IEC 61439-3:2024

Low-voltage switchgear and controlgear assemblies - Part 3: Distribution boards intended to be operated by ordinary persons (DBO)

IEC 61439-3:2024 defines the specific requirements for distribution boards intended to be operated by ordinary persons (abbreviated DBO throughout this document, see 3.1.101) as follows:
- assemblies intended to be operated by ordinary persons (e.g. switching operations and replacing fuse-links), e.g. in domestic (household) applications;
- assemblies containing outgoing circuits with protective devices intended to be operated by ordinary persons, complying e.g. with IEC 60898-1, the IEC 61008 series, the IEC 61009 series, IEC 62606, IEC 62423 and IEC 60269-3;
- assemblies for applications where the nominal voltage to earth does not exceed 300 V AC (see Table G.1 of IEC 61439-1:2020);
NOTE The voltage limits for DC applications are under consideration.
- assemblies with a rated current (Inc) of the outgoing circuits not exceeding 125 A and a rated current (InA) not exceeding 250 A;
- assemblies intended for use in connection with the generation, transmission, distribution and conversion of electrical energy, and for the control of equipment consuming electrical energy and for associated data processing;
- enclosed, stationary assemblies;
- assemblies for indoor or outdoor use.
This second edition cancels and replaces the first edition published in 2012. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) alignment with the structure of IEC 61439-1:2020;
b) inclusion in the scope of more examples of the type of protection and control devices;
c) deletion of type A and Type B DBOs;
d) addition of a new Annex BB related to DBOs used in a prosumer’s electrical installation (PEI);
e) addition of a new Annex CC related to rated current of a DBO with additional source of supply in parallel/simultaneously with another source that is connected to the DBO e.g. PV.

Ensembles d'appareillage à basse tension - Partie 3: Tableaux de répartition destinés à être utilisés par des personnes ordinaires (DBO)

L'IEC 61439-3:2024 définit les exigences spécifiques pour les tableaux de répartition destinés à être utilisés par des personnes ordinaires (abrégés DBO dans l'ensemble du présent document, voir 3.1.101) ci-après:
- ensembles destinés à être utilisés par des personnes ordinaires (par exemple, pour manœuvrer des appareils de commande et remplacer des éléments de fusible), par exemple dans des applications domestiques;
- ensembles qui contiennent des circuits de départ avec des dispositifs de protection, destinés à être utilisés par des personnes ordinaires, qui satisfont par exemple à l'IEC 60898-1, à la série IEC 61008, à la série IEC 61009, à l'IEC 62606, à l'IEC 62423 et à l'IEC 60269-3;
- ensembles destinés à des applications pour lesquelles la tension nominale à la terre ne dépasse pas 300 V en courant alternatif (voir Tableau G.1 de l'IEC 61439-1:2020);
NOTE Les limites de tension pour les applications en courant continu sont à l'étude.
- ensembles dans lesquels le courant assigné (Inc) des circuits de départ est inférieur ou égal à 125 A et dont le courant assigné (InA) est inférieur ou égal à 250 A;
- ensembles destinés à être utilisés avec des équipements conçus pour la production, le transport, la distribution et la conversion de l'énergie électrique, la commande des matériels qui consomment de l'énergie électrique et le traitement des données associées;
- ensembles fixes sous enveloppe;
- ensembles pour utilisation en intérieure ou en extérieur.
Cette seconde édition annule et remplace la première édition parue en 2012. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) alignement sur la structure de l'IEC 61439-1:2020;
b) inclusion dans le domaine d'application de plus d'exemples de types de dispositifs de protection et de commande;
c) suppression des DBO de type A et de type B;
d) ajout d'une nouvelle Annexe BB relative aux DBO utilisés dans une installation électrique de prosommateur (PEI);
e) ajout d'une nouvelle Annexe CC relative au courant assigné d'un DBO avec une source d'alimentation supplémentaire parallèlement/simultanément avec une autre source reliée au DBO, par exemple un panneau photovoltaïque (PV).

General Information

• Status: Published
• Publication Date: 25-Mar-2024
• ICS: 29.130.20 - Low voltage switchgear and controlgear
• Technical Committee: SC 121B - Low-voltage switchgear and controlgear assemblies
• Drafting Committee: MT 4 - TC 121/SC 121B/MT 4
• Current Stage: PPUB - Publication issued
• Start Date: 22-Mar-2024
• Completion Date: 26-Mar-2024

Relations

• Revises: IEC 61439-3:2012/COR2:2019 - Corrigendum 2 - Low-voltage switchgear and controlgear assemblies - Part 3: Distribution boards intended to be operated by ordinary persons (DBO)
• Effective Date: 05-Sep-2023
• Revises: IEC 61439-3:2012/COR1:2013 - Corrigendum 1 - Low-voltage switchgear and controlgear assemblies - Part 3: Distribution boards intended to be operated by ordinary persons (DBO)
• Effective Date: 05-Sep-2023
• Revises: IEC 61439-3:2012 - Low-voltage switchgear and controlgear assemblies - Part 3: Distribution boards intended to be operated by ordinary persons (DBO)
• Effective Date: 05-Sep-2023

Standards Content (Sample)

IEC 61439-3 ®
Edition 2.0 2024-03
COMMENTED VERSION
INTERNATIONAL
STANDARD
colour
inside
Low-voltage switchgear and controlgear assemblies –
Part 3: Distribution boards intended to be operated by ordinary persons (DBO)
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from
either IEC or IEC's member National Committee in the country of the requester. If you have any questions about IEC
copyright or have an enquiry about obtaining additional rights to this publication, please contact the address below or
your local IEC member National Committee for further information.

IEC Secretariat Tel.: [phone]
3, rue de Varembé [e-mail]
CH-1211 Geneva 20 www.iec.ch
Switzerland
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.

About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigendum or an amendment might have been published.

IEC publications search - webstore.iec.ch/advsearchform IEC Products & Services Portal - products.iec.ch
The advanced search enables to find IEC publications by a
Discover our powerful search engine and read freely all the
variety of criteria (reference number, text, technical publications previews, graphical symbols and the glossary.
committee, …). It also gives information on projects, replaced With a subscription you will always have access to up to date
and withdrawn publications. content tailored to your needs.

IEC Just Published - webstore.iec.ch/justpublished
Electropedia - www.electropedia.org
Stay up to date on all new IEC publications. Just Published
The world's leading online dictionary on electrotechnology,
details all new publications released. Available online and
containing more than 22 500 terminological entries in English
once a month by email.
and French, with equivalent terms in 25 additional languages.

Also known as the International Electrotechnical Vocabulary
IEC Customer Service Centre - webstore.iec.ch/csc
(IEV) online.
If you wish to give us your feedback on this publication or

need further assistance, please contact the Customer Service
Centre: [e-mail].
IEC 61439-3 ®
Edition 2.0 2024-03
COMMENTED VERSION
INTERNATIONAL
STANDARD
colour
inside
Low-voltage switchgear and controlgear assemblies –
Part 3: Distribution boards intended to be operated by ordinary persons (DBO)
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
ICS 29.130.20 ISBN 978-2-8322-8659-3
– 2 – IEC 61439-3:2024 CMV © IEC 2024
