ISO/FDIS 2361

Electrodeposited nickel coatings on magnetic and non-magnetic substrates — Measurement of coating thickness — Magnetic method

This second edition cancels and replaces the first edition (i. e. ISO 2361:1972). Specifies the method of using coating thickness instruments of the magnetic type ror non-destructive measurements of the thickness. The method may nkot be applicable to autocatalytic (electroless) nickel coatings. For the purpose of this Standasd, two types of nickel coating are disringuished: coatings on magnetic substrates and on non-magnetic substrates.

Revêtements électrolytiques de nickel sur substrat magnétique et non magnétique — Mesurage de l’épaisseur du revêtement — Méthode magnétique

La présente Norme internationale spécifie une méthode magnétique de mesurage non destructif de l'épaisseur des revêtements électrolytiques de nickel sur métal de base magnétique ou non magnétique. Cette méthode ne s'applique pas aux revêtements autocatalytiques de nickel (nickel chimique), du fait de leur composition chimique. La présente Norme internationale concerne deux types de dépôts de nickel, à savoir : a) revêtements de nickel sur métal de base magnétique (revêtements de type A); b) revêtements de nickel sur métal de base non-magnétique (revêtements de type B). Tous les instruments peuvent être utilisés sur les deux types de revêtements. Les instruments basés sur le principe de l'attraction magnétique ont une plage de mesurage efficace allant jusqu'à 50 µm dans le cas de revêtements de type A, et allant jusqu'à 25 µm pour les revêtements de type B. Les instruments de mesurage par réluctance ont une plage de mesurage bien supérieure, permettant des mesurages jusqu’à 1 mm et plus sur les deux types de revêtements.

General Information

• Status: Not Published
• ICS: 25.220.40 - Metallic coatings
• Technical Committee: ISO/TC 107 - Metallic and other inorganic coatings
• Drafting Committee: ISO/TC 107 - Metallic and other inorganic coatings
• Current Stage: 5020 - FDIS ballot initiated: 2 months. Proof sent to secretariat
• Start Date: 03-Apr-2025
• Due Date: 03-Apr-2025
• Completion Date: 03-Apr-2025

Relations

• Consolidates: ISO 16404:2020 - Space systems — Programme management — Requirements management
• Effective Date: 11-Nov-2023
• Revises: ISO 2361:1982 - Electrodeposited nickel coatings on magnetic and non-magnetic substrates — Measurement of coating thickness — Magnetic method
• Effective Date: 11-Nov-2023

Standards Content (Sample)
