ISO/IEC/IEEE 8802-1Q:2024/Amd 40:2026

• Status: Published
• Publication Date: 23-Aug-2026
• ICS: 35.110 - Networking
• Technical Committee: ISO/IEC JTC 1/SC 6 - Telecommunications and information exchange between systems
• Drafting Committee: ISO/IEC JTC 1/SC 6 - Telecommunications and information exchange between systems
• Current Stage: 6060 - International Standard published
• Start Date: 24-Aug-2026
• Due Date: 26-Jun-2028
• Completion Date: 24-Aug-2026

• Amends: ISO/IEC/IEEE 8802-1Q:2024 - Telecommunications and exchange between information technology systems — Requirements for local and metropolitan area networks — Part 1Q: Bridges and bridged networks
• Effective Date: 28-Jun-2025

Overview

ISO/IEC/IEEE 8802-1Q:2024/Amd 40:2026 is an international standard developed through the collaborative efforts of ISO, IEC, and IEEE. This amendment, also known as IEEE Std 802.1Qdy™-2025, specifies the use of YANG data models for the Multiple Spanning Tree Protocol (MSTP) in local and metropolitan area networks (LAN/MAN). MSTP enables the efficient management of network bridges and VLANs, supporting reliable and resilient Ethernet networks essential for mission-critical applications such as industrial automation.

The amendment enhances the IEEE 802.1Q family of standards by providing models for the configuration and status reporting of MSTP and Rapid Spanning Tree Protocol (RSTP) components using YANG, a modern data modeling language widely adopted for network management and automation.

Key Topics

• YANG Data Models: Introduction of YANG schemas for MSTP and RSTP, enabling standardized, programmatic management of bridges and bridged networks.
• Network Automation: Facilitation of automated network configuration, monitoring, and troubleshooting through interoperable YANG models compatible with various network automation frameworks.
• MSTP Configuration and Reporting: YANG models provide detailed configuration capabilities for both the Common and Internal Spanning Tree (CIST) and Multiple Spanning Tree Instances (MSTIs), including VLAN and VID assignments within MST regions.
• State-of-the-Art Management: Support for real-time status reporting, facilitating the integration of MSTP with industrial and enterprise network management systems.
• Enhanced Conformance and Interoperability: The amendment clarifies bridge component requirements and options for MSTP management using YANG, ensuring that implementations meet consistent international standards.

Applications

Industrial Automation Networks

• Resilient and Flexible Topologies: MSTP YANG models empower automation networks to adopt complex topologies while maintaining loop-free, reliable operations across varying VLAN configurations.
• Programmable Network Management: Integration with industry-standard network controllers and management platforms ensures efficient commissioning, diagnostics, and maintenance.

Enterprise and Data Center Networks

• Simplified VLAN Management: YANG models enable centralized configuration of VLAN bridges and their spanning tree instances, leading to operational efficiency for large-scale, multi-tenant environments.
• Scalable Automation: Supports large networks by allowing administrators to automate repetitive configuration tasks and quickly adapt to changing network requirements.

Service Providers and Metropolitan Networks

• Standardized Configuration: The use of YANG enhances interoperability across multi-vendor environments, simplifying service deployment and lifecycle management in metropolitan area networks.

Related Standards

Organizations deploying or referencing ISO/IEC/IEEE 8802-1Q:2024/Amd 40:2026 may also consider the following related standards:

• IEEE 802.1Q™: The foundational standard for virtual LANs and bridging in LAN/MAN environments.
• IEEE 802.1Qcz™, 802.1Qcw™, 802.1Qcj™, 802.1Qdj™, 802.1Qdx™: Previous amendments addressing specific enhancements in bridging and network management.
• IEEE 802.1Q-2022: The consolidated standard for bridges and bridged networks, forming the basis for this amendment.
• YANG Data Modeling Language (RFC 6020, RFC 7950): The underlying technology for standardized, model-driven network management.
• Other MSTP and RSTP Implementations: As defined and referenced in the IEEE 802.1 family and related ISO/IEC standards for spanning tree protocols.

---

By adopting ISO/IEC/IEEE 8802-1Q:2024/Amd 40:2026, organizations can leverage YANG-based management to enhance the automation, reliability, and scalability of their LAN and metropolitan network infrastructure, in line with international best practices for telecommunications standards.
