1 Scope The present document specifies the requirements for Building Material Analysis and Classification (BMA&C) Applications operating in all or part of the frequency band from 2.2 GHz to 8 GHz. Reduced emissions in the range from 0,96 GHz to 2,2 GHz and 8 GHz to 10,6 GHz are permitted and defined in clause 4.2.1.1. The document applies to:
a) UWB building material analysis and classification equipment for imaging and object detection applications; b) equipment fitted with an integral antenna; c) handheld devices; d) equipment with an activation switch which allows emissions only when the equipment is in direct contact to the material to be investigated. The document does not apply to: • UWB communication applications; and • Ground probing and through-wall equipment. The present document specifies the equipment which is designed to not radiate into the free air. It is designed to function only when positioned such that it radiates directly into the absorptive material such as walls and other building materials which absorb emissions. Any leakage or residual emissions appearing e.g. behind the wall or outside the backwards and sideways screened antenna is defined as undesired emission. The present document does not necessarily include all the characteristics which may be required by a user, nor does it necessarily represent the optimum performance achievable. The present document contains all technical characteristics and test methods for Building Material Analysis and Classification equipment operated in accordance with the ECC Decision ECC/DEC/(06)xy [4] for imaging
...
ETSI EN 302 435-2 V1.2.1 (2008-04)
Harmonized European Standard (Telecommunications series)
Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Short Range Devices (SRD);
Technical characteristics for SRD equipment using
Ultra WideBand technology (UWB);
Building Material Analysis and Classification equipment applications
operating in the frequency band from 2,2 GHz to 8 GHz;
Part 2: Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive
---------------------- Page: 1 ----------------------
2 ETSI EN 302 435-2 V1.2.1 (2008-04)
Reference
DEN/ERM-TG31C-001-2
Keywords
radio, SRD, UWB, testing
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2008.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
---------------------- Page: 2 ----------------------
3 ETSI EN 302 435-2 V1.2.1 (2008-04)
Contents
Intellectual Property Rights.4
Foreword.4
Introduction .4
1 Scope.5
2 References.5
2.1 Normative references.6
2.2 Informative references.6
3 Definitions, symbols and abbreviations .6
3.1 Definitions.6
3.2 Symbols.6
3.3 Abbreviations.6
4 Technical requirements specifications .7
4.1 Environmental profile.7
4.2 Conformance requirements.7
4.2.1 Transmitter requirements.7
4.2.1.1 Maximum Undesired UWB Emissions (UE) .7
4.2.1.2 Maximum Other Emissions (OE).7
4.2.1.3 Total Power spectral density (UE-TP) .7
4.2.1.4 Minimum pulse repetition frequency .7
4.2.2 Other equipment requirements.7
4.2.2.1 Design requirements.7
4.2.2.2 Listen before Talk .7
5 Testing for compliance with technical requirements.8
5.1 Environmental conditions for testing .8
5.2 Essential radio test suites.8
5.2.1 Transmitter test suites .8
5.2.1.1 Maximum Undesired UWB Emissions (UE) .8
5.2.1.2 Maximum Other Emissions (OE).8
5.2.1.3 Total Power spectral density (UE-TP) .8
5.2.2 Other test suites.8
5.2.2.1 Listen before Talk .8
5.3 Interpretation of measurement results .8
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT).9
Annex B (informative): The EN title in the official languages .11
Annex C (informative): Bibliography.13
History .14
ETSI
---------------------- Page: 3 ----------------------
4 ETSI EN 302 435-2 V1.2.1 (2008-04)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM).
The present document is part 2 of a multi-part deliverable covering Ultra WideBand (UWB) Building Material
Analysis (BMA) and Classification equipment applications operating in the frequency band from 2,2 GHz to 8 GHz, as
identified below:
Part 1: "Technical characteristics and test methods";
Part 2: "Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive".
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC [5] (as amended) laying down a procedure for the provision of information in the
field of technical standards and regulations.
The present document is intended to become a Harmonized Standard, the reference of which will be published in the
Official Journal of the European Communities referencing the Directive 1999/5/EC of the European Parliament and of
the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual
recognition of their conformity ("the R&TTE Directive").
Technical specifications relevant to Directive 1999/5/EC [3] are given in annex A.
National transposition dates
Date of adoption of this EN: 4 April 2008
Date of latest announcement of this EN (doa): 31 July 2008
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 31 January 2009
Date of withdrawal of any conflicting National Standard (dow): 31 January 2010
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive. The modular
structure is shown in EG 201 399 [2].
ETSI
---------------------- Page: 4 ----------------------
5 ETSI EN 302 435-2 V1.2.1 (2008-04)
1 Scope
The present document specifies the requirements for Building Material Analysis and Classification (BMA) applications
using UWB technology operating in all or part of the frequency band from 2,2 GHz to 8 GHz. Additionally it specifies
reduced emissions in the ranges from 0,96 GHz to 2,2 GHz and 8 GHz to 10,6 GHz.
Equipment covered by the present document operates in accordance with ECC Decision ECC/DEC(07)01 [6] on
Building Material Analysis (BMA) devices using Ultra WideBand technology in the bands below 8,0 GHz.
Table 1: Radiocommunications service frequency bands
Radiocommunications service frequency bands
Transmit 2 200 MHz to 8 000 MHz
Receive 2 200 MHz to 8 000 MHz
The present document applies to:
a) UWB building material analysis and classification equipment for imaging and object detection applications;
b) equipment fitted with an integral antenna;
c) handheld devices.
The present document does not apply to:
• UWB communication devices; and
• Ground penetrating radar devices; and
• through-wall radar imaging devices;
as defined in ITU-R Recommendation SM.1754 [4].
The present document specifies the equipment which is designed to not radiate into the free space. It is designed to
function only when positioned such that it radiates directly into the absorptive material such as walls and other building
materials which absorb emissions.
The present document does not necessarily include all the characteristics which may be required by a user, nor does it
necessarily represent the optimum performance achievable.
The present document is intended to cover the provisions of article 3.2 of Directive 1999/5/EC (R&TTE Directive),
which states that ". radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radiocommunications and orbital resources so as to avoid harmful interference".
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific.
• For a specific reference, subsequent revisions do not apply.
• Non-specific reference may be made only to a complete document or a part thereof and only in the following
cases:
- if it is accepted that it will be possible to use all future changes of the referenced document for the
purposes of the referring document;
- for informative references.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
ETSI
---------------------- Page: 5 ----------------------
6 ETSI EN 302 435-2 V1.2.1 (2008-04)
For online referenced documents, information sufficient to identify and locate the source shall be provided. Preferably,
the primary source of the referenced document should be cited, in order to ensure traceability. Furthermore, the
reference should, as far as possible, remain valid for the expected life of the document. The reference shall include the
method of access to the referenced document and the full network address, with the same punctuation and use of upper
case and lower case letters.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are indispensable for the application of the present document. For dated
references, only the edition cited applies. For non-specific references, the latest edition of the referenced document
(including any amendments) applies.
[1] ETSI EN 302 435-1 (V1.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Short Range Devices (SRD); Technical characteristics for SRD equipment using Ultra WideBand
technology (UWB); Building Material Analysis and Classification equipment applications
operating in the frequency band from 2,2 GHz to 8 GHz; Part 1: Technical characteristics and test
methods".
2.2 Informative references
The following referenced documents are not essential to the use of the present document but they assist the user with
regard to a particular subject area. For non-specific references, the latest version of the referenced document (including
any amendments) applies.
[2] ETSI EG 201 399: "Electromagnetic compatibility and Radio spectrum Matters (ERM); A guide to
the production of candidate Harmonized Standards for application under the R&TTE Directive".
[3] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity
[4] ITU-R Recommendation SM.1754: "Measurement techniques of ultra-wideband transmissions".
[5] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[6] ECC/DEC(07)01 Decision of 30 March 2007 on Building Material Analysis (BMA) devices using
UWB technology.
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the terms and definitions given in clause 3 of
EN 302 435-1 [1] apply.
3.2 Symbols
For the purposes of the present document, the symbols given in clause 3 of EN 302 435-1 [1] apply.
3.3 Abbreviations
For the purposes of the present document, the abbreviations given in clause 3 of EN 302 435-1 [1] apply.
ETSI
---------------------- Page: 6 ----------------------
7 ETSI EN 302 435-2 V1.2.1 (2008-04)
4 Technical requirements specifications
4.1 Environmental profile
The technical requirements of the present document apply under the environmental profile for operation of the
equipment, which shall be declared by the provider. The equipment shall comply with all the technical requirements of
the present document at all times when operating within the boundary limits of the declared operational environmental
profile.
4.2 Conformance requirements
4.2.1 Transmitter requirements
4.2.1.1 Maximum Undesired UWB Emissions (UE)
The maximum undesired UWB emissions shall not exceed the limits specified in clause 8.3.1.3 of
...
Final draft ETSI EN 302 435-2 V1.2.1 (2008-02)
Harmonized European Standard (Telecommunications series)
Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Short Range Devices (SRD);
Technical characteristics for SRD equipment using
Ultra WideBand technology (UWB);
Building Material Analysis and Classification equipment applications
operating in the frequency band from 2,2 GHz to 8 GHz;
Part 2: Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive
---------------------- Page: 1 ----------------------
2 Final draft ETSI EN 302 435-2 V1.2.1 (2008-02)
Reference
DEN/ERM-TG31C-001-2
Keywords
radio, SRD, UWB, testing
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2008.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
---------------------- Page: 2 ----------------------
3 Final draft ETSI EN 302 435-2 V1.2.1 (2008-02)
Contents
Intellectual Property Rights.4
Foreword.4
Introduction .4
1 Scope.5
2 References.5
2.1 Normative references.6
2.2 Informative references.6
3 Definitions, symbols and abbreviations .6
3.1 Definitions.6
3.2 Symbols.6
3.3 Abbreviations.6
4 Technical requirements specifications .7
4.1 Environmental profile.7
4.2 Conformance requirements.7
4.2.1 Transmitter requirements.7
4.2.1.1 Maximum Undesired UWB Emissions (UE) .7
4.2.1.2 Maximum Other Emissions (OE).7
4.2.1.3 Total Power spectral density (UE-TP) .7
4.2.1.4 Minimum pulse repetition frequency .7
4.2.2 Other equipment requirements.7
4.2.2.1 Design requirements.7
4.2.2.2 Listen before Talk .7
5 Testing for compliance with technical requirements.7
5.1 Environmental conditions for testing .7
5.2 Essential radio test suites.8
5.2.1 Transmitter test suites .8
5.2.1.1 Maximum Undesired UWB Emissions (UE) .8
5.2.1.2 Maximum Other Emissions (OE).8
5.2.1.3 Total Power spectral density (UE-TP) .8
5.2.2 Other test suites.8
5.2.2.1 Listen before Talk .8
5.3 Interpretation of measurement results .8
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT).9
Annex B (informative): The EN title in the official languages .11
Annex C (informative): Bibliography.13
History .14
ETSI
---------------------- Page: 3 ----------------------
4 Final draft ETSI EN 302 435-2 V1.2.1 (2008-02)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM), and is now submitted for the Vote phase of the
ETSI standards Two-step Approval Procedure.
The present document is part 2 of a multi-part deliverable covering Ultra WideBand (UWB) Building Material
Analysis (BMA) and Classification equipment applications operating in the frequency band from 2,2 GHz to 8 GHz, as
identified below:
Part 1: "Technical characteristics and test methods";
Part 2: "Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive".
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC (as amended) laying down a procedure for the provision of information in the field of
technical standards and regulations.
The present document is intended to become a Harmonized Standard, the reference of which will be published in the
Official Journal of the European Communities referencing the Directive 1999/5/EC of the European Parliament and of
the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual
recognition of their conformity ("the R&TTE Directive").
Technical specifications relevant to Directive 1999/5/EC [3] are given in annex A.
Proposed national transposition dates
Date of latest announcement of this EN (doa): 3 months after ETSI publication
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 6 months after doa
Date of withdrawal of any conflicting National Standard (dow): 18 months after doa
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive. The modular
structure is shown in EG 201 399 [2].
ETSI
---------------------- Page: 4 ----------------------
5 Final draft ETSI EN 302 435-2 V1.2.1 (2008-02)
1 Scope
The present document specifies the requirements for Building Material Analysis and Classification (BMA) applications
using UWB technology operating in all or part of the frequency band from 2,2 GHz to 8 GHz. Additionally it specifies
reduced emissions in the ranges from 0,96 GHz to 2,2 GHz and 8 GHz to 10,6 GHz.
Equipment covered by the present document operates in accordance with ECC Decision ECC/DEC(07)01 on Building
Material Analysis (BMA) devices using Ultra WideBand technology in the bands below 8,0 GHz.
Table 1: Radiocommunications service frequency bands
Radiocommunications service frequency bands
Transmit 2 200 MHz to 8 000 MHz
Receive 2 200 MHz to 8 000 MHz
The present document applies to:
a) UWB building material analysis and classification equipment for imaging and object detection applications;
b) equipment fitted with an integral antenna;
c) handheld devices.
The present document does not apply to:
• UWB communication devices; and
• Ground penetrating radar devices; and
• through-wall radar imaging devices;
as defined in ITU-R Recommendation SM.1754 [4].
The present document specifies the equipment which is designed to not radiate into the free space. It is designed to
function only when positioned such that it radiates directly into the absorptive material such as walls and other building
materials which absorb emissions.
The present document does not necessarily include all the characteristics which may be required by a user, nor does it
necessarily represent the optimum performance achievable.
The present document is intended to cover the provisions of article 3.2 of Directive 1999/5/EC (R&TTE Directive),
which states that ". radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radiocommunications and orbital resources so as to avoid harmful interference".
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific.
• For a specific reference, subsequent revisions do not apply.
• Non-specific reference may be made only to a complete document or a part thereof and only in the following
cases:
- if it is accepted that it will be possible to use all future changes of the referenced document for the
purposes of the referring document;
- for informative references.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
ETSI
---------------------- Page: 5 ----------------------
6 Final draft ETSI EN 302 435-2 V1.2.1 (2008-02)
For online referenced documents, information sufficient to identify and locate the source shall be provided. Preferably,
the primary source of the referenced document should be cited, in order to ensure traceability. Furthermore, the
reference should, as far as possible, remain valid for the expected life of the document. The reference shall include the
method of access to the referenced document and the full network address, with the same punctuation and use of upper
case and lower case letters.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are indispensable for the application of the present document. For dated
references, only the edition cited applies. For non-specific references, the latest edition of the referenced document
(including any amendments) applies.
[1] ETSI EN 302 435-1 (V1.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Short Range Devices (SRD); Technical characteristics for SRD equipment using Ultra WideBand
technology (UWB); Building Material Analysis and Classification equipment applications
operating in the frequency band from 2,2 GHz to 8 GHz; Part 1: Technical characteristics and test
methods".
2.2 Informative references
[2] ETSI EG 201 399: "Electromagnetic compatibility and Radio spectrum Matters (ERM); A guide to
the production of candidate Harmonized Standards for application under the R&TTE Directive".
[3] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity
[4] ITU-R Recommendation SM.1754: "Measurement techniques of ultra-wideband transmission
...
SLOVENSKI STANDARD
SIST EN 302 435-2 V1.2.1:2008
01-september-2008
(OHNWURPDJQHWQD]GUXåOMLYRVWLQ]DGHYHY]YH]L]UDGLMVNLPVSHNWURP (50
1DSUDYHNUDWNHJDGRVHJD 65' 7HKQLþQHNDUDNWHULVWLNH]DRSUHPR65'NL
XSRUDEOMDXOWUDãLURNRSDVRYQR 8:% WHKQRORJLMR$SOLNDFLMHRSUHPH]DDQDOL]RLQ
NODVLILNDFLMRYJUDMHQLKPDWHULDORYNLGHOXMHYIUHNYHQþQHPSDVXRG*+]GR
*+]GHO +DUPRQL]LUDQL(1NL]DMHPDELVWYHQH]DKWHYHþOHQDGLUHNWLYH
5 77(
Electromagnetic compatibility and Radio spectrum Matters (ERM) - Short Range Devices
(SRD) - Technical characteristics for SRD equipment using Ultra WideBand technology
(UWB) - Building Material Analysis and Classification equipment applications operating in
the frequency band from 2,2 GHz to 8 GHz - Part 2: Harmonized EN covering essential
requirements of article 3.2 of the R&TTE Directive
Ta slovenski standard je istoveten z: EN 302 435-2 Version 1.2.1
ICS:
33.060.20 Sprejemna in oddajna Receiving and transmitting
oprema equipment
33.100.01 Elektromagnetna združljivost Electromagnetic compatibility
na splošno in general
SIST EN 302 435-2 V1.2.1:2008 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
SIST EN 302 435-2 V1.2.1:2008
---------------------- Page: 2 ----------------------
SIST EN 302 435-2 V1.2.1:2008
ETSI EN 302 435-2 V1.2.1 (2008-04)
Harmonized European Standard (Telecommunications series)
Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Short Range Devices (SRD);
Technical characteristics for SRD equipment using
Ultra WideBand technology (UWB);
Building Material Analysis and Classification equipment applications
operating in the frequency band from 2,2 GHz to 8 GHz;
Part 2: Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive
---------------------- Page: 3 ----------------------
SIST EN 302 435-2 V1.2.1:2008
2 ETSI EN 302 435-2 V1.2.1 (2008-04)
Reference
DEN/ERM-TG31C-001-2
Keywords
radio, SRD, UWB, testing
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2008.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
---------------------- Page: 4 ----------------------
SIST EN 302 435-2 V1.2.1:2008
3 ETSI EN 302 435-2 V1.2.1 (2008-04)
Contents
Intellectual Property Rights.4
Foreword.4
Introduction .4
1 Scope.5
2 References.5
2.1 Normative references.6
2.2 Informative references.6
3 Definitions, symbols and abbreviations .6
3.1 Definitions.6
3.2 Symbols.6
3.3 Abbreviations.6
4 Technical requirements specifications .7
4.1 Environmental profile.7
4.2 Conformance requirements.7
4.2.1 Transmitter requirements.7
4.2.1.1 Maximum Undesired UWB Emissions (UE) .7
4.2.1.2 Maximum Other Emissions (OE).7
4.2.1.3 Total Power spectral density (UE-TP) .7
4.2.1.4 Minimum pulse repetition frequency .7
4.2.2 Other equipment requirements.7
4.2.2.1 Design requirements.7
4.2.2.2 Listen before Talk .7
5 Testing for compliance with technical requirements.8
5.1 Environmental conditions for testing .8
5.2 Essential radio test suites.8
5.2.1 Transmitter test suites .8
5.2.1.1 Maximum Undesired UWB Emissions (UE) .8
5.2.1.2 Maximum Other Emissions (OE).8
5.2.1.3 Total Power spectral density (UE-TP) .8
5.2.2 Other test suites.8
5.2.2.1 Listen before Talk .8
5.3 Interpretation of measurement results .8
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT).9
Annex B (informative): The EN title in the official languages .11
Annex C (informative): Bibliography.13
History .14
ETSI
---------------------- Page: 5 ----------------------
SIST EN 302 435-2 V1.2.1:2008
4 ETSI EN 302 435-2 V1.2.1 (2008-04)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM).
The present document is part 2 of a multi-part deliverable covering Ultra WideBand (UWB) Building Material
Analysis (BMA) and Classification equipment applications operating in the frequency band from 2,2 GHz to 8 GHz, as
identified below:
Part 1: "Technical characteristics and test methods";
Part 2: "Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive".
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC [5] (as amended) laying down a procedure for the provision of information in the
field of technical standards and regulations.
The present document is intended to become a Harmonized Standard, the reference of which will be published in the
Official Journal of the European Communities referencing the Directive 1999/5/EC of the European Parliament and of
the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual
recognition of their conformity ("the R&TTE Directive").
Technical specifications relevant to Directive 1999/5/EC [3] are given in annex A.
National transposition dates
Date of adoption of this EN: 4 April 2008
Date of latest announcement of this EN (doa): 31 July 2008
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 31 January 2009
Date of withdrawal of any conflicting National Standard (dow): 31 January 2010
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive. The modular
structure is shown in EG 201 399 [2].
ETSI
---------------------- Page: 6 ----------------------
SIST EN 302 435-2 V1.2.1:2008
5 ETSI EN 302 435-2 V1.2.1 (2008-04)
1 Scope
The present document specifies the requirements for Building Material Analysis and Classification (BMA) applications
using UWB technology operating in all or part of the frequency band from 2,2 GHz to 8 GHz. Additionally it specifies
reduced emissions in the ranges from 0,96 GHz to 2,2 GHz and 8 GHz to 10,6 GHz.
Equipment covered by the present document operates in accordance with ECC Decision ECC/DEC(07)01 [6] on
Building Material Analysis (BMA) devices using Ultra WideBand technology in the bands below 8,0 GHz.
Table 1: Radiocommunications service frequency bands
Radiocommunications service frequency bands
Transmit 2 200 MHz to 8 000 MHz
Receive 2 200 MHz to 8 000 MHz
The present document applies to:
a) UWB building material analysis and classification equipment for imaging and object detection applications;
b) equipment fitted with an integral antenna;
c) handheld devices.
The present document does not apply to:
• UWB communication devices; and
• Ground penetrating radar devices; and
• through-wall radar imaging devices;
as defined in ITU-R Recommendation SM.1754 [4].
The present document specifies the equipment which is designed to not radiate into the free space. It is designed to
function only when positioned such that it radiates directly into the absorptive material such as walls and other building
materials which absorb emissions.
The present document does not necessarily include all the characteristics which may be required by a user, nor does it
necessarily represent the optimum performance achievable.
The present document is intended to cover the provisions of article 3.2 of Directive 1999/5/EC (R&TTE Directive),
which states that ". radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radiocommunications and orbital resources so as to avoid harmful interference".
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific.
• For a specific reference, subsequent revisions do not apply.
• Non-specific reference may be made only to a complete document or a part thereof and only in the following
cases:
- if it is accepted that it will be possible to use all future changes of the referenced document for the
purposes of the referring document;
- for informative references.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
ETSI
---------------------- Page: 7 ----------------------
SIST EN 302 435-2 V1.2.1:2008
6 ETSI EN 302 435-2 V1.2.1 (2008-04)
For online referenced documents, information sufficient to identify and locate the source shall be provided. Preferably,
the primary source of the referenced document should be cited, in order to ensure traceability. Furthermore, the
reference should, as far as possible, remain valid for the expected life of the document. The reference shall include the
method of access to the referenced document and the full network address, with the same punctuation and use of upper
case and lower case letters.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are indispensable for the application of the present document. For dated
references, only the edition cited applies. For non-specific references, the latest edition of the referenced document
(including any amendments) applies.
[1] ETSI EN 302 435-1 (V1.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Short Range Devices (SRD); Technical characteristics for SRD equipment using Ultra WideBand
technology (UWB); Building Material Analysis and Classification equipment applications
operating in the frequency band from 2,2 GHz to 8 GHz; Part 1: Technical characteristics and test
methods".
2.2 Informative references
The following referenced documents are not essential to the use of the present document but they assist the user with
regard to a particular subject area. For non-specific references, the latest version of the referenced document (including
any amendments) applies.
[2] ETSI EG 201 399: "Electromagnetic compatibility and Radio spectrum Matters (ERM); A guide to
the production of candidate Harmonized Standards for application under the R&TTE Directive".
[3] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity
[4] ITU-R Recommendation SM.1754: "Measurement techniques of ultra-wideband transmissions".
[5] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[6] ECC/DEC(07)01 Decision of 30 March 2007 on Building Material Analysis (BMA) devices using
UWB technology.
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the terms and definitions given in clause 3 of
EN 302 435-1 [1] apply.
3.2 Symbols
For the purposes of the present document, the symbols given in clause 3 of EN 302 435-1 [1] apply.
3.3 Abbreviations
For the purposes of the present document, the abbreviations given in clause 3 of EN 302 435-1 [1] apply.
ETSI
---------------------- Page: 8 ----------------------
SIST EN
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
