ASTM F3015-21
(Test Method)Standard Test Method for Accelerated Laboratory Roadwheel Generation of Belt Separation in Radial Passenger Car and Light Truck Tires through Load Range E
Standard Test Method for Accelerated Laboratory Roadwheel Generation of Belt Separation in Radial Passenger Car and Light Truck Tires through Load Range E
SIGNIFICANCE AND USE
4.1 Belt edge separation is a tire condition that can be encountered in tire use, particularly in high tire temperature environments.
4.2 The goal of this standard is to define a scientifically valid protocol for the laboratory generation of belt edge separation in a tire that has previously completed accelerated laboratory aging as described in Practice F2838. This test method does not establish performance limits or tolerances for tire specifications.
4.3 However, as stated in the scope, some tires may not develop belt edge separations under the specified test conditions. They may develop other EOT conditions that are not due to belt edge separation. Also, some tires may not develop any EOT conditions during the course of the test prior to a DCT.
SCOPE
1.1 This standard describes a laboratory method to evaluate tires for their tendency to develop belt edge separation, via the use of a standard roadwheel (Practice F551/F551M). This evaluation is conducted on tires that have undergone accelerated laboratory aging as described in Practice F2838.
1.2 The End-of-Test (EOT) conditions that can be produced by this method include target (belt-edge separation), non-target (conditions other than belt-related separations that can be developed in passenger and light truck tires through on-road use), and non-representative (conditions that are typically developed only on laboratory roadwheels). There is also the possibility that no visible EOT conditions may be generated during the course of this test. In this instance the user may choose to select a designated completion time (DCT) as the EOT condition.
1.3 The values stated in SI units are to be regarded as the standard. The values given in the data log in Appendix X1 in parentheses are provided for information only.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use. For specific precautionary statements, see Section 6.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
General Information
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: F3015 − 21
Standard Test Method for
Accelerated Laboratory Roadwheel Generation of Belt
Separation in Radial Passenger Car and Light Truck Tires
1
through Load Range E
This standard is issued under the fixed designation F3015; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
INTRODUCTION
The United States Congress passed the Transportation Recall Enhancement, Accountability and
Documentation (TREAD) Act in November 2000. Included in the Act were specific directions to the
National Highway Traffic Safety Administration (NHTSA) to upgrade tire safety standards.
As tire wear life has increased over the years, interest in the in-service aging of a tire’s internal
components has increased. To quote NHTSA, “. some members of Congress expressed the view that
thereisaneedforanagingtesttobeconductedonlightvehicletires.Theagencytentativelyconcludes
that we agree there is a need for an aging test in the proposed light vehicle tire standard because most
tire failures occur at mileages well beyond 2,720 kilometers (1,700 miles) to which tires are exposed
2
in the current FMVSS No. 109 Endurance Test.” Until the publication of this standard, there was
neither an industry nor a government standard practice for the accelerated laboratory roadwheel
generation of belt separation in tires.
This standard represents the body of work whose goal was to develop a scientifically valid, short
duration aged tire test standard focused on the generation of belt edge separation. The scope of this
work is limited to radial passenger car and light truck tires through Load Range E. The standards
development task group conducted research in order to determine: (1) the appropriate accelerated
laboratory aging conditions which correlate material property changes at the belt edge of the tire as
produced in the laboratory with those observed in service (as described in Practice F2838), and (2) the
appropriate laboratory roadwheel durability test parameters which are capable of producing belt edge
separations while avoiding those conditions which are exclusively by-products of roadwheel testing
(as described in this standard).
1. Scope use), and non-representative (conditions that are typically
developed only on laboratory roadwheels). There is also the
1.1 This standard describes a laboratory method to evaluate
possibility that no visible EOT conditions may be generated
tires for their tendency to develop belt edge separation, via the
during the course of this test. In this instance the user may
use of a standard roadwheel (Practice F551/F551M). This
choose to select a designated completion time (DCT) as the
evaluation is conducted on tires that have undergone acceler-
EOT condition.
ated laboratory aging as described in Practice F2838.
1.3 The values stated in SI units are to be regarded as the
1.2 The End-of-Test (EOT) conditions that can be produced
standard. The values given in the data log in Appendix X1 in
by this method include target (belt-edge separation), non-target
parentheses are provided for information only.
(conditions other than belt-related separations that can be
1.4 This standard does not purport to address all of the
developed in passenger and light truck tires through on-road
safety concerns, if any, associated with its use. It is the
responsibility of the user of this standard to establish appro-
1
This test method is under the jurisdiction of ASTM Committee F09 on Tires
priate safety, health, and environmental practices and deter-
and is the direct responsibility of Subcommittee F09.30 on Laboratory (Non-
mine the applicability of regulatory limitations prior to use.
Vehicular) Testing.
Current edition approved April 1, 2021. Published May 2021. Originally
For specific precautionary statements, see Section 6.
approved in 2013. Last previous edition approved in 2013 as F3015 – 13. DOI:
1.5 This international standard was developed in accor-
10.1520/F3015-21.
2
dance with internationally recognized principles on standard-
Federal Register Vol. 67, No. 43, Tuesday, March 5, 2002, p. 10068, Paragraph
6, “Aging Effects.” ization established in the Decision on Principles for the
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
F3015 − 21
Development of International Standards, Guides and Recom- 3.1.7 cold inflation pressure, n—the
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F3015 − 13 F3015 − 21
Standard Test Method for
Accelerated Laboratory Roadwheel Generation of Belt
Separation in Radial Passenger Car and Light Truck Tires
1
through Load Range E
This standard is issued under the fixed designation F3015; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
INTRODUCTION
The United States Congress passed the Transportation Recall Enhancement, Accountability and
Documentation (TREAD) Act in November 2000. Included in the Act were specific directions to the
National Highway Traffic Safety Administration (NHTSA) to upgrade tire safety standards.
As tire wear life has increased over the years, interest in the in-service aging of a tire’s internal
components has increased. To quote NHTSA, “. some members of Congress expressed the view that
there is a need for an aging test to be conducted on light vehicle tires. The agency tentatively concludes
that we agree there is a need for an aging test in the proposed light vehicle tire standard because most
tire failures occur at mileages well beyond 2,720 kilometers (1,700 miles) to which tires are exposed
2
in the current FMVSS No. 109 Endurance Test.” Until the publication of this standard, there was
neither an industry nor a government standard practice for the accelerated laboratory roadwheel
generation of belt separation in tires.
This standard represents the body of work whose goal was to develop a scientifically valid, short
duration aged tire test standard focused on the generation of belt edge separation. The scope of this
work is limited to radial passenger car and light truck tires through Load Range E. The standards
development task group conducted research in order to determine: (1) the appropriate accelerated
laboratory aging conditions which correlate material property changes at the belt edge of the tire as
produced in the laboratory with those observed in service (as described in Practice F2838), and (2) the
appropriate laboratory roadwheel durability test parameters which are capable of producing belt edge
separations while avoiding those conditions which are exclusively by-products of roadwheel testing
(as described in this standard).
1. Scope
1.1 This standard describes a laboratory method to evaluate tires for their tendency to develop belt edge separation, via the use
of a standard roadwheel (Practice F551/F551M). This evaluation is conducted on tires that have undergone accelerated laboratory
aging as described in Practice F2838.
1.2 The End-of-Test (EOT) conditions that can be produced by this method include target (belt-edge separation), non-target
(conditions other than belt-related separations that can be developed in passenger and light truck tires through on-road use), and
1
This test method is under the jurisdiction of ASTM Committee F09 on Tires and is the direct responsibility of Subcommittee F09.30 on Laboratory (Non-Vehicular)
Testing.
Current edition approved Nov. 15, 2013April 1, 2021. Published January 2014May 2021. Originally approved in 2013. Last previous edition approved in 2013 as
F3015 – 13. DOI: 10.1520/F3015-13.10.1520/F3015-21.
2
Federal Register Vol. 67, No. 43, Tuesday, March 5, 2002, p. 10068, Paragraph 6, “Aging Effects.”
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
F3015 − 21
non-representative (conditions that are typically developed only on laboratory roadwheels). There is also the possibility that no
visible EOT conditions may be generated during the course of this test. In this instance the user may choose to select a designated
completion time (DCT) as the EOT condition.
1.3 The values stated in SI units are to be regarded as the standard. The values given in the data log in Appendix X1 in parentheses
are provided for information only.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety safety, health, and healthenvironmental practices and determine the
applicability of regulatory limitations prior to use. For specific precautionary statements, see Section 6.
1.5 This international standard was developed in accordance with inter
...
