EN 2936:1996

Aerospace series - Bolts, T-head, relieved shank, long thread, in heat resisting nickel base alloy NI-P101HT (Waspaloy), silver plated - Classification: 1 210 MPa (at ambient temperature)/730°C

This standard specifies the characteristics of T-headed bolts with relieved shank, long thread, in NI-P101HT, silver plated, for aerospace applications. Classification: 1 210 MPa / 730 °C

Luft- und Raumfahrt - T-Kopfschrauben, Dünnschaft, langes Gewinde , aus hochwarmfester Nickelbasislegierung NI-P101HT (Waspaloy), versilbert - Klasse: 1 210 MPa (bei Raumtemperatur)/730°C

Diese Norm legt die Eigenschaften von T-Kopfschrauben mit Dünnschaft und langem Gewinde, aus NI-P101HT, versilbert, zur Verwendung in der Luft- und Raumfahrt fest. Klasse: 1 210 MPa / 730 °C

Série aérospatiale - Vis à tête en T, fût dégagé, filetage long, en alliage résistant à chaud à base de nickel NI-P101HT (Waspaloy), argentées - Classification: 1210 MPa (à température ambiante)/730°C

La présente norme spécifie les caractéristiques des vis à tête en T, à fu ^t dégagé, à filetage long, en NI-P101HT, argentées, pour les applications aérospatiales. Classification: 1 210 MPa / 730 °C

Aerospace series - Bolts, T-head, relieved shank, long thread, in heat resisting nickel base alloy NI-P101HT (Waspaloy), silver plated - Classification: 1 210 MPa (at ambient temperature)/730 °C

General Information

• Status: Published
• Publication Date: 19-Mar-1996
• Withdrawal Date: 29-Sep-1996
• ICS: 49.030.20 - Bolts, screws, studs
• Technical Committee: ASD-STAN - Aerospace
• Drafting Committee: ASD-STAN/D 3 - Mechanical
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 31-May-2017
• Completion Date: 11-Feb-2026
• Ref Project: SIST EN 2936:2001 - Aerospace series - Bolts, T-head, relieved shank, long thread, in heat resisting nickel base alloy NI-P101HT (Waspaloy), silver plated - Classification: 1 210 MPa (at ambient temperature)/730°C

Overview

EN 2936:1996 (adopted as SIST EN 2936:2001) is an aerospace-series standard that specifies the characteristics of T-head bolts with relieved shank and long thread, manufactured from the heat‑resisting nickel‑base alloy NI‑P101HT (Waspaloy) and silver plated. The fasteners are classified for mechanical performance 1 210 MPa (at ambient temperature) and rated for use up to 730 °C. This standard is part of the CEN aerospace series and is indexed under ICS 49.030.20 (bolts, screws, studs).

Key topics and requirements

• Material specification: Fasteners made from NI‑P101HT (Waspaloy) - a high‑temperature nickel‑base alloy suitable for hot aerospace environments.
• Bolt geometry: T‑head configuration with relieved (reduced) shank and long thread; intended to meet specific assembly and clamping needs.
• Surface finish: Silver plating for corrosion protection, electrical conductivity where required, and specific surface properties.
• Mechanical classification: 1 210 MPa strength class at ambient temperature and suitability for service up to 730 °C, indicating high-temperature mechanical performance.
• Conformance and marking: Provisions for identifying material, classification, and finish to support traceability (as typical for aerospace fastener standards).
• Scope limitation: Focused on the defined bolt type and material; it does not replace general installation, torqueing, or assembly standards.

Applications

• Aerospace structures and assemblies exposed to high temperatures (hot sections of engines, auxiliary equipment, or airframe areas with elevated thermal stress).
• Situations requiring a T‑head bolt for captive or slot‑mounted fastening where a relieved shank and long thread are necessary for adjustment or clearance.
• Use by aerospace fastener manufacturers, OEM procurement teams, design engineers, maintenance and repair organizations, and quality assurance bodies specifying high‑temperature fasteners.

Who uses this standard

• Design engineers specifying components for high‑temperature aerospace systems.
• Manufacturers producing NI‑P101HT (Waspaloy) T‑head bolts to ensure dimensional and material conformity.
• Procurement and quality teams verifying batch traceability, markings, and plating.
• Maintenance/overhaul facilities selecting appropriate replacement fasteners for certified assemblies.

Related standards

• This document is part of the CEN aerospace series and is nationally adopted as SIST EN 2936:2001. For broader fastener selection, refer to other aerospace-series standards governing bolt dimensions, torqueing, testing, and installation practices.

Keywords: EN 2936, T‑head bolts, NI‑P101HT, Waspaloy, silver plated, relieved shank, long thread, aerospace fasteners, 1210 MPa, 730 °C.

Standards Content (Sample)

SLOVENSKI STANDARD
01-januar-2001
Aerospace series - Bolts, T-head, relieved shank, long thread, in heat resisting
nickel base alloy NI-P101HT (Waspaloy), silver plated - Classification: 1 210 MPa
(at ambient temperature)/730 °C
Aerospace series - Bolts, T-head, relieved shank, long thread, in heat resisting nickel
base alloy NI-P101HT (Waspaloy), silver plated - Classification: 1 210 MPa (at ambient
temperature)/730°C
Luft- und Raumfahrt - T-Kopfschrauben, Dünnschaft, langes Gewinde , aus
hochwarmfester Nickelbasislegierung NI-P101HT (Waspaloy), versilbert - Klasse: 1 210
MPa (bei Raumtemperatur)/730°C
Série aérospatiale - Vis a tete en T, fut dégagé, filetage long, en alliage résistant a chaud
a base de nickel NI-P101HT (Waspaloy), argentées - Classification: 1210 MPa (a
température ambiante)/730°C
Ta slovenski standard je istoveten z: EN 2936
...
