This document specifies the requirements for three types, three classes and two categories of textile-reinforced rubber hose for compressed air, up to a maximum working pressure of 2,5 MPa (25 bar) with an operating-temperature range of −40 °C to +70 °C, depending on the type and category.
Tuyaux en caoutchouc renforcés textile pour l'air comprimé — Spécifications
Le présent document spécifie les exigences pour trois types, trois classes et deux catégories de tuyaux en caoutchouc renforcés textile pour l'air comprimé, pouvant être utilisés jusqu'à une pression maximale de service de 2,5 MPa (25 bar) et sur une plage de températures de service de −40 °C à +70 °C, en fonction du type et de la catégorie.
