SIST EN 2240-061:2011

Aerospace series - Lamps, incandescent - Part 061: Lamp, code 1683 - Product standard

This European Standard specifies the required characteristics for lamp, code 1683, for aerospace applications.
It shall be used together with EN 2756.

Luft- und Raumfahrt - Glühlampen - Teil 061: Lampe, Kode 1683 - Produktnorm

Diese Norm legt die Anforderungen an Lampen mit dem Kode 1683 zur Anwendung in der Luftfahrt fest. Sie ist in Verbindung mit EN 2756 anzuwenden.

Série aérospatiale - Lampes à incandescence - Partie 061: Lampe, code 1683 - Norme de produit

La présente Norme Européenne spécifie les caractéristiques requises pour une lampe, code 1683,
utilisée à bord des aéronefs.
Elle doit être utilisée conjointement avec l’EN 2756.

Aeronavtika - Žarnice - 061. del: Žarnica, koda 1683 - Standard za izdelek

Ta evropski standard opredeljuje zahtevane lastnosti za žarnico, koda 1683, za uporabo v aeronavtiki. Uporabljal naj bi se skupaj z EN 2756.

General Information

• Status: Published
• Publication Date: 02-Aug-2011
• ICS: 49.060 - Aerospace electric equipment and systems
• Technical Committee: I13 - Imaginarni 13
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 27-Jul-2011
• Due Date: 01-Oct-2011
• Completion Date: 03-Aug-2011
• Ref Project: EN 2240-061:2011 - Aerospace series - Lamps, incandescent - Part 061: Lamp, code 1683 - Product standard

Overview

The SIST EN 2240-061:2011 standard, published by CEN and developed by the Aerospace and Defence Industries Association of Europe (ASD-STAN), defines the product requirements for lamp, code 1683, specifically designed for aerospace applications. This European Standard ensures that incandescent lamps used within the aerospace sector meet strict quality, performance, and safety criteria. It complements the general test methods outlined in EN 2756 and relates to other standards covering main characteristics, technical specifications, and lamp caps.

Lamp code 1683, as standardized in EN 2240-061, represents a critical component in aerospace electric equipment and systems. Proper adherence to these specifications supports reliability, safety, and interoperability in aerospace lighting systems.

Key Topics

• Scope and Application
  Specifies required characteristics exclusive to lamp code 1683 for aerospace use, ensuring uniform performance and compatibility across EU member states.

• Dimensions and Physical Characteristics
  Key dimensions such as filament form (C-2R/C-6), light center length (31.7 ± 1.5 mm), and mass (8.5 kg per 1,000 lamps) are standardized. The lamp bulb is clear with nominal voltage of 28 V and wattage of 28.56 W.

• Electrical and Optical Properties
  Includes nominal current (1.02 A ± 8%), luminous flux (400 lumens ± 15%), and color temperature (2,810 K). The lamp’s operational life is specified for static and dynamic conditions under both DC and AC voltages, ensuring durability and consistent light output.

• Lamp Cap Specification
  Uses BA15s/19 type caps per EN 2241 standards, ensuring mechanical and electrical compatibility.

• Marking and Identification
  Lamps and packaging must be marked with the international code number to facilitate traceability and quality assurance aligned with EN 2240-002.

• Related Testing and Compliance
  Integral use with EN 2756 test methods guarantees all lamps conform to rigorous aerospace safety and performance criteria before deployment.

Applications

This standard is predominantly applied in the aerospace industry for:

• Aircraft Lighting Systems: Ensures incandescent lamps meet performance and durability requirements for cockpit instrumentation, interior illumination, and external signals.
• Aerospace Maintenance and Repairs: Sets criteria for replacement lamps used during routine aircraft maintenance to maintain consistent system specifications.
• Safety-Critical Aerospace Equipment: Supports the certification and verification of lighting components within navigation and operational systems where reliability is crucial.
• Quality Control in Aerospace Manufacturing: Serves as a reference for manufacturers designing and producing incandescent lamps for aeronautical use, ensuring compliance with European regulations.

Related Standards

EN 2240-061 integrates closely with other standards in the aerospace lighting series, including:

• EN 2240-001: Technical specification for incandescent lamps in aerospace applications.
• EN 2240-002: Defines the main characteristics including coding and markings for aerospace lamps.
• EN 2241: Covers dimensional and mechanical requirements of lamp caps.
• EN 2756: Specifies the test methods to verify conformity and performance of aerospace incandescent lamps.

Compliance with this suite of standards helps maintain high quality and interoperability of aerospace lighting components under international regulations.

---

By adhering to SIST EN 2240-061:2011, aerospace manufacturers and maintenance providers can ensure the reliable performance of incandescent lamps used in critical aerospace systems, enhancing safety and operational efficiency across the aviation sector.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Aeronavtika - Žarnice - 061. del: Žarnica, koda 1683 - Standard za izdelekLuft- und Raumfahrt - Glühlampen - Teil 061: Lampe, Kode 1683 - ProduktnormSérie aérospatiale - Lampes à incandescence - Partie 061: Lampe, code 1683 - Norme de produitAerospace series -
Lamps, incandescent - Part 061: Lamp, code 1683 - Product standard49.060Aerospace electric equipment and systemsICS:Ta slovenski standard je istoveten z:EN 2240-061:2011SIST EN 2240-061:2011en,fr,de01-september-2011SIST EN 2240-061:2011SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 2240-061
June 2011 ICS 49.060 English Version
Aerospace series -
Lamps, incandescent - Part 061: Lamp, code 1683 - Product standard
Série aérospatiale - Lampes à incandescence - Partie061: Lampe, code 1683 - Norme de produit
Luft- und Raumfahrt - Glühlampen - Teil 061: Lampe, Kode 1683 - Produktnorm This European Standard was approved by CEN on 7 April 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 2240-061:2011: ESIST EN 2240-061:2011
...
