ISO 5149-3

• Abstract:

  ISO 5149-3:2014 is applicable to the installation site (plant space and services). It specifies requirements for the site for safety, which could be needed because of, but not directly connected with, the refrigerating system and its ancillary components. ISO 5149-3:2014 is applicable to new refrigerating systems, extensions or modifications of existing systems, and for used systems being transferred to and operated on another site. It also applies in the case of the conversion of a system for another refrigerant.

• Status: Not Published
• ICS: 27.080 - Heat pumps
• ICS: 27.200 - Refrigerating technology
• Technical Committee: ISO/TC 86/SC 1 - Safety and environmental requirements for refrigerating systems
• Drafting Committee: ISO/TC 86/SC 1 - Safety and environmental requirements for refrigerating systems
• Current Stage: 6000 - International Standard under publication
• Start Date: 22-Sep-2026
• Completion Date: 10-Oct-2026

• Revises: ISO 5149-3:2014/Amd 1:2021 - Refrigerating systems and heat pumps — Safety and environmental requirements — Part 3: Installation site — Amendment 1: Update of the requirements for machinery rooms and emergency mechanical ventilation
• Effective Date: 19-Nov-2022
• Revises: ISO 5149-3:2014 - Refrigerating systems and heat pumps — Safety and environmental requirements — Part 3: Installation site
• Effective Date: 19-Nov-2022

ISO 5149-3 is an ISO standard for the installation site of refrigerating systems and heat pumps. It sets classification and selection criteria for refrigerating systems and safety requirements for the plant space and services around them. In practice, it helps designers, installers, owners and safety staff decide where equipment may be placed, how the space is classified, and how leak, ventilation, alarm and electrical safety measures are selected.

What does ISO 5149-3 specify?

ISO 5149-3 specifies the installation-site requirements for refrigerating systems and their ancillary components, with a focus on safety conditions that are needed around the system rather than inside the system itself. It applies to new systems, extensions and modifications, used systems moved to another site, and systems converted to another refrigerant.

The document also sets the classification and selection criteria used in ISO 5149-2 and ISO 5149-4. Its structure runs from scope, references and terms through location classification, refrigerant quantity limits, machinery-room requirements, additional measures, electrical installations, alarms, detection systems, site instructions and inspections, heat sources, and heat-transfer fluid requirements.

Annex	What it covers
Annex A	Examples of classification and access category in Clause 5
Annex B	Safety classification and information about refrigerants
Annex C	Determination of the releasable charge
Annex D	Determination of the release height
Annex E	Determination of estimated height reached by the airflow
Annex F	Charge limit determination using surrounding concentration test

What are the key requirements of ISO 5149-3?

ISO 5149-3 organizes safety around classification first, then charge limits and site controls. The practical result is that the same refrigerating system can need different measures depending on where it is installed, who can access the space, and which refrigerant it uses.

• Classify the installation location and access category before setting the safety measures. Clause 5 divides locations into four classes and access into three categories, and also classifies refrigerants by toxicity and flammability. In practice, this means the designer has to consider the room, the occupants, and the refrigerant together, not just the equipment alone.

• Treat each space and each refrigerating system separately when several spaces or systems are involved. Clause 5 says spaces with refrigerant-containing parts are considered individually, and multiple systems are evaluated independently. This matters when one plant serves several rooms or when equipment is spread across different areas.

• Use the room volume or area that the refrigerant can actually affect. Clause 6 requires volume and area calculations for the space into which refrigerant can leak, with deductions for significant equipment and inventory and with limits on when spaces above false ceilings count. This keeps charge calculations tied to the real dilution space.

• Keep the refrigerant charge and releasable charge within the limit set by Clause 7. ISO 5149-3 gives two safety concepts - Path A and Path B. Path A limits charge using toxicity and flammability calculations; Path B allows safety to be achieved by other methods. For the user, this means the chosen design route determines whether the main control is charge limitation, ventilation, detection, shut-off or a combination.

• Apply the correct refrigerant data and cap factors from Annex B and Clause 7. The standard uses toxicity factor (TF), lower flammability limit (LFL), and charge cap factors for flammable refrigerants. That matters because the allowable charge may depend on both toxicity and flammability, and in some cases on whether the system is sealed, ventilated, or verified by test.

• Follow the machinery-room rules when equipment is located in a machinery room. Clause 8 covers occupancy, venting outdoors, combustion equipment, open flame, storage, remote emergency switching, openings, piping, lighting, dimensions, doors, ventilation, and extra measures for flammable refrigerants and R-717. In practice, the room must be usable for service but controlled as a safety space, not as general occupied space.

• Install and maintain alarms, detection systems and electrical equipment so they support the safety concept. Clauses 10 to 13 require electrical installations to suit the hazard, alarm and detector functions to match the refrigerant and location, and regular inspection and maintenance of the site. This means safety devices are part of the installation concept, not optional accessories.

• Control site heat sources and verify heat-transfer fluids. Clauses 14 and 15 address nearby heat sources, temporary high temperatures, and properties of heat-transfer fluid such as ingestion risk, contamination, pressure, marking, freezing point, flash point, auto-ignition temperature, thermal expansion and corrosion protection. For secondary systems, the fluid choice affects both safety and the building’s operating limits.

What terms does ISO 5149-3 define?

ISO 5149-3 uses the terms and definitions from ISO 5149-1, and it also uses these key abbreviations:

• ATEL - acute toxicity exposure limit, used in refrigerant safety data.
• ODL - oxygen deprivation limit, used together with ATEL when judging toxicity risk.
• LFL - lower flammability limit, the flammability threshold used in charge and ventilation calculations.
• TF - toxicity factor, used to set refrigerant quantity limits.
• CL - concentration limit, used in ventilation-based safety calculations.
• CLAM - concentration limit with additional measures, used in advanced methods.
• RV - room volume, used in charge limit calculations.
• SDS - safety data sheet, used to assess heat-transfer-fluid hazards.

Who uses ISO 5149-3?

ISO 5149-3 is used by refrigeration and heat pump designers, installers, commissioning engineers, building owners, facility managers, and safety or quality personnel who need to decide where equipment can be installed and what protections are required. It is also relevant to buyers and specifiers who need to compare plant-room layouts, ventilation arrangements, detection systems, and site obligations before ordering or approving a system.

The document matters in sectors that use refrigerating systems, secondary cooling or heating systems, machinery rooms, occupied spaces, open-air plant, ventilated enclosures, and systems being transferred or converted. Typical tasks include site classification, charge-limit calculation, selection of ventilation or detection, emergency switching, warning notices, inspection planning, and review of heat-transfer-fluid properties.

Which standards are used with ISO 5149-3?

• ISO 817 - provides refrigerant designation and safety classification, including the refrigerant data used in Annex B.
• ISO 5149-1 - supplies the vocabulary and definitions used throughout the series.
• ISO 5149-2 - provides the design, construction, testing, marking and documentation framework that this part refers to.
• ISO 5149-4 - covers operation, maintenance, repair and recovery, including maintenance-related responsibilities at the site.
• ISO 12100 - supports risk assessment and risk reduction, especially for the Path B approach and related safety decisions.
• ISO 13850 - provides principles for emergency stop function, used for the remote emergency switch.
• ISO 22712 - addresses competence of personnel, relevant to those working on or around the systems.
• IEC 60079-10-1 - used for hazardous area classification when flammable refrigerants are involved.
• IEC 60204-1 - used for the connection and arrangement of the main power supply and emergency functions.
• IEC 60364-1 and IEC 60364-5 - used for general electrical installation requirements.

What does the ISO 5149-3 document contain?

ISO 5149-3 contains the methods and tables needed to classify installation locations, access categories and refrigerants, and to calculate room volume, releasable charge, release height and airflow height. It also includes tables for charge limits, plus annexed calculation and test methods for release and concentration behavior.

It sets out the site checks and procedures for machinery-room ventilation, alarms, detection systems, warning notices, inspections and maintenance. The document also covers the practical layout of machinery rooms, including openings, doors, ducts, emergency lighting, service access and separation from other building spaces.

For charge verification, the document includes calculation routes and a surrounding concentration test in Annex F. For refrigerant safety data, Annex B collects the information needed for toxicity, flammability and related classifications.
