-2-5:2014 et l'IEC 61375-3-4:2014, c'est-à-dire qu'elle couvre les modes opératoires à appliquer à ces équipements et dispositifs dont il convient de démontrer la conformité.

General Information

• Status: Published
• Publication Date: 24-Oct-2021
• ICS: 45.060.01 - Railway rolling stock in general
• Technical Committee: TC 9 - Electrical equipment and systems for railways
• Drafting Committee: WG 43 - TC 9/WG 43
• Current Stage: PPUB - Publication issued
• Start Date: 25-Oct-2021
• Completion Date: 05-Nov-2021

Overview

IEC 61375-2-8:2021 - "Electronic railway equipment - Train communication network (TCN) - Part 2‑8: TCN conformance test" defines the conformance test procedures for TCN equipment. It applies to devices implemented according to IEC 61375-2-3:2015, IEC 61375-2-5:2014 and IEC 61375-3-4:2014. The standard enables formal verification that an Item Under Test (IUT) meets protocol, interface and behaviour requirements, which is a pre‑requisite for interoperability between different TCN implementations.

Key Topics and Requirements

• Conformance approach and boundaries: Defines how conformance testing is scoped, including test categories (basic interconnection, capability, behaviour, and conformance resolution tests) and the mapping of IUT types to test suites.
• PICS pro‑forma: Use of Protocol Implementation Conformance Statements (PICS) to declare IUT capabilities and guide test applicability.
• Basic interface and physical layer tests: Inspection and electrical/physical checks for Ethernet interfaces, waveform and auto‑sensing/crossover behavior.
• Communication protocol tests: Simple UDP/TCP payload tests and long‑term reliability checks to validate protocol handling by End Devices.
• Communication reliability and robustness: Burst immunity, interface isolation and other resilience tests for stable operation under adverse conditions.
• Test suites for device classes: Extensive, structured test cases for:
  • End Devices (IEC 61375-2-3, -2-5, -3-4 related test cases)
  • ECN‑equipped consists (switch management, priority levels, rate limiting, VLAN/tagging, DHCP, DNS, NTP, SNMP)
  • ETBN (Ethernet Train Backbone Network) functions (link aggregation, TTDP/HELLO, TOPOLOGY frames, unicast/multicast forwarding)
• Management and service interfaces: Tests include DHCP address assignment, DNS/TCN‑URI resolution, SNMP/network management, switch management and optional interfaces (ECSP, TTDB manager, ETBN control).
• Conformance assessment process: Criteria for verdicts, analysis of results, and relation to interoperability and performance testing.

Practical Applications and Who Uses It

• Railway equipment manufacturers - validate that TCN hardware and software implementations conform to IEC TCN specifications before product release.
• Independent test laboratories and certification bodies - execute standardized test suites and PICS-based conformance assessments.
• System integrators and operators - confirm that components will interoperate reliably on train networks (ECN and ETBN).
• Network and firmware engineers - use the test definitions to design robust Ethernet-based TCN products (switches, end devices, backbone elements).

Related Standards

• IEC 61375-2-3:2015 (End Device definitions)
• IEC 61375-2-5:2014
• IEC 61375-3-4:2014
• IEEE Ethernet standards (referenced for waveform and electrical tests)

Keywords: IEC 61375-2-8, TCN conformance test, Train Communication Network, railway Ethernet testing, TCN interoperability, ECN, ETBN, PICS, DHCP, DNS, SNMP, NTP, multicast, link aggregation.

Standards Content (Sample)
