IEC 61010-2-030:2023
(Main)Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 2-030: Particular requirements for equipment having testing or measuring circuits
Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 2-030: Particular requirements for equipment having testing or measuring circuits
IEC 61010-2-030:2023 specifies safety requirements for equipment having testing or measuring circuits which are connected for test or measurement purposes to devices or circuits outside the measurement equipment itself. These include measuring circuits which are part of electrical test and measurement equipment, laboratory equipment, or process control equipment. These circuits in equipment have additional protective means between the circuit and an operator. This third edition cancels and replaces the second edition published in 2017. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) in 1.2.1, requirements for protection against hazards which could occur from reading a voltage have been added to the scope;
b) Clause 2, all normative references have been dated and new normative references have been added;
c) in 4.3.2.5, requirements for power supply have been modified;
d) in 4.3.2.6, requirements for inputs/outputs have been modified;
e) in 4.4.2.101, a new subclause about surge protective devices has been added;
f) in 5.1.5.101.2, minimum ratings for voltage of measuring terminals are required;
g) Subclause 6.6.101 modifies 6.6.101 and 6.6.102 of previous edition:
1) in 6.6.101.1, insulating material of group I may be allowed for determination of creepage distances of measuring circuit terminals;
2) In 6.6.101.2, clearances and creepage distances up to 3 000 V for measuring circuit terminals in unmated position have been defined;
3) in 6.6.101.3, requirements for measuring circuit terminals in partially mated position have been specified;
4) in 6.6.101.4, requirements for measuring circuit terminals in mated position have been specified;
5) Subclause 6.6.101.5 replaces 6.6.102;
h) Subclause 9.101 to consider the protection of measuring circuits against the spread of fire and arc flash has been added and Table 102 has been replaced by Table K.101;
i) in 9.101.2, relocation of 101.3 of previous edition;
j) in 9.101.3, relocation of 101.4 of previous edition, extension to measurement category II and reference to IEC 61000-4-5 for tests;
k) in 14.101, relocation of 14.102 and 14.101 of previous edition has been removed;
l) in 101.3, relocation of 101.5 of previous edition, and more requirements added against hazard occurring from reading a voltage value;
m) in K.2.1, another method for determination of clearances of secondary circuits is proposed;
n) in K.3.2, new Table K.15 and Table K.16 for clearance calculation;
o) in K.101.4.1, new Table K.103 and Table K.104 replace Table K.102, Table K.103 and Table K.104;
p) in K.101.4, the subclause has been reviewed; Tables and tests for solid insulation have been modified; Table K.105 replaces Table K.9;
q) Table K.101, replacement of Table K.106;
r) Clause K.4, redraft of the clause to propose a method for determination of Ut for circuits which reduce transient overvoltages;
s) Annex AA: Figure AA.1 has been redesigned;
t) Annex EE: addition of a new informative annex for determination of clearances for Table 101.
It has the status of a group safety publication in accordance with IEC Guide 104.
Exigences de sécurité pour appareils électriques de mesurage, de régulation et de laboratoire - Partie 2-030: Exigences particulières pour les appareils équipés de circuits d'essai ou de mesure
L'IEC 61010-2-030:2023 spécifie les exigences de sécurité pour les appareils équipés de circuits d’essai ou de mesure qui sont reliés à des fins d’essai ou de mesurage à des dispositifs ou à des circuits extérieurs à l’appareil de mesure même. Ceux-ci comprennent les circuits de mesure qui font partie d’appareils électriques d’essai et de mesure, d’appareils de laboratoire ou d’appareils de contrôle de processus. Ces circuits dans l’appareil disposent des moyens de protection additionnels entre le circuit et un opérateur. Cette troisième édition annule et remplace la deuxième édition publiée en 2017. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l’édition précédente:
a) au paragraphe 1.2.1, les exigences relatives à la protection contre les dangers susceptibles de survenir lors de la lecture d’une tension ont été ajoutées au domaine d’application;
b) à l’Article 2, toutes les références normatives ont été datées et de nouvelles références normatives ont été ajoutées;
c) au paragraphe 4.3.2.5, les exigences relatives à l’alimentation électrique ont été modifiées;
d) au paragraphe 4.3.2.6, les exigences relatives aux entrées/sorties ont été modifiées;
e) au paragraphe 4.4.2.101, un nouveau paragraphe concernant les dispositifs de protection contre les surtensions a été ajouté;
f) au paragraphe 5.1.5.101.2, des valeurs assignées minimales de tension des bornes des circuits de mesure sont exigées;
g) le paragraphe 6.6.101 modifie les paragraphes 6.6.101 et 6.6.102 de l’édition précédente:
1) au paragraphe 6.6.101.1, les matériaux isolants du groupe I peuvent être admis pour la détermination des distances d’isolement des bornes des circuits de mesure;
2) au paragraphe 6.6.101.2, les distances d’isolement et les lignes de fuite inférieures à 3 000 V pour les bornes des circuits de mesure en position découplée ont été définies;
3) au paragraphe 6.6.101.3, des exigences relatives aux bornes des circuits de mesure en position partiellement couplée ont été spécifiées;
4) au paragraphe 6.6.101.4, des exigences relatives aux bornes des circuits de mesure en position couplée ont été spécifiées;
5) le paragraphe 6.6.101.5 remplace le paragraphe 6.6.102;
h) le paragraphe 9.101 a été ajouté pour prendre en compte la protection des circuits de mesure contre la propagation du feu et les arcs électriques et le Tableau 102 a été remplacé par le Tableau K.101;
i) le paragraphe 101.3 de la précédente édition a été déplacé en 9.101.2;
j) le paragraphe 101.4 de la précédente édition a été déplacé au paragraphe 9.101.3. Ce paragraphe a été étendu à la catégorie de mesure II et fait référence à l’IEC 61000-4-5 pour les essais;
k) le paragraphe 14.102 a été déplacé au paragraphe 14.101 et le paragraphe 14.101 de l’édition précédente a été supprimé;
l) le paragraphe 101.5 de l’édition précédente a été déplacé au paragraphe 101.3 et des exigences supplémentaires ont été ajoutées contre les dangers liés à la lecture d’une valeur de tension;
m) au paragraphe K.2.1, une autre méthode de détermination des distances d’isolement des circuits secondaires a été proposée;
n) au paragraphe K.3.2, le Tableau K.15 et le Tableau K.16 ont été ajoutés pour le calcul de la distance d’isolement;
o) au paragraphe K.101.4.1, les nouveaux tableaux (Tableau K.103 et Tableau K.104) remplacent le Tableau K.102, le Tableau K.103 et le Tableau K.104;
p) le paragraphe K.101.4 a été révisé. Les tableaux et les essais relatifs à l’isolation solide ont été modifiés; Le Tableau K.105 remplace le Tableau K.9;
q) le Tableau K.101 remplace le Tableau K.106;
r) l’Article K.4 a fait l’objet d’une refonte pour proposer une méthode de détermination de Ut pour les circuits qui réduisent les surtensions transitoires;
s) en Annexe AA: la Figure AA.1 a été modifiée;
t) en Annexe EE: une nouvelle annexe informative a été ajoutée pour la détermination des distances d’isolement pour le Tabl
General Information
Relations
Overview
IEC 61010-2-030:2023 (Edition 3.0) is the IEC safety standard that defines particular safety requirements for equipment having testing or measuring circuits. It applies to measuring circuits that connect, for test or measurement purposes, to devices or circuits outside the measurement equipment itself - including electrical test & measurement equipment, laboratory instruments and process‑control equipment. This third edition (2023) cancels and replaces the 2017 edition and constitutes a technical revision with multiple updates addressing clearances, creepage, surge protection, terminal ratings, fire/arc‑flash protection and more.
Key topics and technical requirements
- Scope & object: Protective measures for measuring circuits connected to external circuits; verification and environmental conditions.
- Protection against electric shock: Basic, supplementary and reinforced insulation; protective bonding; limits for accessible parts; testing in a SINGLE FAULT CONDITION.
- Measuring circuit terminals: New and revised rules for clearances and creepage - defined for unmated, partially mated and mated positions, including values up to 3 000 V and new minimum voltage ratings for measuring terminals.
- Surge and transient protection: Addition of requirements and tests for surge protective devices (reference to IEC 61000-4-5 for surge tests).
- Fire and arc‑flash protection: New subclause to consider spread of fire and arc flash from measuring circuits; related tables updated (Table K.101 and others).
- Constructional & testing requirements: Updated reference test conditions, sequence of tests, voltage test procedures, insulation testing, and requirements for power supply, inputs/outputs and connectors.
- Methods & annexes: Revised methods for determining clearances, determination of Ut for circuits that reduce transient overvoltages, plus updated informative annexes (AA, EE) and extensive updates in Clause K.
Practical applications and users
This standard is essential for:
- Equipment designers and manufacturers of multimeters, insulation testers, oscilloscopes, bench instruments, test fixtures and laboratory analyzers.
- Safety engineers and compliance teams preparing CE/CB/IECEE documentation or performing risk assessments and type testing.
- Test labs and certification bodies evaluating electrical safety of measuring and test equipment.
- System integrators and maintenance professionals ensuring safe connections between measurement equipment and external circuits.
Using IEC 61010-2-030:2023 helps ensure safe operator protection, consistent terminal ratings and robust immunity against transients, arc flash and fire risks when measuring or testing live circuits.
Related standards
- IEC 61010-1 (General requirements for measurement, control and laboratory equipment) - referenced and included in the extended version.
- IEC 61000-4-5 (Surge immunity testing) - referenced for surge protective device testing.
- IEC Guide 104 - standard’s status as a group safety publication.
Keywords: IEC 61010-2-030:2023, safety requirements, measuring circuits, test and measurement equipment, clearances, creepage distances, surge protection, arc flash, laboratory equipment.
