EN 933-11:2009

(Main)

Tests for geometrical properties of aggregates - Part 11: Classification test for the constituents of coarse recycled aggregate

Tests for geometrical properties of aggregates - Part 11: Classification test for the constituents of coarse recycled aggregate

This European Standard describes a simple method for the examination of coarse recycled aggregates for the purpose of identifying and estimating the relative proportions of constituent materials. This reference test method should be used for type testing and in case of dispute. For other purposes, in particular factory production control, other methods may be used provided that an appropriate working relationship with the reference method has been established.
NOTE 1   This method is not appropriate for lightweight aggregates covered by EN 13055 series.
NOTE 2   If dangerous substances are found in while carrying out this method, they should be dealt with in accordance with regulations in the place of use.

Prüfverfahren für geometrische Eigenschaften von Gesteinskörnungen - Teil 11: Einteilung der Bestandteile in grober recyclierter Gesteinskörnung

Diese Europäische Norm legt ein einfaches Prüfverfahren für grobe recyclierte Gesteinskörnungen mit dem Ziel fest, die relativen Anteile der einzelnen Bestandteile zu identifizieren und abzuschätzen. Dieses Referenz-Prüf¬verfahren ist für die Erstprüfung und bei Streitfragen anzuwenden. Für andere Zwecke, speziell im Rahmen der werkseigenen Produktionskontrolle, dürfen andere Verfahren angewendet werden, sofern ein ausreichender Zusammenhang mit dem Referenzverfahren nachgewiesen wurde.
ANMERKUNG 1   Dieses Verfahren ist für die in der Normenreihe EN 13055 behandelten leichten Gesteinskörnungen nicht geeignet.
ANMERKUNG 2   Falls bei der Durchführung dieses Verfahrens gefährliche Stoffe gefunden werden, sollten sie entsprechend der am Verwendungsort geltenden Vorschriften behandelt werden.

Essais pour déterminer les caractéristiques géométriques des granulats - Partie 11: Essai de classification des constituants de gravillons recyclés

La présente Norme européenne décrit une méthode simple d’examen des gravillons recyclés afin d’identifier
et d’estimer les proportions relatives des différents constituants. Il convient d’utiliser cette méthode d’essai de
référence pour tous les essais de type, de même qu’en cas de litige. Á d’autres fins, en particulier pour le
contrôle de la production en usine, d’autres méthodes peuvent être utilisées à condition qu’il existe une
relation entre ces dernières et la méthode de référence.
NOTE 1 La présente méthode ne convient pas pour les granulats légers traités dans la série de normes de l’EN 13055.
NOTE 2 Si l’on détecte des substances dangereuses lors de l’application de la présente méthode, il convient de les
traiter conformément à la réglementation en vigueur sur le lieu d’utilisation.

Preskusi geometričnih lastnosti agregatov - 11. del: Klasifikacija sestavin grobega recikliranega agregata

Ta evropski standard opisuje enostavno metodo preverjanja grobih recikliranih agregatov za namen prepoznavanja in ocenjevanja relativnih deležev sestavnih materialov. Ta referenčna preskusna metoda bi se morala uporabljati za preskušanje tipa in v primeru spora. Za druge namene, zlasti za kontrolo proizvodnje, se lahko uporabijo druge metode, pod pogojem, da je bil vzpostavljen primerni delovni odnos z referenčno metodo.
OPOMBA 1: Ta metoda ni primerna za lahke agregate, zajete v seriji EN 13055.
OPOMBA 2: Če so med izvajanjem te metode odkrite nevarne snovi, je potrebno z njimi na kraju uporabe ravnati v skladu s predpisi.
