SIST EN 13160-5:2016
(Main)Leak detection systems - Part 5: Requirements and test/assessment methods for in-tank gauge systems and pressurised pipework systems
Leak detection systems - Part 5: Requirements and test/assessment methods for in-tank gauge systems and pressurised pipework systems
This standard gives requirements and the corresponding test/assessment methods applicable to leak detection kits, based upon volumetric loss from within the tank or pressurised pipework system. The kits are usually composed by:
- measuring device
; - evaluation device
; - alarm device
Leckanzeigesysteme - Teil 5: Anforderungen und Prüf-/Bewertungsmethoden für Tankinhaltsmesssysteme und druckbeaufschlagte Rohrleitungen
Diese Europäische Norm legt Anforderungen an und die einschlägigen Prüf-/Bewertungsmethoden für Leckanzeiger, die auf dem Volumenverlust aus dem Inneren des Tanks und/oder Rohrleitungssystems basieren, fest. Die Systeme bestehen in der Regel aus:
Messeinrichtung;
Auswerteeinrichtung;
Alarmeinrichtung.
Vorgesehener Verwendungszweck:
Leckanzeiger sind für den Einsatz in/mit ein- oder doppel¬wandigen unterirdischen Tanks oder ein- oder doppelwandigen unterirdischen und/oder oberirdischen Rohrleitungen vorgesehen, die für brennbare Flüssigkeiten mit einem Flammpunkt von höchstens 100 °C ausgelegt sind.
Systèmes de détection de fuites - Partie 5 : Exigences et méthodes d'essai/d'évaluation des systèmes de détection de fuites en citernes et des systèmes de tuyauterie sous pression
La présente Norme européenne spécifie les exigences et les méthodes d'essai/d'évaluation correspondantes applicables aux kits de détection de fuites, fondées sur la perte volumétrique dans le réservoir et/ou dans le système de tuyauteries. Les kits sont généralement constitués des éléments suivants :
— Dispositif de mesurage
— Dispositif d'évaluation
— Dispositif d'alarme
Usage prévu :
Les kits de détection de fuites sont destinés à être utilisés dans/avec des réservoirs souterrains à simple ou double paroi ou des tuyauteries à simple ou double paroi, souterraines et/ou aériennes, conçus pour des liquides inflammables ayant un point d'éclair inférieur ou égal à 100 °C.
Sistemi za kontrolo tesnosti - 5. del: Zahteve in metode za preskušanje in ocenjevanje sistemov zaznavanja netesnosti, vgrajenih v rezervoarje in tlačne cevovode
Ta standard določa zahteve ter ustrezne metode za preskušanje in ocenjevanje, ki se uporabljajo za komplete za kontrolo tesnosti, ki temeljijo na volumetrični izgubi v rezervoarju ali cevovodu pod tlakom. Kompleti so običajno sestavljeni iz: – merilne naprave , – naprave za ocenjevanje , – alarmne naprave.
