(Main)Ophthalmic optics - Contact lenses - Part 3: Measurement methods (ISO 18369-3:2017)
Ophthalmic optics - Contact lenses - Part 3: Measurement methods (ISO 18369-3:2017)
This document specifies the methods for measuring the physical and optical properties of contact
lenses specified in ISO 18369-2, i.e. radius of curvature, label back vertex power, diameter, thickness,
inspection of edges, inclusions and surface imperfections and determination of spectral transmittance.
This document also specifies the equilibrating solution and standard saline solution for testing of
contact lenses.
