SIST EN ISO 5183-2:2002

Resistance spot welding - Electrode adaptors, male taper 1:10 - Part 2: Parallel shank fixing for end-thrust electrodes (ISO 5183-2:2000)

Res. 2/2001 : UAP to be applied on published ISO 5183-2 (MB/010410)

Widerstandspunktschweißen - Elektrodenschäfte mit Außenkegel 1:10 - Teil 2: Zylindrische Befestigung für gerade Beanspruchung (ISO 5183-2:2000)

Dieser Teil von ISO 5183 legt Maße und Grenzabmaße für Widerstandspunktschweiß-Elektrodenschäfte fest, bei denen die Befestigung der Elektrodenkappe (siehe ISO 5821) mittels eines Außenkegels 1:10 erfolgt und zur Befestigung des Elektrodenschaftes im Elektrodenhalter (siehe ISO 8430-3) ein zylindrischer Schaft verwendet wird.

Equipement de soudage par résistance - Allonges d'électrode a embout amovible, cône mâle 1:10 - Partie 2: Emmanchement cylindrique pour poussée en bout (ISO 5183-2:2000)

La présente partie de l'ISO 5183 spécifie les dimensions et tolérances des corps de pointes d'électrode (couramment appelés allonges) à embout amovible (voir ISO 5821) pour soudage par points par résistance sur lesquels la fixation de l'embout est un cône mâle 1:10 et pour lesquels l'emmanchement cylindrique pour poussée en bout est conforme à l'ISO 8430-3.

Uporovno točkovno varjenje - Držala elektrod z zunanjim konusom 1:10 - 2. del: Valjasta pritrditev za vtične elektrode (ISO 5183-2:2000)

General Information

• Status: Published
• Publication Date: 30-Apr-2002
• ICS: 25.160.30 - Welding equipment
• Technical Committee: VAR - Welding
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-May-2002
• Due Date: 01-May-2002
• Completion Date: 01-May-2002
• Ref Project: EN ISO 5183-2:2001 - Resistance spot welding - Electrode adaptors, male taper 1:10 - Part 2: Parallel shank fixing for end-thrust electrodes (ISO 5183-2:2000)
