SIST EN 300 392-3-1 V1.4.1:2016
(Main)Terrestrial Trunked Radio (TETRA) - Voice plus Data (V+D) - Part 3: Interworking at the Inter-System Interface (ISI) - Sub-part 1: General design
Terrestrial Trunked Radio (TETRA) - Voice plus Data (V+D) - Part 3: Interworking at the Inter-System Interface (ISI) - Sub-part 1: General design
The present document defines the general aspects of interworking at the Inter-System Interface (ISI) for Terrestrial
Trunked Radio (TETRA) system supporting Voice plus Data (V+D). Those specify the general concepts which are the
basis of the ISI operation between TETRA systems. It introduces the Additional Network Features (ANFs) used at
the ISI, and specifies:
- the general protocol mechanism, called ISI Generic Functional Protocol (ISI GFP), upon which the definition
of each ANF is based; and
- the security requirements for the ISI.
The ISI GFP specification applies to any TETRA Switching and Management Infrastructure (SwMI) which supports the
ISI. The security requirements for the ISI only apply to SwMIs which support authentication or encryption over the ISI.
Besides the ISI general design, the present document, interworking at the Inter-System Interface comprises the
following other sub-parts:
- Additional Network Feature - ISI Individual Call (ANF-ISIIC);
- Additional Network Feature - ISI Group Call (ANF-ISIGC);
- Additional Network Feature - ISI Short Data service (ANF-ISISDS); and
- Additional Network Feature - ISI Mobility Management (ANF-ISIMM).
Prizemni snopovni radio (TETRA) - Govor in podatki (V+D) - 3. del: Medsebojno delovanje na medsistemskem vmesniku (ISI) - 1. poddel: Splošna zasnova
Ta dokument določa splošne vidike medsebojnega delovanja na medsistemskem vmesniku (ISI) za sistem prizemnega snopovnega radia (TETRA), ki podpira govor in podatke (V+D). Ti opredeljujejo splošne koncepte, ki so podlaga delovanja ISI med sistemi TETRA. Uvaja dodatne omrežne funkcije (ANF-je), ki se uporabljajo na vmesniku ISI, ter določa naslednje:
- splošni mehanizem protokola, imenovan generični funkcionalni protokol ISI (ISI GFP), na katerem temelji definicija vsakega posameznega ANF-ja; ter
- varnostne zahteve za ISI.
Ta specifikacija ISI GFP velja za vse komutacijske in upravne infrastrukture (SwMI) TETRA, ki podpirajo ISI. Varnostne zahteve za ISI veljajo le za komutacijske in upravne infrastrukture, ki podpirajo overjanje ali šifriranje prek vmesnika ISI. Poleg splošne zasnove ISI je ta dokument, medsebojno delovanje na medsistemskem vmesniku, sestavljen iz naslednjih poddelov:
- dodatna omrežna funkcija – posamezni klic medsistemskega vmesnika (ANF-ISIIC);
- dodatna omrežna funkcija – skupinski klic medsistemskega vmesnika (ANF-ISIGC);
-dodatna omrežna funkcija – storitev kratkih podatkov medsistemskega vmesnika (ANF-ISISD) ter
- dodatna omrežna funkcija – upravljanje mobilnosti medsistemskega vmesnika (ANF-ISIMM).
