• Abstract:

  Establishes a simple classification of the main types according to the mode of actuation of their obturation device and disregarding their details of conception and construction. Three categories of steam traps can be distinguished: mechanical traps, actuated by the level of condensate; thermostatic traps, actuated by the temperature of the condensate; thermodynamic traps, actuated by fluid dynamics.

• Status: Not Published
• Publication Date: 09-Jan-2028
• ICS: 23.060.01 - Valves in general
• Technical Committee: CEN/TC 69 - Industrial valves
• Drafting Committee: CEN/TC 69 - Industrial valves
• Current Stage: 4060 - Closure of enquiry - Enquiry
• Start Date: 07-Sep-2026
• Completion Date: 07-Sep-2026
• Ref Project: oSIST prEN ISO 6704:2026 - Automatic steam traps - Classification (ISO/DIS 6704:2026)

• Revises: EN 26704:1991 - Automatic steam traps - Classification (ISO 6704:1982)
• Effective Date: 05-Mar-2025

Overview

prEN ISO 6704:2026, Automatic Steam Traps - Classification provides an internationally recognized classification system for automatic steam traps based on the mode of actuation of their obturation devices. Developed by CEN and ISO/TC 153, this standard intentionally excludes detailed design and construction features, focusing solely on the operational principle behind each main steam trap type. By clarifying definitions and categories, prEN ISO 6704:2026 supports consistency in technical communication and specification across industries that utilize steam systems.

Automatic steam traps play a crucial role in energy efficiency, steam system reliability, and process safety by ensuring the efficient removal of condensate while preventing steam loss. The standard distinguishes three primary categories:

• Mechanical steam traps
• Thermostatic steam traps
• Thermodynamic steam traps

Key Topics

• Mechanical Steam Traps:
  Actuated by the level of condensate within the trap, these include variants such as closed float types (with or without a lever) and open top or inverted bucket designs.

• Thermostatic Steam Traps:
  Actuated by the temperature of the condensate. Types include vapour pressure traps, bimetallic or thermoelastic traps, and special forms using disc or cantilever elements.

• Thermodynamic Steam Traps:
  Operate based on fluid dynamics, opening and closing in response to pressure differences and flow patterns. Subtypes include disc traps, impulse traps, and orifice traps.

• Definitions and Terminology:
  Includes harmonized terms such as 'obturator' (the movable element within the valve controlling flow) for clarity in standardization and procurement.

Applications

prEN ISO 6704:2026 offers significant value across multiple application areas:

• Steam System Design and Maintenance:
  Enables designers, engineers, and maintenance teams to specify and select appropriate automatic steam trap types based on operating principles rather than manufacturer-specific designs, supporting interoperability and best-fit solutions.

• Energy Management and Efficiency:
  Correct steam trap classification assists in optimizing steam usage, decreasing energy loss, and minimizing maintenance costs, directly contributing to sustainable operation of boilers, heat exchangers, and process equipment.

• Industrial Sectors:
  Applicable in industries such as power generation, chemical processing, petrochemical, food and beverage, pharmaceuticals, and HVAC, wherever steam distribution and condensate removal are critical.

• Procurement and Compliance:
  Supports standard terminology in technical procurement and contract documentation, helping ensure compliance with recognized international standards and facilitating global trade of steam system components.

Related Standards

For comprehensive understanding and implementation, prEN ISO 6704:2026 relates to several key standards:

• ISO 6552:
  Provides additional terminology related to steam traps and valves.

• ISO/TC 153 Series:
  Covers broader standards on valves in general, supporting classification, testing, and performance assessment.

• ICS 23.060.01; 23.040.99:
  International Classification for Standards categories supporting broader valve and piping component industry practice.

Summary

prEN ISO 6704:2026 is a foundational document for the classification of automatic steam traps, ensuring clear, standardized categorization throughout steam system applications. Its implementation facilitates uniform communication, reliable specification, and improvement in overall system performance and energy efficiency in industrial steam operations. As organizations strive for operational excellence and energy rationalization, adherence to prEN ISO 6704 is an essential part of best practices for steam system design, operation, and maintenance.
