SIST EN 3646-006:2026

Aerospace series - Connectors, electrical, circular, bayonet coupling, operating temperature 175 °C or 200 °C continuous - Part 006: Receptacle, hermetic, jam-nut mounting - Product standard

This document specifies the characteristics of hermetic jam-nut mounted receptacles in the family of bayonet coupling circular connectors, intended for use in an operating temperature range of – 65 °C to 175 °C or 200 °C continuous.
It is applicable to models specified in Table 4.
For plugs and protective covers, see EN 3646-008 and EN 3646-009 respectively.

Luft- und Raumfahrt - Elektrische Rundsteckverbinder mit Bajonettkupplung, Betriebstemperatur 175 °C oder 200 °C konstant - Teil 006: Hermetischer fester Steckverbinder mit Mutternbefestigung - Produktnorm

Dieses Dokument legt die Eigenschaften von hermetischen festen Steckverbindern mit Mutternbefestigung aus der Familie der Rundsteckverbinder mit Bajonettkupplung fest, die für den Einsatz im Betriebstemperaturbereich von −65 °C bis 175 °C oder 200 °C konstant vorgesehen sind.
Es ist für die in Tabelle 4 angegebene Bauform anwendbar.
Für zugehörige freie Steckverbinder und Schutzkappen siehe EN 3646 008 bzw. EN 3646 009.

Série aérospatiale - Connecteurs électriques circulaires à accouplement par baïonenettes, température d'utilisation 175 °C ou 200 °C continu - Partie 006: Embasse hermétique à fixation par écrou - Norme de produit

Le présent document spécifie les caractéristiques des embases hermétiques à fixation par écrou de la famille des connecteurs circulaires à accouplement par baïonnettes, destinés à une utilisation dans une plage de températures comprises entre −65 °C et 175 °C ou 200 °C continu.
Il est applicable au modèle spécifié dans le Tableau 4.
Pour les fiches et les bouchons de vol, voir respectivement l’EN 3646-008 et l’EN 3646-009.

Aeronavtika - Konektorji, električni, okrogli, bajonetno sklapljanje, stalna delovna temperatura 175 °C ali 200 °C - 006. del: Podloga, hermetična, pritrjena z matico - Standard za proizvod

Ta dokument določa lastnosti hermetičnih vtičnic z montažo z matico v družini okroglih konektorjev z bajonetnim spojem, namenjenih za uporabo v temperaturnem območju od – 65 °C do 175 °C ali 200 °C neprekinjeno.
Uporablja se za modele, določene v Tabeli 4.
Za vtiče in zaščitne pokrove glej EN 3646-008 in EN 3646-009.
