IMT cellular networks - Harmonised Standard covering the essential requirements of article 3.2 of Directive 2014/53/EU - Part 13: Evolved Universal Terrestrial Radio Access (E-UTRA) User Equipment (UE)

The present document applies to the following radio equipment type:
• User Equipment for Evolved Universal Terrestrial Radio Access (E-UTRA).
This radio equipment type is capable of operating in all or any part of the frequency bands given in tables from 1-1
through 1-5.
The present document covers requirements for E-UTRA FDD and E-UTRA TDD User Equipment from 3GPP™
Releases 8, 9, 10 and 11 defined in ETSI TS 136 101 [3]. This includes the requirements for E-UTRA UE operating
bands and E-UTRA CA operating bands from 3GPP™ Release 12 defined in ETSI TS 136 101 [i.13].
NOTE: For Band 20:
􀀀 For user equipment designed to be mobile or nomadic, the requirements in the present document
measured at the antenna port also show conformity to the corresponding requirement defined as
TRP (total radiated power), as described in Commission Decision 2010/267/EU [i.6], ECC
Decision (09)03 [i.7] and CEPT Report 30 [i.8].
􀀀 For user equipment designed to be fixed or installed, the present document does not address the
requirements described in Commission Decision 2010/267/EU [i.6], ECC Decision (09)03 [i.7] and
CEPT Report 30 [i.8].
The present document contains requirements to demonstrate that radio equipment both effectively uses and supports the
efficient use of radio spectrum in order to avoid harmful interference.
The present document covers the essential requirements of article 3.2 of Directive 2014/53/EU [i.2] under the
conditions identified in annex A.

Celična omrežja IMT - Harmonizirani standard, ki zajema bistvene zahteve člena 3.2 direktive 2014/53/EU - 13. del: Uporabniška oprema za razviti prizemni radijski dostop za UMTS (E-UTRA)

Ta dokument se uporablja za radijsko opremo naslednje vrste:
• uporabniška oprema za razviti prizemni radijski dostop za UMTS (E-UTRA).
Ta vrsta radijske opreme lahko deluje v vseh delih frekvenčnih pasov iz preglednic 1-1 do 1-5.
Ta dokument zajema zahteve za uporabniško opremo E-UTRA FDD in E-UTRA TDD iz izdaj 8, 9, 10 in 11 dokumenta 3GPP™, kot je določeno v dokumentu ETSI TS 136 101 [3]. To vključuje zahteve za pasove, v katerih deluje E-UTRA UE, in pasove, v katerih deluje E-UTRA CA iz izdaje 12 dokumenta 3GPP™, kot je določeno v dokumentu ETSI TS 136 101 [i.13]. OPOMBA: Za pas 20:
Za uporabniško opremo, zasnovano kot mobilno ali nomadsko, so zahteve iz tega dokumenta, izmerjene na antenskem vhodu, tudi v skladu z ustrezno zahtevo, opredeljeno kot TRP (skupna sevana moč), kot je opisana v Sklepu Komisije 2010/267/EU [i.6], Sklepu Odbora za elektronske komunikacije (09)03 [i.7] in poročilu CEPT 30 [i.8].
Za uporabniško opremo, zasnovano za priključitev ali namestitev, ta dokument ne obravnava zahtev, opisanih v Sklepu Komisije 2010/267/EU [i.6], Sklepu Odbora za elektronske komunikacije (09)03 [i.7] in poročilu CEPT 30 [i.8].
Ta dokument vsebuje zahteve, s katerimi se dokazuje, da je radijska oprema izdelana tako, da učinkovito uporablja in podpira učinkovito rabo radijskega spektra z namenom preprečevanja škodljivega motenja.
Ta dokument zajema bistvene zahteve člena 3.2 direktive 2014/53/EU [i.2] pod pogoji iz dodatka A.
