SIST EN ISO 20347:2022/A1:2024

• Status: Published In Translation
• Public Enquiry End Date: 01-Aug-2023
• Publication Date: 14-Apr-2024
• ICS: 13.340.50 - Leg and foot protection
• Technical Committee: OVP - Personal protecting equipment
• Current Stage: 6100 - Translation of adopted SIST standards (Adopted Project)
• Start Date: 14-May-2025
• Due Date: 13-May-2026
• Directive: Harmonized Standard2016/425 - Regulation (EU) 2016/425 of the European Parliament and of the Council of 9 March 2016 on personal protective equipment and repealing Council Directive 89/686/EEC
  OJ Ref: 2024, 2024/2599, OJ L OJ Date: 08-Oct-2024
• Mandate: M/571 - COMMISSION IMPLEMENTING DECISION of 19.11.2020 on a standardisation request to the European Committee for Standardization and the European Committee for Electrotechnical Standardization as regards personal protective equipment in support of Regulation (EU) 2016/425 of the European Parliament and of the Council
• Mandate: M/571 AMD 1 - Personal Protective Equipement
• Ref Project: EN ISO 20347:2022/A1:2024 - Personal protective equipment - Occupational footwear - Amendment 1 (ISO 20347:2021/Amd 1:2024)

• Amends: SIST EN ISO 20347:2022 - Personal protective equipment - Occupational footwear (ISO 20347:2021)
• Effective Date: 01-May-2024

Overview

EN ISO 20347:2022/A1:2024 is Amendment 1 to the European adoption of ISO 20347 (Occupational footwear). Published by CEN in 2024, this amendment updates test references, performance criteria and specific material requirements for non-safety occupational footwear used as personal protective equipment (PPE). It aligns EN ISO 20347 with related changes in ISO 20344:2021+Amd.1:2024 and clarifies performance, test and marking requirements relevant to EU PPE Regulation (EU) 2016/425.

Key topics and technical requirements

• Normative references: Updates ISO 20344 references to include Amendment 1 (ISO 20344:2021+Amd.1:2024) throughout the text.
• Materials & chemical limits: Chromium VI content in each leather part is limited to < 3.0 mg/kg when tested per ISO 20344.
• Water vapour performance (WVP/WVC):
  • New two-tier compliance options depending on the proportion of non-permeable upper material (max 10% or 50%):
    • If ≤10% non-permeable: remaining materials WVP ≥ 0.8 mg/(cm²·h) and WVC ≥ 15 mg/cm².
    • If ≤50% non-permeable: remaining materials WVP ≥ 2.0 mg/(cm²·h).
  • Specific exceptions and measurement rules for hybrid footwear and localized lining are defined.
• Upper and tear strength: Table updates add tear strength and WVP/WVC requirements to specific material classes.
• Footwear construction & hybrid designs: Defines Area A (foot section) and Area B (extended section) with minimum heights and class-dependent requirements.
• Outsole & flexing durability:
  • Cut growth limit ≤ 4 mm after 30,000 flex cycles; defined thresholds for acceptable crack depth/length/number.
  • Bond strength for multi-layer outsoles ≥ 4.0 N/mm (≥ 3.0 N/mm if tearing of material occurs).
• Perforation-resistant inserts:
  • Non-metallic inserts: no perforation at any measured point and no layer separation (tent effect) during tests.
  • Inserts used as insoles have specific allowances; no holes allowed other than stitching.
• Ankle protection: Outer ankle protection average force ≤ 10 kN and no single value > 15 kN; inner protection must meet same limits.
• Scuff cap (renamed): New ergonomic requirement-during kneeling, scuff cap must prevent contact between upper and flat ground.

Applications and users

• Who uses it: PPE manufacturers, product designers, test laboratories, conformity assessors, procurement officers and safety managers specifying occupational footwear for workplace compliance.
• Practical value:
  • Ensures product compliance with EU PPE Regulation (EU) 2016/425 when cited in the OJ.
  • Provides updated test criteria for durability, comfort (breathability), chemical safety and mechanical protection.
  • Helps manufacturers design and verify occupational footwear (non-safety footwear classes) for regulated markets across CEN member states.

Related standards

• ISO 20344:2021 + Amd.1:2024 (test methods) - updated normative reference.
• EN 13832-3:2018 (Footwear protecting against chemicals - Part 3) - title clarified in the amendment.
• ISO 20347:2021 (base standard) - this document is an amendment to that edition.

Keywords: EN ISO 20347:2022/A1:2024, occupational footwear standard, PPE footwear, water vapour permeability, chromium VI limit, ISO 20344, scuff cap, ankle protection, perforation-resistant inserts.
