Standards Content (Sample)
INTERNATIONAL IEC
STANDARD
60335-2-24
Sixth edition
2002-10
Household and similar electrical appliances –
Safety –
Part 2-24:
Particular requirements for refrigerating
appliances, ice-cream appliances and ice-makers
Appareils électrodomestiques et analogues –
Sécurité –
Partie 2-24:
Règles particulières pour les appareils de réfrigération,
les appareils de glaces à la crème et les fabriques de glace
Reference number
Publication numbering
As from 1 January 1997 all IEC publications are issued with a designation in the
60000 series. For example, IEC 34-1 is now referred to as IEC 60034-1.
Consolidated editions
The IEC is now publishing consolidated versions of its publications. For example,
edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the base publication, the
base publication incorporating amendment 1 and the base publication incorporating
amendments 1 and 2.
Further information on IEC publications
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology. Information relating to
this publication, including its validity, is available in the IEC Catalogue of
publications (see below) in addition to new editions, amendments and corrigenda.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is also available from the following:
• IEC Web Site (www.iec.ch)
• Catalogue of IEC publications
The on-line catalogue on the IEC web site (http://www.iec.ch/searchpub/cur_fut.htm)
enables you to search by a variety of criteria including text searches, technical
committees and date of publication. On-line information is also available on
recently issued publications, withdrawn and replaced publications, as well as
corrigenda.
• IEC Just Published
This summary of recently issued publications (http://www.iec.ch/online_news/
justpub/jp_entry.htm) is also available by email. Please contact the Customer
Service Centre (see below) for further information.
• Customer Service Centre
If you have any questions regarding this publication or need further assistance,
please contact the Customer Service Centre:
Email: custserv@iec.ch
Tel: +41 22 919 02 11
Fax: +41 22 919 03 00
INTERNATIONAL IEC
STANDARD
60335-2-24
Sixth edition
2002-10
Household and similar electrical appliances –
Safety –
Part 2-24:
Particular requirements for refrigerating
appliances, ice-cream appliances and ice-makers
Appareils électrodomestiques et analogues –
Sécurité –
Partie 2-24:
Règles particulières pour les appareils de réfrigération,
les appareils de glaces à la crème et les fabriques de glace
IEC 2002 Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission, 3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, Switzerland
Telephone: +41 22 919 02 11 Telefax: +41 22 919 03 00 E-mail: inmail@iec.ch Web: www.iec.ch
PRICE CODE
Commission Electrotechnique Internationale
XB
International Electrotechnical Commission
Международная Электротехническая Комиссия
For price, see current catalogue
– 2 – 60335-2-24 © IEC:2002(E)
CONTENTS
FOREWORD . 4
INTRODUCTION .6
1 Scope . 7
2 Normative references. 8
3 Definitions . 8
4 General requirement .10
5 General conditions for the tests .10
6 Classification .12
7 Marking and instructions .12
8 Protection against access to live parts .15
9 Starting of motor-operated appliances .15
10 Power input and current.16
11 Heating.16
12 Void .19
13 Leakage current and electric strength at operating temperature .19
14 Transient overvoltages.20
15 Moisture resistance.20
16 Leakage current and electric strength .21
17 Overload protection of transformers and associated circuits.22
18 Endurance .22
19 Abnormal operation.22
20 Stability and mechanical hazards.24
21 Mechanical strength.26
22 Construction .27
23 Internal wiring.35
24 Components .35
25 Supply connection and external flexible cords.36
26 Terminals for external conductors .37
27 Provision for earthing.38
28 Screws and connections .38
29 Clearances, creepage distances and solid insulation .38
30 Resistance to heat and fire .38
31 Resistance to rusting .39
32 Radiation, toxicity and similar hazards .39
Annexes.42
Annex C Ageing test on motors .41
Annex D Alternative requirements for protected motor units .41
Annex AA (normative) Locked-rotor test of fan motors.43
Annex BB (informative) Method for accumulation of frost .45
Bibliography.48
60335-2-24 IEC:2002(E) – 3 –
Figure 101 – Apparatus for spillage test 40
Figure 102 – Detail of scratching tool tip .41
Figure AA.1 – Supply circuit for locked-rotor test of a single-phase fan motor .44
Figure BB.1 – Diagram of apparatus for water evaporation for accumulation of frost .46
Figure BB.2 – Apparatus for water evaporation and for accumulation of frost .47
Table 101 – Maximum temperatures for motor-compressors.18
Table 102 – Refrigerant flammability parameters.34
