ISO 14693:2003

Petroleum and natural gas industries - Drilling and well-servicing equipment

ISO 14693:2003 provides general principles and specifies requirements for design, manufacture and testing of new drilling and well-servicing equipment and of replacement primary load-carrying components manufactured subsequent to the publication of ISO 14693:2003. ISO 14693:2003 is applicable to the following equipment: -- rotary tables; -- rotary bushings; -- rotary slips; -- rotary hoses; -- piston mud-pump components; -- drawworks components; -- spiders not capable of use as elevators; -- manual tongs; -- safety clamps not used as hoisting devices; -- power tongs, including spinning wrenches. Annex A gives a number of standardized supplementary requirements which apply only when specified.

Industries du pétrole et du gaz naturel — Équipement de forage et d'entretien des puits

General Information

• Status: Published
• Publication Date: 07-Dec-2003
• ICS: 75.180.10 - Exploratory, drilling and extraction equipment
• Technical Committee: ISO/TC 67/SC 4 - Drilling and production equipment
• Drafting Committee: ISO/TC 67/SC 4/WG 1 - Drilling equipment
• Current Stage: 9599 - Withdrawal of International Standard
• Start Date: 04-Apr-2025
• Completion Date: 13-Dec-2025

Relations

• Consolidates: ISO/R 94:1959 - Title missing - Legacy paper document
• Effective Date: 28-Feb-2023

Overview

ISO 14693:2003 - Petroleum and natural gas industries: Drilling and well‑servicing equipment - establishes general principles and mandatory requirements for the design, manufacture and testing of new drilling and well‑servicing equipment and replacement primary load‑carrying components produced after publication. The standard is intended to ensure mechanical integrity, safety and traceability for critical rig components used in onshore and offshore drilling operations.

What the standard covers

ISO 14693:2003 is applicable to key drilling components including:

• rotary tables, rotary bushings, rotary slips
• rotary hoses
• piston mud‑pump components
• drawworks components
• spiders (not used as elevators)
• manual and power tongs (including spinning wrenches)
• safety clamps (not used as hoisting devices)

The document includes normative annexes (e.g., Annex A) with optional supplementary requirements that apply only when specified.

Key technical topics and requirements

• Design requirements: definition of design conditions, strength analysis, size class designation, rating and load‑rating basis, design safety factors and shear strength considerations.
• Design verification: specified function, pressure and load tests (including proof and load tests), apparatus for verification, procedures for rating and for handling design changes.
• Materials and fabrication: material specification, mechanical properties, material qualification and chemical composition controls.
• Welding and heat treatment: welder and procedure qualification, documentation, consumables control, post‑weld heat treatment and repair weld requirements.
• Quality control and testing: inspection personnel qualifications, dimensional verification, proof load testing, hydrostatic and functional testing, and record retention.
• Marking and documentation: product marking requirements and documents to be retained/delivered with equipment.
• Supplementary guidance: informative annexes cover heat‑treatment qualification, US customary dimensions, pump nomenclature and maintenance guidance.

Practical applications and users

ISO 14693:2003 is used by:

• Equipment manufacturers and fabricators to design and certify drilling components.
• Procurement and QA/QC teams in oil & gas operators to specify acceptance criteria.
• Drilling engineers and rig managers for safe equipment selection and maintenance planning.
• Third‑party inspectors and certification bodies performing verification, testing and traceability audits.
• Maintenance and repair workshops for replacing primary load‑carrying components to compliant standards.

By following ISO 14693, organizations improve safety, interoperability and lifecycle reliability of drilling and well‑servicing equipment.

Related standards

• API Specification 7K (basis for this ISO standard)
• ISO 148 (Charpy impact)
• ISO 6892 (tensile testing)
• ISO 7500‑1 (testing machine verification)
• API Spec 5B (threading and gaging)
