EN 6126:2018

Aerospace series - Fitting end, 24° internal cone, external thread, flareless type, size -32 tube diameter D=2 inches (D=50,8 mm) extra fine thread pitch inch series - Inch series - Design standard

This European Standard specifies the dimensions, tolerances and the required characteristics of a fitting end, 24° cone, external thread, flareless type, size −32 for use in hydraulic and fluid systems at 220 psi, diameter D = 2 inches (D = 50,8 mm) for aerospace applications.
This is a design standard, not valid for order.
This fitting can not be used for plug in union.

Luft- und Raumfahrt - Anschlussstück, Innenkonus 24°, Außengewinde, nicht gebördelt, Größe -32, Rohrdurchmesser D=2 inches (D=50,8 mm) Extrafeingewindesteigung - Inch-Reihe - Konstruktionsnorm

Série aérospatiale - Raccord, cône interne à 24°, filetage externe, de type sans épanoui et dimension -32 diamètre du tube D=2 inches (D=50,8 mm) filetage à pas extra fin - Série en inches - Norme de conception

Aeronavtika - Končnik, notranji stožec 24°, zunanji navoj, nerobljen, velikost -32 premer cevi D=2 inches (D=50,8 mm), dodatna serija finih palčnih mer - Palčne mere - Standard za projektiranje

Ta evropski standard določa dimenzije, tolerance in zahtevane lastnosti končnikov (stožec 24°, zunanji navoj, nerobljen, velikost –32) za uporabo v hidravličnih in tekočinskih sistemih pri 220 psi, premer D = 2 palca (D = 50,8 mm), ki se uporabljajo v aeronavtiki.
To je standard za zasnovo in ni veljaven za naročilo.
Tega končnika ni mogoče uporabiti za vtično zvezo.

General Information

• Status: Published
• Publication Date: 07-Aug-2018
• Withdrawal Date: 27-Feb-2019
• ICS: 49.080 - Aerospace fluid systems and components
• Technical Committee: ASD-STAN - Aerospace
• Drafting Committee: ASD-STAN/D 3 - Mechanical
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 08-Aug-2018
• Completion Date: 08-Aug-2018
• Ref Project: SIST EN 6126:2018 - Aerospace series - Fitting end, 24° internal cone, external thread, flareless type, size -32 tube diameter D=2 inches (D=50,8 mm) extra fine thread pitch inch series - Inch series - Design standard

Overview

EN 6126:2018 is a European design standard developed by the Aerospace and Defence Industries Association of Europe (ASD-STAN) and approved by CEN. This standard specifies the detailed dimensions, tolerances, and critical characteristics for a specific aerospace fitting end. It covers a 24° internal cone flareless fitting with an external thread, sized at −32, designed for tubes with a diameter of 2 inches (50.8 mm). Intended for use in hydraulic and fluid systems operating at 220 psi, this standard ensures precision and uniformity in aerospace fluid system components.

Importantly, EN 6126:2018 is a design standard only and is not valid for direct ordering. Additionally, this fitting is not suitable for plug-in unions.

Key Topics

• Fitting Type and Design

  • Flareless fitting with a 24° internal cone
  • External thread profile with extra fine inch-series thread pitch
  • Size designation: -32, supporting tube diameter of 2 inches (50.8 mm)

• Dimensional Specifications and Tolerances

  • Defined precise dimensions and tolerances outlined in multiple figures and tables
  • Expressed primarily in inches and millimeters for international usability
  • Thread class specified as 3A, following ISO aerospace UNJ thread standards

• Pressure and Application Parameters

  • Designed for hydraulic and fluid systems in aerospace environments at 220 psi
  • Tested and standardized to ensure reliability and safety in aerospace fluid components

• Design Variants

  • Several fitting end styles (G, B, E, F) providing options for different aerospace design needs
  • Optional undercuts and wrench pad dimensions to accommodate installation variations

• Standard Limitations and Usage

  • Not applicable for plug-in unions
  • Intended as a guideline for design rather than procurement
  • Compliance with referenced normative documents such as ISO 3161 for UNJ threads

Applications

EN 6126:2018 serves as a crucial guideline for aerospace engineers and designers involved in the development of hydraulic and fluid systems. Its applications include:

• Aerospace Hydraulic Systems
  Providing critical design parameters for secure and leak-resistant fittings in aircraft hydraulic systems that operate under specified pressure conditions.

• Fluid Transfer Lines
  Enabling manufacturers to standardize flareless fittings for reliable fluid conveyance, maintaining system integrity during aircraft operation.

• Component Manufacturing
  Assisting manufacturers to produce fitting ends that conform to aerospace industry standards, ensuring interchangeability, safety, and performance.

• Design Engineering
  Guiding aerospace design engineers to incorporate standardized fittings that meet stringent aerospace safety and functional requirements.

Related Standards

EN 6126:2018 references and aligns with various international and aerospace standards to ensure compatibility and coherence across industry practices:

• ISO 3161 – Aerospace UNJ Threads: General requirements and limit dimensions for aerospace thread forms used in conjunction with EN 6126 fittings.
• ASD-STAN Standards – Broader aerospace component design frameworks that complement EN 6126’s fitting specifications.
• CEN-CENELEC Internal Regulations – Framework for harmonization and adoption of European standards across member countries.

Professionals working with hydraulic and fluid system components in aerospace should consider EN 6126:2018 alongside these standards to ensure comprehensive compliance and optimal system performance.

---

By adhering to EN 6126:2018, aerospace manufacturers and engineers can achieve enhanced safety, consistency, and quality in the design of flareless fittings with 24° internal cones and external threads, tailored for demanding hydraulic applications at a 2-inch tube diameter. This supports the aerospace industry's rigorous requirements for fluid system integrity and reliability.
