Safety requirements for dry-cleaning machines - Part 3: Machines using combustible solvents (ISO 8230-3:2008)

ISO 8230-3:2008 specifies safety requirements for dry-cleaning machines that use a combustible solvent (CS) as their cleaning medium.
It is applicable to such dry-cleaning machines, within the scope of ISO 8230-1, when they are used as intended and under conditions of misuse that are reasonably foreseeable by the manufacturer.
ISO 8230-3:2008, in conjunction with ISO 8230-1, deals with all significant hazards, significant hazardous situations and significant hazardous events that have been identified as being significant to the types of machines covered by this part of ISO 8230 and which require specific action by the designer or manufacturer to eliminate or reduce the risk.
It deals with the following significant hazards specific to the use of CS: hazards related to the entire dry-cleaning machine (electrical hazards, explosion hazards); hazards relating to the machine and tumblers (combustible solvent emission, explosion hazards during the cleaning phase, explosion hazards during the drying phase); hazards relating to the distilling equipment (combustible solvent emission, explosion hazards).

Sicherheitsanforderungen für Textilreinigungsanlagen - Teil 3: Maschinen, die entzündbare Lösemittel verwenden (ISO 8230-3:2008)

Dieser Teil der ISO 8230 legt Sicherheitsanforderungen für Textilreinigungsmaschinen fest, die ein entzündbares Lösungsmittel (CS), wie in ISO 8230-1 definiert, als ihr Reinigungsmittel verwenden.
Er ist gültig für diese Textilreinigungsmaschinen im Anwendungsbereich der ISO 8230 1, soweit sie wie vorgesehen und unter Bedingungen des Missbrauchs genutzt werden, die vom Hersteller vernünftigerweise vorhersehbar sind.
Dieser Teil der ISO 8230 befasst sich in Verbindung mit ISO 8230 1 mit allen wesentlichen Gefährdungen, wesentlichen gefährlichen Situationen und wesentlichen gefährlichen Ereignissen, die für die Arten von Maschinen die von diesem Teil der ISO 8230 abgedeckt werden, als wesentlich identifiziert worden sind, und die spezifische Maßnahmen vom Konstrukteur und Hersteller verlangen, um das Risiko auszuschließen.
Er befasst sich mit folgenden wesentlichen, für die Verwendung von CS spezifischen Gefährdungen:
   Gefährdungen in Verbindung mit der gesamten Textilreinigungsmaschine (elektrische Gefährdungen, Explosionsgefahren);
   Gefährdungen in Verbindung mit der Maschine (Emission entzündbarer Lösungsmittel, Explosions-gefahren während der Reinigungsphase, Explosionsgefahren während der Trocknungsphase);
   Gefährdungen in Verbindung mit der Destilliereinrichtung (Emission entzündbarer Lösungsmittel, Explosionsgefahren).
Dieser Teil der ISO 8230 gilt für Maschinen, die nach dem Datum seiner Veröffentlichung hergestellt wurden.

Exigences de sécurité pour les machines de nettoyage à sec - Partie 3: Machines utilisant des solvants combustibles (ISO 8230-3:2008)

L'ISO 8230-3:2008 spécifie les exigences de sécurité pour les machines de nettoyage à sec utilisant exclusivement des solvants combustibles (CS), tels que définis dans l'ISO 8230-1, comme moyen de nettoyage.
Elle s'applique aux machines de nettoyage au sec couvertes par le domaine d'application de l'ISO 8230‑1, lorsqu'elles sont utilisées normalement et dans les conditions de mauvaise utilisation raisonnablement prévisibles par le constructeur.
L'ISO 8230-3:2008 traite, conjointement avec l'ISO 8230‑1, de tous les phénomènes dangereux significatifs et des situations ou événements dangereux significatifs qui ont été identifiés comme étant pertinents aux machines couvertes par l'ISO 8230-3:2008, et qui exigent une action spécifique de la part du concepteur ou du fabricant pour éliminer ou réduire le risque.
Elle couvre les phénomènes dangereux significatifs suivants spécifiques aux machines de nettoyage à sec utilisant des solvants combustibles comme moyen de nettoyage: phénomènes dangereux associés aux machines de nettoyage à sec prises dans leur ensemble (phénomènes dangereux électriques, explosion); phénomènes dangereux associés à la machine (émission de solvant combustible, explosion durant la phase de nettoyage, explosion durant la phase de séchage); phénomènes dangereux relatifs à l'équipement de distillation (émission de solvant combustible, explosion).
