SIST EN 4026:2002

Aerospace series - Pipe coupling 8°30' in titanium alloy - Tees

This standard specifies the characteristics of tees, for pipe couplings 8°30', in titanium alloy, for aerospace applications.
Nominal pressure: up to 28 000 kPa
Temperature range:   55 °C to 135 °C

Luft- und Raumfahrt - Rohrverschraubung 8°30' aus Titanlegierung - T-Verschraubungen

Diese Norm legt die Eigenschaften von T-Verschraubungen, für Rohrverschraubungen 8°30', aus Titanlegierung, zur
Verwendung in der Luft- und Raumfahrt fest.
Nenndruck: bis 28 000 kPa
Temperaturbereich:   55 °C bis 135 °C

Série aérospatiale - Systeme de raccordement 8°30' en alliage de titane - Raccords en té

La présente norme spécifie les caractéristiques des raccords en té pour les systèmes de raccordement 8°30', en alliage
de titane, pour applications aérospatiales.
Pression nominale: jusqu'à 28 000 kPa
Plage de température:   55 °C à 135 °C

Aerospace series - Pipe coupling 8-30' in titanium alloy - Tees

General Information

• Status: Published
• Publication Date: 31-Dec-2001
• ICS: 49.080 - Aerospace fluid systems and components
• Technical Committee: SS SPL - Technical Board for the general field
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Jan-2002
• Due Date: 01-Jan-2002
• Completion Date: 01-Jan-2002
• Ref Project: EN 4026:2001 - Aerospace series - Pipe coupling 8°30' in titanium alloy - Tees

Overview

EN 4026:2001 (Aerospace series) defines the characteristics of tees for 8°30' pipe couplings in titanium alloy intended for aerospace fluid systems. The standard is published by CEN and applies to tees designed for a nominal pressure up to 28 000 kPa and a temperature range of 55 °C to 135 °C. It specifies geometry, materials, surface finishing, lubrication and marking requirements to ensure interchangeability and reliable performance in aerospace applications.

Key topics and requirements

• Scope and limits
  • Tees for pipe coupling 8°30' in titanium alloy for aerospace use.
  • Rated up to 28 000 kPa; temperature range given as 55 °C to 135 °C.
• Configuration, dimensions and mass
  • Detailed dimensional data and mass values are given (table and figure in the standard); values apply before lubricating.
  • Unspecified dimensions may be chosen by the manufacturer provided EN 3275 (type II) qualification/acceptance requirements are met.
• Threads and sealing
  • Uses MJ thread series; limits and thread dimensions referenced to ISO 5855‑3.
  • Dynamic beam seal specification referenced to EN 3275.
• Materials
  • Titanium alloy grades and product forms are referenced to EN 3311 / EN 3312 / EN 3314 / EN 3315 (TI‑P64001 variants).
• Surface treatment and lubrication
  • Thread and sealing faces to be lubricated per EN 2491.
  • Abrasive blasting with non‑metallic grit required prior to lubrication.
  • Lubricant film thickness: 0.005 mm to 0.013 mm.
• Internal finishing and surface quality
  • Internal radius R = 0.3 mm to 1.0 mm; internal surface roughness 0.8 µm.
  • Hand deburring is explicitly prohibited.
• Marking
  • Marking to follow EN 2424 (style A) and accompanying figure.

Applications and users

• Typical users: aerospace OEMs, fluid‑system designers, component manufacturers, quality and procurement engineers, maintenance organizations, and certification bodies.
• Practical applications: design, manufacture, procurement and inspection of titanium tees used in aerospace fluid systems where weight, corrosion resistance and strength are critical-ensuring compatibility with 8°30' pipe coupling systems and MJ threads.

Related standards

• ISO 5855‑3 (MJ threads)
• EN 3274 / EN 3275 (8°30' coupling geometry and dynamic seal)
• EN 2424 (marking)
• EN 2491 (molybdenum disulfide dry lubricant)
• EN 3311 / EN 3312 / EN 3314 / EN 3315 (titanium alloy material specifications)

EN 4026:2001 provides the prescriptive requirements needed to achieve interchangeability, traceability and performance for titanium alloy tees in aerospace pipe coupling 8°30' systems.
