SIST EN ISO 7041:2025

Fasteners - Prevailing torque hexagon nuts - High nuts (with non-metallic insert) (ISO 7041:2025)

This document specifies the characteristics of prevailing torque hexagon high nuts (with non‑metallic insert), in steel and stainless steel, with metric coarse pitch thread M5 to M39, and with product grades A and B.
NOTE            These nuts are designed with an overall height equal to mmin (as specified in ISO 898-2 and ISO 4033 for style 2) plus the prevailing torque feature. The height of the prevailing torque feature (hmax – mmin) for the non-metallic insert is identical for regular, high and thin nuts for a given diameter.
If in certain cases other specifications are requested, property classes and stainless steel grades can be selected from ISO 898-2 or ISO 3506-2.

Verbindungselemente - Sechskantmuttern mit Klemmteil - Hohe Muttern (mit nichtmetallischem Einsatz) (ISO 7041:2025)

Dieses Dokument legt die Eigenschaften von hohen Sechskantmuttern mit Klemmteil (mit nichtmetallischem Einsatz) aus Stahl und nichtrostendem Stahl mit metrischen Regelgewinden von M5 bis M39, und in Produktklassen A und B fest.
ANMERKUNG   Diese Muttern sind mit einer Gesamthöhe von mmin (wie in ISO 898 2 und ISO 4033 für den Typ 2 festgelegt) plus Klemmteil gestaltet. Die Höhe des Klemmteils (hmax − mmin) für den nichtmetallischen Einsatz ist für normalhohe, hohe und niedrige Muttern bei einem bestimmten Durchmesser gleich.
Falls in bestimmten Fällen andere Festlegungen benötigt werden, können Festigkeitsklassen und Stahlsorten nichtrostender Stähle ISO 898 2 oder ISO 3506 2 entnommen werden.

Fixations - Écrous hexagonaux autofreinés - Écrous hauts (à anneau non métallique) (ISO 7041:2025)

Le présent document spécifie les caractéristiques des écrous hauts hexagonaux autofreinés (à anneau non métallique), en acier et en acier inoxydable, à filetage métrique à pas gros M5 à M39, et de grades A et B.
NOTE            Ces écrous sont conçus avec une hauteur totale égale à mmin (tel que spécifié dans l’ISO 898-2 et l’ISO 4033 pour le style 2) plus le dispositif d’autofreinage. La hauteur du dispositif d’autofreinage (hmax – mmin) pour l’anneau non métallique est identique pour les écrous normaux, hauts et bas d’un diamètre donné.
Si dans certains cas d’autres spécifications sont requises, les classes de qualité et les grades d’acier inoxydable peuvent être choisis dans l’ISO 898-2 ou l’ISO 3506-2.

Vezni elementi - Šestrobe zaščitne matice - Visoke matice (s plastičnim vložkom) (ISO 7041:2025)

General Information

• Status: Not Published
• Public Enquiry End Date: 30-Jul-2024
• ICS: 21.060.20 - Nuts
• Technical Committee: ISEL - Mechanical elements
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 27-Jun-2025
• Due Date: 01-Sep-2025
• Ref Project: EN ISO 7041:2025 - Fasteners - Prevailing torque hexagon nuts - High nuts (with non-metallic insert) (ISO 7041:2025)
