ISO/TS 15638-13:2015

Intelligent transport systems — Framework for cooperative telematics applications for regulated commercial freight vehicles (TARV) — Part 13: "Mass" information for jurisdictional control and enforcement

ISO/TS 15638-13:2015 addresses the provision of ?Mass (4.37) information for jurisdictional control and enforcement' and specifies the form and content of such data required to support such systems and access methods (4.3) to that data. The Scope of this part of ISO 15638 is to provide specifications (4.50) for common communications and data exchange aspects of the application service (4.6) Mass (4.37) information for jurisdictional control and enforcement that a regulator (4.44) may elect to require or support as an option, including a) high-level definition of the service that a service provider (4.48) has to provide (the service definition describes common service elements but does not define the detail of how such an application service (4.6) is instantiated, not the acceptable value ranges of the data concepts defined), b) means to realize the service, and c) application data, naming content and quality that an IVS (4.30) has to deliver. For clarification, Mass in this context is defined as a mass of a given heavy vehicle as measured by equipment affixed to the regulated vehicle; these mass calculations are achieved by dynamic real-time measurement using equipment especially installed for this purpose to measure the ?mass' impact on the road surface; it is, by definition, a service that can only be available to regulated vehicles that are especially equipped" (4.37). The definition of what comprises a ?regulated' service is regarded as an issue for National decision, and may vary from jurisdiction (4.34) to jurisdiction. This deliverable does not impose any requirements on nations in respect of which services for regulated vehicles jurisdictions will require, or support as an option, but provides standardised sets of requirements descriptions for identified services to enable consistent and cost-efficient implementations where instantiated. ISO/TS 15638-13:2015 is not a substitute for general electronic fee collection system which, where applied normally need to accord to International EFC Standards in preference to this specification. The Scope of this part of ISO 15638 is limited to the imposition of control and enforcement measures for regulated commercial freight vehicles related to measurement of the Mass (4.37) on board the vehicle. ISO/TS 15638-13:2015 has been developed for use in the context of regulated commercial freight vehicles [hereinafter, referred to as ?regulated vehicles' (4.43)]. There is nothing however to prevent a jurisdiction extending or adapting the scope to include other types of regulated vehicles, as it deems appropriate.

Systèmes intelligents de transport — Cadre pour applications télématiques coopératives pour véhicules de fret commercial réglementé (TARV) — Partie 13: Les informations du "MASS" pour le contrôle et l'application de règles juridiques

General Information

• Status: Published
• Publication Date: 12-Nov-2015
• ICS: 03.220.20 - Road transport
• ICS: 35.240.60 - IT applications in transport
• Technical Committee: ISO/TC 204 - Intelligent transport systems
• Drafting Committee: ISO/TC 204/WG 7 - General fleet management and commercial/freight
• Current Stage: 9060 - Close of review
• Start Date: 02-Dec-2025

Standards Content (Sample)

TECHNICAL ISO/TS
SPECIFICATION 15638-13
First edition
2015-12-01
Intelligent transport systems —
Framework for cooperative telematics
applications for regulated commercial
freight vehicles (TARV) —
Part 13:
”Mass” information for jurisdictional
control and enforcement
Systèmes intelligents de transport — Cadre pour applications
télématiques coopératives pour véhicules de fret commercial
réglementé (TARV)
Reference number
ISO/TS 15638-13:2015(E)
©
ISO 2015

---------------------- Page: 1 ----------------------
ISO/TS 15638-13:2015(E)

COPYRIGHT PROTECTED DOCUMENT
© ISO 2015, Published in Switzerland
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized otherwise in any form
or by any means, electronic or mechanical, including photocopying, or posting on the internet or an intranet, without prior
written permission. Permission can be requested from either ISO at the address below or ISO’s member body in the country of
the requester.
ISO copyright office
Ch. de Blandonnet 8 • CP 401
CH-1214 Vernier, Geneva, Switzerland
Tel. [phone]
Fax [phone]
[e-mail]
www.iso.org
ii © ISO 2015 – All rights reserved

---------------------- Page: 2 ----------------------
ISO/TS 15638-13:2015(E)

Contents Page
Foreword .v
Introduction .vii
1 Scope . 1
2 Conformance . 1
3 Normative references . 2
4 Terms and definitions . 2
5 Symbols and abbreviated terms . 8
6 General overview and framework requirements . 9
7 Requirements for services using generic vehicle data .10
8 Application services that require data in addition to basic vehicle data .10
8.1 General .10
8.2 Quality of service requirements .10
8.3 Test requirements .10
8.4 Marking, labelling, and packaging .10
9 Common features of regulated TARV application services .10
9.1 General .10
9.2 Common role of the jurisdiction, approval authority, service provider and user .11
9.3 Common characteristics for instantiations of regulated application services .12
9.4 Common sequence of operations for regulated application services .12
9.5 Quality of service .12
9.6 Information security .12
9.7 Data naming content and quality .12
9.8 Software engineering quality systems .12
9.9 Quality monitoring station .12
9.10 Audits .12
9.11 Access control policy .12
9.12 Approval of IVSs and service providers .12
10 Mass information for jurisdictional control and enforcement (MICE) .12
10.1 TARV MICE service description and scope — MICE use cases .12
10.1.1 General.12
10.1.2 Jurisdiction — Regulatory, safety, and funding .15
10.1.3 Vehicle operators – Regulatory observance .16
10.1.4 Jurisdiction — Assessment and collection .16
10.1.5 Approval authority — Approval and audit of ASP system .16
10.2 Concept of operations for Mass information for jurisdictional control and
enforcement (MICE) .16
10.2.1 General.16
10.2.2 Statement of the goals and objectives of the TARV MICE system .17
10.2.3 Strategies, tactics, policies, and constraints affecting the system .18
10.2.4 Organisations, activities, and interactions among participants
and stakeholders . .19
10.3 Vehicle Mass information for jurisdictional control and enforcement data (MICED) .21
10.4 MICE use cases .22
10.4.1 Approaching MICE zone .22
10.4.2 Within MICE zone .22
10.4.3 Leaving MICE zone .23
10.4.4 Reporting .23
10.4.5 Possible access control .24
10.5 Clear statement of responsibilities and authorities delegated .24
10.6 Equipment required for TARV MICE .25
© ISO 2015 – All rights reserved iii

---------------------- Page: 3 ----------------------
ISO/TS 15638-13:2015(E)

10.6.1 TARV IVS .25
10.6.2 Equipment periphery/connected to the IVS .26
10.6.3 TARV MICE ‘app’ .26
10.6.4 MICE applications and systems .26
10.7 Operational processes for the system .26
10.7.1 Define and update MICE zone .26
10.7.2 Operational processes for the system — Approaching MICE zone .27
10.7.3 Operational processes for the system — within MICE zone .27
10.7.4 Operational processes for the system — exiting MICE zone .27
10.7.5 Reporting .27
10.8 Sequence of operations for TARV MICE .28
10.8.1 MICE service element (MICE SE1): Define MICE zone .28
10.8.2 MICE service element (MICE SE2): Publish regulation .28
10.8.3 MICE service element (MICE SE3): Detect approaching regulated vehicle .28
10.8.4 MICE service element (MICE SE4): ‘Interrogated’ request for vehicle data .28
10.8.5 MICE service element (MICE SE5): ASP notifies jurisdiction or its agents
of approaching vehicle .29
10.8.6 MICE service element (MICE SE6): Grant/deny access .29
10.8.7 MICE service element (MICE SE7): Periodic or requested updates . .29
10.8.8 MICE service element (MICE SE8): Vehicle egress .29
10.9 Generic TARV MICE data naming content and quality .29
10.10 Specific TARV MICE data naming content and quality .29
10.11 TARV MICE application service specific provisions for quality of service .30
10.12 TARV MICE application service specific provisions for test requirements .30
10.13 TARV MICE application specific rules for the approval of IVSs and ‘Service Providers’ .30
11 Declaration of patents and intellectual property .30
Annex A (informative) ASN.1 Modules for ISO 15638-13 data concepts .32
Annex B (informative) Independent testing of the protocols defined in this part of ISO 15638 .35
Bibliography .62
iv © ISO 2015 – All rights reserved

---------------------- Page: 4 ----------------------
ISO/TS 15638-13:2015(E)

Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www.iso.org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation on the meaning of ISO specific terms and expressions related to conformity
assessment, as well as information about ISO’s adherence to the WTO principles in the Technical
Barriers to Trade (TBT) see the following URL: Foreword - Supplementary information
The committee responsible for this document is ISO/TC 204, Intelligent transport systems.
ISO 15638 consists of the following parts, under the general title Intelligent transport systems —
Framework for collaborative Telematics Applications for Regulated commercial freight Vehicles (TARV):
— Part 1: Framework and architecture
— Part 2: Common platform parameters using CALM
— Part 3: Operating requirements, ‘Approval Authority’ procedures, and enforcement provisions for the
providers of regulated services
— Part 5: Generic vehicle information
— Part 6: Regulated applications
— Part 7: Other applications
— Part 8: Vehicle access management
— Part 9: Remote electronic tachograph monitoring (RTM)
— Part 10: Emergency messaging system/eCall (EMS)
— Part 11: Driver work records
— Part 12: Vehicle mass monitoring
— Part 13: ‘Mass’ information for jurisdictional control and enforcement
— Part 14: Vehicle access control
— Part 15: Vehicle location monitoring
— Part 16: Vehicle speed monitoring
© ISO 2015 – All rights reserved v

---------------------- Page: 5 ----------------------
ISO/TS 15638-13:2015(E)

— Part 17: Consignment and location monitoring
— Part 18: ADR (Dangerous Goods) transport monitoring (ADR)
— Part 19: Vehicle parking facilities (VPF)
The following parts are under preparation:
— Part 4: System security requirements
vi © ISO 2015 – All rights reserved

---------------------- Page: 6 ----------------------
ISO/TS 15638-13:2015(E)

Introduction
Many ITS technologies have been embraced by commercial transport operators (4.39) and freight
owners, in the areas of fleet management, safety and security. Telematics (4.52) applications have also
been developed for governmental use. Such regulatory services in use or being considered vary from
jurisdiction (4.34) to jurisdiction, but include electronic on-board recorders, digital tachograph (4.51),
on-board mass (4.37) monitoring, Mass (4.37) information for jurisdictional control and enforcement,
vehicle access (4.1) methods, hazardous goods (4.29) tracking and e-call (4.25). Additional applications
with a regulatory impact being developed include fatigue management, speed monitoring and heavy
vehicle penalties imposed based on location, distance and time.
In such an emerging environment of regulatory and commercial applications (4.16), it is timely to consider
an overall architecture (4.12) (business and functional) that could support these functions from a single
platform within a commercial freight vehicle that operates within such regulations. International
Standards will allow for a speedy development and specification (4.50) of new applications that build
upon the functionality of a generic specification platform. A suite of standards deliverables is required
to describe and define the framework (4.28) and requirements so that the on-board equipment and
back office systems can be commercially designed in an open market to meet common requirements of
jurisdictions (4.34).
This suite of standards addresses and defines the framework (4.28) for a range of cooperative telematics
(4.52) applications for regulated vehicles (4.43) (such as access methods (4.3), driver fatigue management,
speed monitoring, on-board mass (4.37) monitoring, penalties and enforcement). The overall scope
includes the concept of operation, legal and regulatory issues, and the generic cooperative provision
of services to regulated vehicles (4.43), using an on-board ITS platform. The framework is based on a
(multiple) service provider (4.48) oriented approach with provisions for the approval (4.9) and auditing
(4.13) of service providers.
This suite of standards deliverables will
— provide the basis for future development of cooperative telematics (4.52) applications for
regulated vehicles (4.43). Many elements to accomplish this are already available. Existing relevant
standards will be referenced, and the specifications (4.50) will use existing standards (such as
CALM) wherever practicable,
— allow for a powerful platform for highly cost-effective delivery of a range of telematics applications
for regulated vehicles (4.43),
— a business architecture (4.12) based on a (multiple) service provider (4.48) oriented approach, and
— address legal and regulatory aspects for the approval (4.9) and auditing (4.13) of service providers.
This suite of standards deliverables is timely as many governments (Europe, North America, Asia and
Australia/New Zealand) are considering the use of telematics (4.52) for a range of regulatory purposes.
Ensuring that a single in-vehicle platform can deliver a range of services to both government and
industry through open standards and competitive markets is a strategic objective.
This part of ISO 15638 provides specifications (4.50) for Mass (4.37) information for jurisdictional
control and enforcement.
NOTE 1 The definition of what comprises a ‘regulated’ vehicle is regarded as an issue for National decision,
and may vary from jurisdiction (4.36) to jurisdiction. This suite of standards deliverables does not impose any
requirements on nations in respect of how they define a regulated vehicle (4.43).
NOTE 2 The definition of what comprises a ‘regulated’ service is regarded as an issue for National decision,
and may vary from jurisdiction (4.34) to jurisdiction. This suite of standards deliverables does not impose any
requirements on nations in respect of which services for regulated vehicles (4.43) jurisdictions will require, or
support as an option, but will provide standardised sets of requirements descriptions for identified services to
enable consistent and cost-efficient implementations where implemented.
© ISO 2015 – All rights reserved vii

---------------------- Page: 7 ----------------------
TECHNICAL SPECIFICATION ISO/TS 15638-13:2015(E)
Intelligent transport systems — Framework for
cooperative telematics applications for regulated
commercial freight vehicles (TARV) —
Part 13:
”Mass” information for jurisdictional control and
enforcement
1 Scope
This part of ISO 15638 addresses the provision of ‘Mass (4.37) information for jurisdictional control and
enforcement’ and specifies the form and content of such data required to support such systems and
access methods (4.3) to that data.
The Scope of this part of ISO 15638 is to provide specifications (4.50) for common communications and
data exchange aspects of the application service (4.6) Mass (4.37) information for jurisdictional control
and enforcement that a regulator (4.44) may elect to require or support as an option, including
a) high-level definition of the service that a service provider (4.48) has to provide (the service definition
describes common service elements but does not define the detail of how such an application service
(4.6) is instantiated, not the acceptable value ranges of the data concepts defined),
b) means to realize the service, and
c) application data, naming content and quality that an IVS (4.30) has to deliver.
For clarification, Mass in this context is defined as a mass of a given heavy vehicle as measured by
equipment affixed to the regulated vehicle; these mass calculations are achieved by dynamic real-time
measurement using equipment especially installed for this purpose to measure the ‘mass’ impact on
the road surface; it is, by definition, a service that can only be available to regulated vehicles that are
especially equipped” (4.37).
The definition of what comprises a ‘regulated’ service is regarded as an issue for National decision, and
may vary from jurisdiction (4.34) to jurisdiction. This deliverable does not impose any requirements on
nations in respect of which services for regulated vehicles jurisdictions will require, or support as an
option, but provides standardised sets of requirements descriptions for identified services to enable
consistent and cost-efficient implementations where instantiated.
This part of ISO 15638 is not a substitute for general electronic fee collection system which, where
applied normally need to accord to International EFC Standards in preference to this specification. The
Scope of this part of ISO 15638 is limited to the imposition of control and enforcement measures for
regulated commercial freight vehicles related to measurement of the Mass (4.37) on board the vehicle.
ISO 15638 has been developed for use in the context of regulated commercial freight vehicles
[hereinafter, referred to as ‘regulated vehicles’ (4.43)]. There is nothing however to prevent a jurisdiction
extending or adapting the scope to include other types of regulated vehicles, as it deems appropriate.
2 Conformance
Requirements to demonstrate conformance to any of the general provisions or specific application
services (4.6) described in this part of ISO 15638 shall be within the regulations imposed by the
jurisdiction (4.34) where they are instantiated. Conformance requirements to meet the provisions of
© ISO 2015 – All rights reserved 1

---------------------- Page: 8 ----------------------
ISO/TS 15638-13:2015(E)

this International Standard are therefore deemed to be under the control of, and to the specification of,
the jurisdiction where the application service(s) is/are instantiated.
The protocols defined in this part of ISO 15638 have been independently tested. Annex B provides
results of these tests. In any conformance assurance process undertaken by candidate systems, where
appropriate, the results may be used as part of its process of conformance compliance.
3 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
ISO 12855, Electronic fee collection — Information exchange between service provision and toll charging
ISO 15638-1, Intelligent transport systems — Framework for collaborative Telematics Applications for
Regulated commercial freight Vehicles (TARV) — Part 1: Framework and architecture
ISO 15638-2, Intelligent transport systems — Framework for collaborative Telematics Applications for
Regulated commercial freight Vehicles (TARV) — Part 2: Common platform parameters using CALM
ISO 15638-3, Intelligent transport systems — Framework for collaborative telematics applications for
regulated commercial freight vehicles (TARV) — Part 3: Operating requirements, ‘Approval Authority’
procedures, and enforcement provisions for the providers of regulated services
1)
ISO 15638-4:— , Intelligent transport systems — Framework for collaborative Telematics Applications for
Regulated commercial freight Vehicles (TARV) — Part 4: System security requirements
ISO 15638-5, Intelligent transport systems — Framework for collaborative Telematics Applications for
Regulated commercial freight Vehicles (TARV) — Part 5: Generic vehicle information
ISO 15638-6, Intelligent transport systems — Framework for collaborative Telematics Applications for
Regulated commercial freight Vehicles (TARV) — Part 6: Regulated applications
ISO 15638-12, Intelligent transport systems — Framework for cooperative telematics applications for
regulated vehicles (TARV) — Vehicle mass monitoring
ISO 15638-14, Intelligent transport systems — Framework for cooperative telematics applications for
regulated vehicles (TARV) — Vehicle access control
4 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 15638-1 and the following apply.
4.1
access
admittance, entry, permit to use the road network and/or associated infrastructure (bridges,
tunnels, etc.)
4.2
access control
procedures and measures to control admittance, entry, permit to use the road network and/or
associated infrastructure (bridges, tunnels, etc.)
4.3
access methods
procedures and protocols to provision and retrieve data
1) Under development.
2 © ISO 2015 – All rights reserved

---------------------- Page: 9 ----------------------
ISO/TS 15638-13:2015(E)

4.4
access monitoring
observation and recording of vehicle-related data when using the road network and/or associated
infrastructure (bridges, tunnels, etc.)
4.5
app
small (usually) Java™ (4.33) applets, organised as software bundles, that support application services
(4.6) by keeping the data pantry (4.22) provisioned with up-to-date data
4.6
application service
service provided by a service provider (4.48) enabled by accessing data from the IVS (4.30) of a regulated
vehicle (4.43) via a wireless communications network
4.7
application service provider
ASP
party that provides an application service (4.6)
4.8
app library
separately secure area of memory in IVS (4.30) where apps are stored (with different access controls to
data pantry (4.22))
4.9
approval
formal affirmation that an applicant has satisfied all the requirements for appointment as an application
service provider (4.7) or that an application service delivers the required service levels
4.10
approval agreement
written agreement made between an approval authority (regulatory) (4.11) and a service provider (4.48)
Note 1 to entry: An approval authority (regulatory) (4.11) approval agreement recognizes the fact that a service
provider (4.48), having satisfied the approval authority’s requirements for appointment as a service provider, is
appointed in that capacity and sets out the legal obligations of the parties with respect to the on-going role of the
service provider.
4.11
approval authority (regulatory)
organisation (usually independent) which conducts approval (4.9) and ongoing audit (4.13) for service
providers (4.48) on behalf of a jurisdiction (4.34)
4.12
architecture
formalised description of the design of the structure of TARV and its framework (4.28)
4.13
audit/auditing
review of a party’s capacity to meet, or continue to meet, the initial and ongoing approval agreements
(4.10) as a service provider (4.48)
4.14
basic vehicle data
data that shall be maintained/provided by all IVS (4.30) (regard
...
